基于光谱知识库的TM影像冬小麦条锈病监测研究

Monitoring of Winter Wheat Stripe Rust Based on the Spectral Knowledge Base for TM Images

  • 摘要
  • 论文信息
  • 参考文献
  • 被引情况
  • PDF全文
分享:

摘要

基于高光谱信息的冬小麦条锈病严重度反演模型通常不能直接应用在宽波段卫星影像上, 而拥有高光谱波段信息的航空遥感影像又因数据尺度小、 成本高难以应用于大规模监测。 文章提出一种通过构建冬小麦条锈病光谱知识库, 利用TM影像实现病情识别和监测的方法。 该方法以包含各种不同病情严重度的试验田的三幅小麦关键生育期PHI航空遥感影像为媒介, 利用病情指数DI的经验反演模型和基于波谱响应函数的TM波段模拟, 建立DI和TM波段模拟反射率间的光谱知识库。 在此基础上, 通过马氏距离法和光谱角度填图(SAM)法将待检象元的光谱信息与光谱知识库进行匹配分析从而实现对病情识别和监测。 监测的精度利用模拟TM象元进行评价, 识别的效果利用TM影像象元进行检验。 结果表明, 该方法在一定生育期范围内具有较佳的监测精度和识别效果。 其中, 使用模拟TM象元在小麦灌浆期精度最佳, 评价的R2达到0.93, 乳熟期次之, 拔节期最差, 基本不能用于监测。 使用TM影像象元在灌浆期和乳熟期可较好地识别染病象元, 在拔节期无法有效识别染病象元。 匹配方法马氏距离法略优于光谱角度匹配法。

Abstract

In most cases, the reversion model for monitoring the severity degree of stripe rust based on the hyperspectral information can not be directly applied by the satellite images with relatively broad bandwidth, while the airborne hyperspectral images can not be applied for large-scale monitoring either, due to the scale limitation of its data and high cost. For resolving this dilemma, we developed a monitoring method based on PHI images, which relies on the construction of spectral knowledge base of winter wheat stripe rust. Three PHI images corresponding to the winter wheat experimental field that included different severity degree of stripe rust were used as a medium to establish the spectral knowledge base of relationships between disease index (DI) and the simulated reflectance of TM bands by using the empirical reversion model of DI(%) and the relative spectral response (RSR) function of TM-5 sensor. Based on this, we can monitor and identify the winter wheat stripe rust by matching the spectral information of an untested pixel to the spectral knowledge base via Mahalanobis distance or spectral angle mapping (SAM). The precision of monitoring was validated by simulated TM pixels, while the effectiveness of identification was tested by pixels from TM images. The results showed that the method can provide high precision for monitoring and reasonable accuracy for identification in some certain growth stages of winter wheat. Based on the simulated TM pixels, the model performed best in the pustulation period, yielded a coefficient of determination R2=0.93, while the precision of estimates dropped in the milk stage, and performed worst in the jointing stage, which is basically inappropriate for monitoring. Moreover, by using the pixels from TM images, the infected pixels could be identified accurately in pustulation and milk stages, while failed to be identified in jointing stage. For matching algorithms, the Mahalanobis distance method produced a slightly better result than SAM method.

广告组6 - 调制器
补充资料

中图分类号:O657.3;S127

基金项目:国家(863计划)项目(2006AA10A302, 2006AA10Z203), 国家科技支撑计划项目(2008DADAB02-2, 2007BAH12B02, 2006BAD10A01)和环境与灾害监测预报小卫星星座减灾应用系统项目资助

收稿日期:2009-06-29

修改稿日期:2009-10-02

网络出版日期:0001-01-01

作者单位    点击查看

张竞成:浙江大学农业遥感与信息技术应用研究所, 浙江 杭州310029国家农业信息化工程技术研究中心, 北京100097
李建元:国家农业信息化工程技术研究中心, 北京100097同济大学电子与信息工程学院, 上海201800
杨贵军:国家农业信息化工程技术研究中心, 北京100097
黄文江:国家农业信息化工程技术研究中心, 北京100097
罗菊花:国家农业信息化工程技术研究中心, 北京100097
王纪华:浙江大学农业遥感与信息技术应用研究所, 浙江 杭州310029国家农业信息化工程技术研究中心, 北京100097

联系人作者:张竞成(zjc19840222@gmail.com)

备注:张竞成, 1984年生, 浙江大学农业遥感与信息技术应用研究所博士研究生

【1】Dereje Hailu, Chemeda Fininsa. Crop Protection, 2007, 26(8): 1209.

【2】Lars Wiik. Crop Protection, 2009, 28(1): 82.

【3】Kim K S, Beresford R M. Agricultural and Forest Meteorology, 2008, 148(8-9): 1374.

【4】CHEN Xian-ming, Maey Moore, Eugene A Milus, et al. Plant Disease, 2002, 86: 39.

【5】Kurt S. Crop Protection, 2002, 21: 495.

【6】Kolmer James A. Current Opinion in Plant Biology, 2005, 8: 441.

【7】JIANG Jin-bao, CHEN Yun-hao, HUANG Wen-jiang(蒋金豹, 陈云浩, 黄文江). Spectroscopy and Spectral Analysis(光谱学与光谱分析), 2007, 27(7): 1363.

【8】JIANG Jin-bao, CHEN Yun-hao, HUANG Wen-jiang, et al(蒋金豹, 陈云浩, 黄文江, 等). Transactions of the Chinese Society of Agricultural Engineering(农业工程学报), 2008, 24(1): 35.

【9】LUO Ju-hua, HUANG Wen-jiang, WEI Chao-ling, et al(罗菊花, 黄文江, 韦朝领, 等). Journal of Natural Disasters(自然灾害学报), 2008, 17(6): 115.

【10】HUANG Wen-jiang, David W Lamb, NIU Zheng, et al. Precision Agric., 2007, (8): 187.

【11】BAO Yan-song, WANG Ji-hua, LIU Liang-yun, et al(鲍艳松, 王纪华, 刘良云, 等). Transactions of the Chinese Society of Agricultural Engineering(农业工程学报), 2007, 23(2): 139.

【12】SUN Jie, ZHANG Hong-lei(孙洁, 张宏磊). Microcomputer Information(微计算机信息), 2008, 21: 225.

【13】ZHANG Bing, SHEN Qian, LI Jun-sheng, et al(张兵, 申茜, 李俊生, 等). Journal of Lake Sciences(湖泊科学), 2009, 21(2): 182.

【14】SHAO Hui, WANG Jian-yu, XUE Yong-qi(邵晖, 王建宇, 薛永祺). Journal of Remote Sensing(遥感学报), 1998, 2(4): 251.

【15】WANG Ji-hua, ZHAO Chun-jiang, HUANG Wen-jiang(王纪华, 赵春江, 黄文江). Foundation and Application of Agricultrual Quantitative Remote Sensing(农业定量遥感基础与应用). Beijing: Science Press(北京: 科学出版社), 2008. 357.

【16】XU Wei-dong, YI Qiu, KUANG Ding-bo(许卫东, 尹球, 匡定波). Journal of Infrared and Millimeter Waves(红外与毫米波学报), 2005, 24(4): 296.

引用该论文

ZHANG Jing-cheng,LI Jian-yuan,YANG Gui-jun,HUANG Wen-jiang,LUO Ju-hua,WANG Ji-hua. Monitoring of Winter Wheat Stripe Rust Based on the Spectral Knowledge Base for TM Images[J]. Spectroscopy and Spectral Analysis, 2010, 30(6): 1579-1585

张竞成,李建元,杨贵军,黄文江,罗菊花,王纪华. 基于光谱知识库的TM影像冬小麦条锈病监测研究[J]. 光谱学与光谱分析, 2010, 30(6): 1579-1585
