基于稀疏表示的失真卫星立体图像全参考质量评价

Sparse Representation-Based Full-Reference Quality Assessment of Distorted Satellite Stereo Images

  • 摘要
  • 论文信息
  • 参考文献
  • 被引情况
  • PDF全文
分享:

摘要

针对建筑物检测特定应用,提出一种基于稀疏表示的失真立体图像全参考质量评价方法。首先构建了一种新的失真卫星立体图像数据库,使用角点检测和数字表面模型的高程信息进行建筑物检测,并根据失真图像检测角点变化,提出检测准确率指标来表示图像的失真程度;然后提出一种基于稀疏表示的客观评价模型,其分别提取原始图像和失真图像的尺度不变特征转换和二进制稳健不变尺度特征进行字典学习;利用稀疏表示测量原始图像和失真图像之间的相似性,得到4个质量分数;最后通过支持向量回归融合4个质量分数得到最终的客观评价值。在构建的数据库上进行测试,实验结果表明,皮尔逊线性相关系数值高于0.90,斯皮尔曼等级相关系数值高于0.87,与现有的评价方法相比,所提方法能更好地反映卫星立体图像的质量。

Abstract

Aiming at the specific application of building detection, a sparse representation-based full-reference quality assessment method for distorted satellite stereoscopic images is proposed. First, a new distorted satellite stereo image database is constructed, in which the corner detection and the digital surface model elevation information are used for building detection. And a detection accuracy index is proposed to represent the degree of distortion based on the change of the detected corners. Then, an objective evaluation model based on sparse representation is proposed, which extracts scale-invariant feature transforms and binary robust invariant scalable key points of the original and the distorted images for dictionary learning. Four quality scores are obtained using sparse representation to measure the similarity between the original and the distorted images. Finally, the final objective assessment value is obtained by fusing the four quality scores using support vector regression. The test is carried out on the constructed database. The test results on the constructed database show that the Pearson linear correlation coefficient is higher than 0.90, and the Spearman rank correlation coefficient is higher than 0.87. Compared with the existing assessment methods, the proposed objective evaluation method can better reflect the quality of satellite stereo images.

Newport宣传-MKS新实验室计划
补充资料

中图分类号:TP751.1

DOI:10.3788/aos201838.1210002

所属栏目:图像处理

基金项目:国家自然科学基金(61622109)

收稿日期:2018-07-10

修改稿日期:2018-08-06

网络出版日期:2018-08-13

作者单位    点击查看

熊义明:宁波大学信息科学与工程学院, 浙江 宁波 315211
邵枫:宁波大学信息科学与工程学院, 浙江 宁波 315211
孟祥超:宁波大学信息科学与工程学院, 浙江 宁波 315211

联系人作者:邵枫(shaofeng@nbu.edu.cn)

【1】Zhang Y J, Zheng M T, Xiong X D, et al. Multistrip bundle block adjustment of ZY-3 satellite imagery by rigorous sensor model without ground control point[J]. IEEE Geoscience and Remote Sensing Letters, 2015, 12(4): 865-869.

【2】Scales K L, Hazen E L, Jacox M G, et al. Scale of inference: on the sensitivity of habitat models for wide-ranging marine predators to the resolution of environmental data[J]. Ecography, 2017, 40(1): 210-220.

【3】Jiang Y H, Zhang G, Tang X M, et al. Improvement and assessment of the geometric accuracy of Chinese high-resolution optical satellites[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2015, 8(10): 4841-4852.

【4】Li S M, Chang Y L, Duan Z C. Objective assessment of stereoscopic image comfort based on convolutional neural network[J]. Acta Optica Sinica, 2018, 38(6): 0610003.
李素梅, 常永莉, 段志成. 基于卷积神经网络的立体图像舒适度客观评价[J]. 光学学报, 2018, 38(6): 0610003.

【5】Hou C P, Ma T T, Yue G H, et al. Multiply-distorted image quality assessment based on high-order phase congruency[J]. Laser & Optoelectronics Progress, 2017, 54(7): 071001.
侯春萍, 马彤彤, 岳广辉, 等. 基于高阶相位一致性的混合失真图像质量评价[J]. 激光与光电子学进展, 2017, 54(7): 071001.

【6】Hasanlou M, Saradjian M R. Quality assessment of Pan-sharpening methods in high-resolution satellite images using radiometric and geometric index[J]. Arabian Journal of Geosciences, 2016, 9(1): 1-10.

【7】Kwan C, Budavari B, Bovik A C, et al. Blind quality assessment of fused WorldView-3 images by using the combinations of pansharpening and hypersharpening paradigms[J]. IEEE Geoscience and Remote Sensing Letters, 2017, 14(10): 1835-1839.

【8】Yang J X, Zhao Y Q, Yi C, et al. No-reference hyperspectral image quality assessment via quality-sensitive features learning[J]. Remote Sensing, 2017, 9(4): 305-329.

【9】Yang X C, Sun Q S, Wang T S. A usability-based subjective remote sensing image quality assessment database[J]. Signal, Image and Video Processing, 2017, 11(4): 697-704.

【10】zcan A H, nsalan C, Reinartz P. Building detection using local features and DSM data[C]//2013 6th International Conference on Recent Advances in Space Technologies (RAST), 2013: 139-143.

【11】Schmid C, Mohr R, Bauckhage C. Evaluation of interest point detectors[J]. International Journal of Computer Vision, 2000, 37(2): 151-172.

【12】Harris C, Stephens M. A combined corner and edge detector[C]//Proceedings of the Alvey Vision Conference, 1988.

【13】Tian J J, Nielsen A A, Reinartz P. Building damage assessment after the earthquake in Haiti using two post-event satellite stereo imagery and DSMs[J]. International Journal of Image and Data Fusion, 2015, 6(2): 155-169.

【14】Tian J J, Cui S Y, Reinartz P. Building change detection based on satellite stereo imagery and digital surface models[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(1): 406-417.

【15】Lowe D G. Distinctive image features from scale-invariant keypoints[J]. International Journal of Computer Vision, 2004, 60(2): 91-110.

【16】Leutenegger S, Chli M, Siegwart R Y. BRISK:binary robust invariant scalable keypoints[C]//2011 International Conference on Computer Vision, 2011: 2548-2555.

【17】Tropp J A, Gilbert A C. Signal recovery from random measurements via orthogonal matching pursuit[J]. IEEE Transactions on Information Theory, 2007, 53(12): 4655-4666.

【18】Aharon M, Elad M, Bruckstein A. K-SVD:an algorithm for designing overcomplete dictionaries for sparse representation[J]. IEEE Transactions on Signal Processing, 2006, 54(11): 4311-4322.

【19】Rubinstein R, Zibulevsky M, Elad M. Efficient implementation of the K-SVD algorithm using batch orthogonal matching pursuit[J].Computer Science Department, 2008, 40(8): 1-15.

【20】Kang L W, Hsu C Y, Chen H W, et al. Feature-based sparse representation for image similarity assessment[J]. IEEE Transactions on Multimedia, 2011, 13(5): 1019-1030.

【21】Jiang Q P, Shao F, Lin W S, et al. Learning sparse representation for objective image retargeting quality assessment[J]. IEEE Transactions on Cybernetics, 2018, 48(4): 1276-1289.

【22】Chang C C, Lin C J. LIBSVM[J]. ACM Transactions on Intelligent Systems and Technology, 2011, 2(3): 1-27.

【23】Wang Z, Simoncelli E P, Bovik A C. Multiscale structural similarity for image quality assessment[C]//The Thrity-Seventh Asilomar Conference on Signals, Systems & Computers, 2003: 1398-1402.

【24】Wang Z, Bovik A C, Sheikh H R, et al. Image quality assessment: from error visibility to structural similarity[J]. IEEE Transactions on Image Processing, 2004, 13(4): 600-612.

【25】Sheikh H R, Bovik A C,de Veciana G. An information fidelity criterion for image quality assessment using natural scene statistics[J]. IEEE Transactions on Image Processing, 2005, 14(12): 2117-2128.

【26】Sheikh H R, Bovik A C. Image information and visual quality[J]. IEEE Transactions on Image Processing, 2006, 15(2): 430-444.

【27】Zhang L, Zhang L, Mou X Q. RFSIM: a feature based image quality assessment metric using Riesz transforms[C]//2010 IEEE International Conference on Image Processing, 2010: 321-324.

【28】Zhang L, Zhang L, Mou X Q, et al. FSIM: a feature similarity index for image quality assessment[J]. IEEE Transactions on Image Processing, 2011, 20(8): 2378-2386.

【29】Zhang L, Li H Y. SR-SIM: a fast and high performance IQA index based on spectral residual[C]//2012 19th IEEE International Conference on Image Processing, 2012: 1473-1476.

【30】Liu A M, Lin W S, Narwaria M. Image quality assessment based on gradient similarity[J]. IEEE Transactions on Image Processing, 2012, 21(4): 1500-1512.

引用该论文

Xiong Yiming,Shao Feng,Meng Xiangchao. Sparse Representation-Based Full-Reference Quality Assessment of Distorted Satellite Stereo Images[J]. Acta Optica Sinica, 2018, 38(12): 1210002

熊义明,邵枫,孟祥超. 基于稀疏表示的失真卫星立体图像全参考质量评价[J]. 光学学报, 2018, 38(12): 1210002
