Electric anapoles, arising from the destructive interference of primitive and toroidal electric dipole moments, have recently emerged as a fundamental class of non-scattering sources. On the other hand, super-scattering states represent the opposite regime wherein the scattering cross-section of a subwavelength particle exceeds the single-channel limit, leading to a strong scattering behavior. Here, we demonstrate that the interplay between the topology of light and the subwavelength scatterer can lead to these two opposite responses within an isolated all-dielectric meta-atom. In particular, we present the emergence of a new non-scattering state, referred to as hybrid anapole, which surpasses conventional electric dipole anapoles by achieving a remarkable 23-fold enhancement in the suppression of far-field radiation and almost threefold enhancement in the confinement of electromagnetic energy inside the meta-atom. We also explore the role of particle orientation and its inversion symmetry in the scattering response and predict the possibility of switching between non-scattering and super-scattering states within the same platform. The presented study elucidates the role of light and matter topologies in the scattering response of subwavelength meta-atoms, uncovering two opposite regimes of light-matter interaction and opening new avenues in applications such as nonlinear optics and spectroscopy.

Subnatural-linewidth single photons are of vital importance in quantum optics and quantum information science. According to previous research, it appears difficult to utilize resonance fluorescence to generate single photons with subnatural linewidth. Here we propose a universally applicable approach to generate fluorescent single photons with subnatural linewidth, which can be implemented based on Λ-shape and similar energy structures. Further, the general condition to obtain fluorescent single photons with subnatural linewidth is revealed. The single-photon linewidth can be easily manipulated over a broad range by external fields, which can be several orders of magnitude smaller than the natural linewidth. Our study can be easily implemented in various physical platforms with current experimental techniques and will significantly facilitate the research on the quantum nature of resonance fluorescence and the technologies in quantum information science.

Bound states in the continuum (BICs) in artificial photonic structures have received considerable attention since they offer unique methods for the extreme field localization and enhancement of light-matter interactions. Usually, the symmetry-protected BICs are located at high symmetric points, while the positions of accidental BICs achieved by tuning the parameters will appear at some points in momentum space. Up to now, to accurately design the position of the accidental BIC in momentum space is still a challenge. Here, we theoretically and experimentally demonstrate an accurately designed accidental BIC in a two-coupled-oscillator system consisting of bilayer gratings, where the optical response of each grating can be described by a single resonator model. By changing the interlayer distance between the gratings to tune the propagation phase shift related to wave vectors, the position of the accidental BIC can be arbitrarily controlled in momentum space. Moreover, we present a general method and rigorous numerical analyses for extracting the polarization vector fields to observe the topological properties of BICs from the polarization-resolved transmission spectra. Finally, an application of the highly efficient second harmonic generation assisted by quasi-BIC is demonstrated. Our work provides a straightforward strategy for manipulating BICs and studying their topological properties in momentum space.

Low-power, flexible, and integrated photodetectors have attracted increasing attention due to their potential applications of photosensing, astronomy, communications, wearable electronics, etc. Herein, the samples of ZnO microwires having p-type (Sb-doped ZnO, ZnO:Sb) and n-type (Ga-doped ZnO, ZnO:Ga) conduction properties were synthesized individually. Sequentially, a p-n homojunction vertical structure photodiode involving a single ZnO:Sb microwire crossed with a ZnO:Ga microwire, which can detect ultraviolet light signals, was constructed. When exposed under 360 nm light illumination at -0.1V, the proposed photodiode reveals pronounced photodetection features, including a largest on/off ratio of 105, responsivity of 2.3 A/W, specific detectivity of ∼6.5×1013 Jones, noise equivalent power of 4.8×10-15WHz-1/2, and superior photoelectron conversion efficiency of ∼7.8%. The photodiode also exhibits a fast response/recovery time of 0.48 ms/9.41 ms. Further, we propose a facile and scalable construction scheme to integrate a p-ZnO:Sb⊗n-ZnO:Ga microwires homojunction component into a flexible, array-type detector, which manifests significant flexibility and electrical stability with insignificant degradation. Moreover, the as-constructed array unit can be integrated into a practical photoimaging system, which demonstrates remarkable high-resolution single-pixel imaging capability. The results represented in this work may supply a workable approach for developing low-dimensional ZnO-based homojunction optoelectronic devices with low-consumption, flexible, and integrated characteristics.

Tunable lasers, with the ability to continuously vary their emission wavelengths, have found widespread applications across various fields such as biomedical imaging, coherent ranging, optical communications, and spectroscopy. In these applications, a wide chirp range is advantageous for large spectral coverage and high frequency resolution. Besides, the frequency accuracy and precision also depend critically on the chirp linearity of the laser. While extensive efforts have been made on the development of many kinds of frequency-agile, widely tunable, narrow-linewidth lasers, wideband yet precise methods to characterize and linearize laser chirp dynamics are also demanded. Here we present an approach to characterize laser chirp dynamics using an optical frequency comb. The instantaneous laser frequency is tracked over terahertz bandwidth at 1 MHz intervals. Using this approach we calibrate the chirp performance of 12 tunable lasers from Toptica, Santec, New Focus, EXFO, and NKT that are commonly used in fiber optics and integrated photonics. In addition, with acquired knowledge of laser chirp dynamics, we demonstrate a simple frequency-linearization scheme that enables coherent ranging without any optical or electronic linearization unit. Our approach not only presents novel wideband, high-resolution laser spectroscopy, but is also critical for sensing applications with ever-increasing requirements on performance.

With the swift advancement of neural networks and their expanding applications in many fields, optical neural networks have gradually become a feasible alternative to electrical neural networks due to their parallelism, high speed, low latency, and power consumption. Nonetheless, optical nonlinearity is hard to realize in free-space optics, which restricts the potential of the architecture. To harness the benefits of optical parallelism while ensuring compatibility with natural light scenes, it becomes essential to implement two-dimensional spatial nonlinearity within an incoherent light environment. Here, we demonstrate a lensless opto-electrical neural network that incorporates optical nonlinearity, capable of performing convolution calculations and achieving nonlinear activation via a quantum dot film, all without an external power supply. Through simulation and experiments, the proposed nonlinear system can enhance the accuracy of image classification tasks, yielding a maximum improvement of 5.88% over linear models. The scheme shows a facile implementation of passive incoherent two-dimensional nonlinearities, paving the way for the applications of multilayer incoherent optical neural networks in the future.

Since the emergence of graphene, transition metal dichalcogenides, and black phosphorus, two-dimensional materials have attracted significant attention and have driven the development of fundamental physics and optoelectronic devices. Metal phosphorus trichalcogenides (MPX3), due to their large bandgap of 1.3–3.5 eV, enable the extension of optoelectronic applications to visible and ultraviolet (UV) wavelengths. Micro-Z/I-scan (μ-Z/I-scan) and micro-pump-probe (μ-pump-probe) setups were used to systematically investigate the third-order nonlinear optical properties and ultrafast carrier dynamics of the representative material AgInP2S6. UV-visible absorption spectra and density functional theory (DFT) calculations revealed a quantum confinement effect, in which the bandgap decreased with increasing thickness. The two-photon absorption (TPA) effect is exhibited under the excitation of both 520 and 1040 nm femtosecond pulses, where the TPA coefficient decreases as the AgInP2S6 thickness increases. In contrast, the TPA saturation intensity exhibits the opposite behavior that the TPA saturation is more likely to occur under visible excitation. After the valence band electrons undergo photon transitions to the conduction band, the non-equilibrium carriers relax through non-radiative and defect-assisted recombination. These findings provide a comprehensive understanding of the optical response process of AgInP2S6 and are a valuable reference for the development of optoelectronic devices.

We report the design, fabrication, and characterization of a universal silicon PN junction ring resonator for C band error-free communication links operated up to 50 Gb/s with co-designed optical modulation and detection performance. The universal p-n junction ring device shows co-designed detection responsivity up to 0.84 A/W, in conjunction with a modulation efficiency of ∼4V·mm and >8dB optical modulation extinction ratio, enabling C band 50 Gb/s NRZ communication link with a bit error rate ≤3×10-12. Individually, the speed of modulation and detection is measured up to 112 Gb/s and 80 Gb/s, respectively. The principle of co-designing the PN junction ring modulator and detector performance required for error-free communication links can significantly ease the fabrication yield challenges of ring structures by reducing the number of types of devices. The principle can also be applied to O band wavelengths. To the best of our knowledge, for the first time, a device of this type has achieved both error-free modulation and detection operation up to 50 Gb/s in the C band individually or in conjugation as an error-free communication link, which paves the way to realize a >1.6Tb/s all-silicon WDM-based error-free optical transceiver link in the future and is essential for future programmable photonics circuits.

Entanglement has been recognized as being crucial when implementing various quantum information tasks. Nevertheless, quantifying entanglement for an unknown quantum state requires nonphysical operations or post-processing measurement data. For example, evaluation methods via quantum state tomography require vast amounts of measurement data and likely estimation. Although a direct entanglement determination has been reported for the unknown pure state, it is still tricky for the mixed state. In this work, assisted by weak measurement and deep learning technology, we directly detect the entanglement (namely, the concurrence) of a class of two-photon polarization-entangled mixed states both theoretically and experimentally according to the local photon spatial distributions after weak measurement. In this way, the number of projective bases is much smaller than that required in quantum state tomography.

Brillouin microscopy, which maps the elastic modulus from the frequency shift of scattered light, has evolved to a faster speed for the investigation of rapid biomechanical changes. Impulsive stimulated Brillouin scattering (ISBS) spectroscopy has the potential to speed up measurement through the resonant amplification interaction from pulsed excitation and time-domain continuous detection. However, significant progress has not been achieved due to the limitation in signal-to-noise ratio (SNR) and the corresponding need for excessive averaging to maintain high spectral precision. Moreover, the limited spatial resolution also hinders its application in mechanical imaging. Here, by scrutinizing the SNR model, we design a high-speed ISBS microscope through multi-parameter optimization including phase, reference power, and acquisition time. Leveraging this, with the further assistance of the Matrix Pencil method for data processing, three-dimensional mechanical images are mapped under multiple contrast mechanisms for a millimeter-scale polydimethylsiloxane pattern immersed in methanol, enabling the identification of these two transparent materials without any contact or labeling. Our experimental results demonstrate the capability to maintain high spectral precision and resolution at a sub-millisecond integration time for one pixel. With a two-order improvement in the speed and a tenfold improvement in the spatial resolution over the state-of-the-art systems, this method makes it possible for ISBS microscopes to sensitively investigate rapid mechanical changes in time and space.

Structured illumination microscopy (SIM) has been widely applied to investigate intricate biological dynamics due to its outstanding super-resolution imaging speed. Incorporating compressive sensing into SIM brings the possibility to further improve the super-resolution imaging speed. Nevertheless, the recovery of the super-resolution information from the compressed measurement remains challenging in experiments. Here, we report structured illumination microscopy with complementary encoding-based compressive imaging (CECI-SIM) to realize faster super-resolution imaging. Compared to the nine measurements to obtain a super-resolution image in a conventional SIM, CECI-SIM can achieve a super-resolution image by three measurements; therefore, a threefold improvement in the imaging speed can be achieved. This faster imaging ability in CECI-SIM is experimentally verified by observing tubulin and actin in mouse embryonic fibroblast cells. This work provides a feasible solution for high-speed super-resolution imaging, which would bring significant applications in biomedical research.

Polarization holography has been extensively applied in many fields, such as optical science, metrology, and biochemistry, due to its property of polarization modulation. However, the modulated polarization state of diffracted light corresponds strictly to that of incident light one by one. Here, a kind of tunable polarization holographic grating has been designed in terms of Jones matrices, and intensity-based polarization manipulation has been realized experimentally. The proposed tunable polarization holographic grating is recorded on an azobenzene liquid-crystalline film by a pair of coherent light beams with orthogonal polarization states and asymmetrically controlled intensities. It is found that the diffracted light can be actively manipulated from linearly to circularly polarized based on the light intensity of the recording holographic field when the polarization state of incident light keeps constant. Our work could enrich the field of light manipulation and holography.

We propose and numerically demonstrate a photonic computing primitive designed for integrated spiking neural networks (SNNs) based on add-drop ring microresonators (ADRMRs) and electrically reconfigurable phase-change material (PCM) photonic switches. In this neuromorphic system, the passive silicon-based ADRMR, equipped with a power-tunable auxiliary light, effectively demonstrates nonlinearity-induced dual neural dynamics encompassing spiking response and synaptic plasticity that can generate single-wavelength optical neural spikes with synaptic weight. By cascading these ADRMRs with different resonant wavelengths, weighted multiple-wavelength spikes can be feasibly output from the ADRMR-based hardware arrays when external wavelength-addressable optical pulses are injected; subsequently, the cumulative power of these weighted output spikes is utilized to ascertain the activation status of the reconfigurable PCM photonic switches. Moreover, the reconfigurable mechanism driving the interconversion of the PCMs between the resonant-bonded crystalline states and the covalent-bonded amorphous states is achieved through precise thermal modulation. Drawing from the thermal properties, an innovative thermodynamic leaky integrate-and-firing (TLIF) neuron system is proposed. With the TLIF neuron system as the fundamental unit, a fully connected SNN is constructed to complete a classic deep learning task: the recognition of handwritten digit patterns. The simulation results reveal that the exemplary SNN can effectively recognize 10 numbers directly in the optical domain by employing the surrogate gradient algorithm. The theoretical verification of our architecture paves a whole new path for integrated photonic SNNs, with the potential to advance the field of neuromorphic photonic systems and enable more efficient spiking information processing.

Expanding the optical communication band is one of the most effective methods of overcoming the nonlinear Shannon capacity limit of single fiber. In this study, GeSn resonance cavity enhanced (RCE) photodetectors (PDs) with an active layer Sn component of 9%–10.8% were designed and fabricated on an SOI substrate. The GeSn RCE PDs present a responsivity of 0.49 A/W at 2 μm and a 3-dB bandwidth of approximately 40 GHz at 2 μm. Consequently, Si-based 2 μm band optical communication with a transmission rate of 50 Gbps was demonstrated by using a GeSn RCE detector. This work demonstrates the considerable potential of the Si-based 2 μm band photonics in future high-speed and high-capacity optical communication.

We present a detailed theoretical and numerical analysis on the temporal-spectral-spatial evolution of a high-peak-power femtosecond laser pulse in two sets of systems: a pure lithium niobate (LN) plate and a periodically poled lithium niobate (PPLN) plate. We develop a modified unidimensional pulse propagation model that considers all the prominent linear and nonlinear processes and carried out the simulation process based on an improved split-step Fourier transformation method. We theoretically analyze the synergic action of the linear dispersion effect, the second-order nonlinearity (2nd-NL) second-harmonic generation (SHG) effect, and the third-order nonlinearity (3rd-NL) self-phase modulation (SPM) effect, and clarify the physical mechanism underlying the peculiar and diverse spectral broadening patterns previously reported in LN and PPLN thin plate experiments. Such analysis and discussion provides a deeper insight into the synergetic contribution of these linear and nonlinear effects brought about by the interaction of a femtosecond laser pulse with the LN nonlinear crystal and helps to draw a picture to fully understand these fruitful optical physical processes, phenomena, and laws.

2D materials are promising candidates as nonlinear optical components for on-chip devices due to their ultrathin structure. In general, their nonlinear optical responses are inherently weak due to the short interaction thickness with light. Recently, there has been great interest in using quasi-bound states in the continuum (q-BICs) of dielectric metasurfaces, which are able to achieve remarkable optical near-field enhancement for elevating the second harmonic generation (SHG) emission from 2D materials. However, most studies focus on the design of combining bulk dielectric metasurfaces with unpatterned 2D materials, which suffer considerable radiation loss and limit near-field enhancement by high-quality q-BIC resonances. Here, we investigate the dielectric metasurface evolution from bulk silicon to monolayer molybdenum disulfide (MoS2), and discover the critical role of meta-atom thickness design on enhancing near-field effects of two q-BIC modes. We further introduce the strong-coupling of the two q-BIC modes by oblique incidence manipulation, and enhance the localized optical field on monolayer MoS2 dramatically. In the ultraviolet and visible regions, the MoS2 SHG enhancement factor of our design is 105 times higher than that of conventional bulk metasurfaces, leading to an extremely high nonlinear conversion efficiency of 5.8%. Our research will provide an important theoretical guide for the design of high-performance nonlinear devices based on 2D materials.

In recent studies, visible light communication (VLC) has been predicted to be a prospective technique in the future 6G communication systems. To suit the trend of exponentially growing connectivity, researchers have intensively studied techniques that enable multiple access (MA) in VLC systems, such as the MIMO system based on LED devices to support potential applications in the Internet of Things (IoT) or edge computing in the next-generation access network. However, their transmission rate is limited due to the intrinsic bandwidth of LED. Unfortunately, the majority of visible light laser communication (VLLC) research with beyond 10 Gb/s data rates concentrates on point-to-point links, or using discrete photodetector (PD) devices instead of an integrated array PD. In this paper, we demonstrated an integrated PD array device fabricated with a Si-substrated GaN/InGaN multiple-quantum-well (MQW) structure, which has a 4×4 array of 50μm×50μm micro-PD units with a common cathode and anode. This single-integrated array successfully provides access for two different transmitters simultaneously in the experiment, implementing a 2×2 MIMO-VLLC link at 405 nm. The highest data rate achieved is 13.2 Gb/s, and the corresponding net data rate (NDR) achieved is 12.27 Gb/s after deducing the FEC overhead, using 2.2 GHz bandwidth and superposed PAM signals. Furthermore, we assess the Huffman-coded coding scheme, which brings a fine-grain adjustment in access capacity and enhances the overall data throughput when the user signal power varies drastically due to distance, weather, or other challenges in the channel condition. As far as we know, this is the first demonstration of multiple visible light laser source access based on a single integrated GaN/InGaN receiver module.

The generation of speckle patterns via random matrices, statistical definitions, or apertures may not always result in optimal outcomes. Issues such as correlation fluctuations in low ensemble numbers and diffraction in long-distance propagation can arise. Instead of improving results of specific applications, our solution is catching deep correlations of patterns with the framework, Speckle-Net, which is fundamental and universally applicable to various systems. We demonstrate this in computational ghost imaging (CGI) and structured illumination microscopy (SIM). In CGI with extremely low ensemble number, it customizes correlation width and minimizes correlation fluctuations in illuminating patterns to achieve higher-quality images. It also creates non-Rayleigh nondiffracting speckle patterns only through a phase mask modulation, which overcomes the power loss in the traditional ring-aperture method. Our approach provides new insights into the nontrivial speckle patterns and has great potential for a variety of applications including dynamic SIM, X-ray and photo-acoustic imaging, and disorder physics.

Controlling the dispersion characteristic of metasurfaces (or metalenses) along a broad bandwidth is of great importance to develop high-performance broadband metadevices. Different from traditional lenses that rely on the material refractive index along the light trajectory, metasurfaces or metalenses provide a new regime of dispersion control via a sub-wavelength metastructure, which is known as negative chromatic dispersion. However, broadband metalenses design with high-performance focusing especially with a reduced device dimension is a significant challenge in society. Here, we design, fabricate, and demonstrate a broadband high-performance diffractive-type plasmonic metalens based on a circular split-ring resonator metasurface with a relative working bandwidth of 28.6%. The metalens thickness is only 0.09λ0 (λ0 is at the central wavelength), which is much thinner than previous broadband all-dielectric metalenses. The full-wave simulation results show that both high transmissive efficiency above 80% (the maximum is even above 90%) and high average focusing efficiency above 45% (the maximum is 56%) are achieved within the entire working bandwidth of 9–12 GHz. Moreover, an average high numerical aperture of 0.7 (NA=0.7) of high-efficiency microwave metalens is obtained in the simulations. The broadband high-performance metalens is also fabricated and experimental measurements verify its much higher average focusing efficiency of 55% (the maximum is above 65% within the broad bandwidth) and a moderate high NA of 0.6. The proposed plasmonic metalens can facilitate the development of wavelength-dependent broadband diffractive devices and is also meaningful to further studies on arbitrary dispersion control in diffractive optics based on plasmonic metasurfaces.

Single-molecule localization microscopy (SMLM) enables three-dimensional (3D) investigation of nanoscale structures in biological samples, offering unique insights into their organization. However, traditional 3D super-resolution microscopy using high numerical aperture (NA) objectives is limited by imaging depth of field (DOF), restricting their practical application to relatively thin biological samples. Here, we developed a unified solution for thick sample super-resolution imaging using a deformable mirror (DM) which served for fast remote focusing, optimized point spread function (PSF) engineering, and accurate aberration correction. By effectively correcting the system aberrations introduced during remote focusing and sample aberrations at different imaging depths, we achieved high-accuracy, large DOF imaging (∼8μm) of the whole-cell organelles [i.e., nuclear pore complex (NPC), microtubules, and mitochondria] with a nearly uniform resolution of approximately 35 nm across the entire cellular volume.

We propose a near-eye display optics system that supports three-dimensional mutual occlusion. By exploiting the polarization-control properties of a phase-only liquid crystal on silicon (LCoS), we achieve real see-through scene masking as well as virtual digital scene imaging using a single LCoS. Dynamic depth control of the real scene mask and virtual digital image is also achieved by using a focus tunable lens (FTL) pair of opposite curvatures. The proposed configuration using a single LCoS and opposite curvature FTL pair enables the self-alignment of the mask and image at an arbitrary depth without distorting the see-through view of the real scene. We verified the feasibility of the proposed optics using two optical benchtop setups: one with two off-the-shelf FTLs for continuous depth control, and the other with a single Pancharatnam–Berry phase-type FTL for the improved form factor.

The room temperature strong coupling between the photonic modes of micro/nanocavities and quantum emitters (QEs) can bring about promising advantages for fundamental and applied physics. Improving the electric fields (EFs) by using plasmonic modes and reducing their losses by applying dielectric nanocavities are widely employed approaches to achieve room temperature strong coupling. However, ideal photonic modes with both large EFs and low loss have been lacking. Herein, we propose the abnormal anapole mode (AAM), showing both a strong EF enhancement of ∼70-fold (comparable to plasmonic modes) and a low loss of 34 meV, which is much smaller than previous records of isolated all-dielectric nanocavities. Besides realizing strong coupling, we further show that by replacing the normal anapole mode with the AAM, the lasing threshold of the AAM-coupled QEs can be reduced by one order of magnitude, implying a vital step toward on-chip integration of nanophotonic devices.

Liquid crystal (LC) photonic devices have attracted intensive attention in recent decades, due to the merits of tunability, cost-effectiveness, and high efficiency. However, the precise and efficient simulation of large-scale three-dimensional electrically stimulated LC photonic devices remains challenging and resource consuming. Here we report a straightforward nonuniform finite difference method (NFDM) for efficiently simulating large-scale LC photonic devices by employing a spatially nonuniform mesh grid. We show that the NFDM can be further accelerated by approximately 504 times by using the improved successive over-relaxation method (by 12 times), the symmetric boundary (by 4 times), the momentum gradient descent algorithm (by 3.5 times), and the multigrid (by 3 times). We experimentally fabricated the large-scale electrically stimulated LC photonic device, and the measured results demonstrate the effectiveness and validity of the proposed NFDM. The NFDM allocates more grids to the core area with steep electric field gradient, thus reducing the distortion of electric field and the truncation error of calculation, rendering it more precise than the finite element method and traditional finite difference method with similar computing resources. This study demonstrates an efficient and highly reliable method to simulate the large-scale electrically stimulated LC photonic device, and paves the way for customizing a large-scale LC photonic device with designable functionalities.
