Single-photon entanglement is a peculiar type of entanglement in which two or more degrees of freedom of a single photon are correlated quantum-mechanically. Here, we demonstrate a photonic integrated chip able to generate and manipulate single-photon path-entangled states, using a commercial red LED as light source. A Bell test, in the Clauser, Horne, Shimony, and Holt (CHSH) form, is performed to confirm the presence of entanglement, resulting in a maximum value of the CHSH correlation parameter equal to . This allows us to use it as an integrated semi-device independent quantum random number generator able to produce certified random numbers. The certification scheme is based on a Bell’s inequality violation and on a partial characterization of the experimental setup, without the need of introducing any further assumptions either on the input state or on the particular form of the measurement observables. In the end a min-entropy of 33% is demonstrated.
2023, 11(9): 1484
The quantum network makes use of quantum states to transmit data, which will revolutionize classical communication and allow for some breakthrough applications. Quantum key distribution (QKD) is one prominent application of quantum networks, and can protect data transmission through quantum mechanics. In this work, we propose an expandable and cost-effective quantum access network, in which the round-trip structure makes quantum states travel in a circle to carry information, and the multi-band technique is proposed to support multi-user access. Based on the round-trip multi-band quantum access network, we realize multi-user secure key sharing through the continuous-variable QKD (CV-QKD) protocol. Due to the encoding characteristics of CV-QKD, the quadrature components in different frequency bands can be used to transmit key information for different users. The feasibility of this scheme is confirmed by comprehensive noise analysis, and is verified by a proof-of-principle experiment. The results show that each user can achieve excess noise suppression and 600 bit/s level secure key generation under 30 km standard fiber transmission. Such networks have the ability of multi-user access theoretically and could be expanded by plugging in simple modules. Therefore, it paves the way for near-term large-scale quantum secure networks.
2023, 11(8): 1449
Integrated photonics provides a promising platform for quantum key distribution (QKD) system in terms of miniaturization, robustness, and scalability. Tremendous QKD works based on integrated photonics have been reported. Nonetheless, most current chip-based QKD implementations require additional off-chip hardware to demodulate quantum states or perform auxiliary tasks such as time synchronization and polarization basis tracking. Here, we report a demonstration of resource-efficient chip-based BB84 QKD with a silicon-based encoder and a decoder. In our scheme, the time synchronization and polarization compensation are implemented relying on the preparation and measurement of the quantum states generated by on-chip devices; thus, we need no additional hardware. The experimental tests show that our scheme is highly stable with a low intrinsic quantum bit error rate of in a 6 h continuous run. Furthermore, over a commercial fiber channel up to 150 km, the system enables the realization of secure key distribution at a rate of 866 bit/s. Our demonstration paves the way for a low-cost, wafer-scale manufactured QKD system.
2023, 11(8): 1364
The entanglement distribution network connects remote users by sharing entanglement resources, which is essential for realizing quantum internet. We propose a photonic-reconfigurable entanglement distribution network (PR-EDN) based on a silicon quantum photonic chip. The entanglement resources are generated by a quantum light source array based on spontaneous four-wave mixing in silicon waveguides and distributed to different users through time-reversed Hong–Ou–Mandel interference by on-chip Mach–Zehnder interferometers with thermo-optic phase shifters (TOPSs). A chip sample is designed and fabricated, supporting a PR-EDN with 3 subnets and 24 users. The network topology of the PR-EDN could be reconfigured in three network states by controlling the quantum interference through the TOPSs, which is demonstrated experimentally. Furthermore, a reconfigurable entanglement-based quantum key distribution network is realized as an application of the PR-EDN. The reconfigurable network topology makes the PR-EDN suitable for future quantum networks requiring complicated network control and management. Moreover, it is also shown that silicon quantum photonic chips have great potential for large-scale PR-EDN, thanks to their capacities for generating and manipulating plenty of entanglement resources.
2023, 11(7): 1314
We demonstrate integrated photonic circuits for quantum devices using sputtered polycrystalline aluminum nitride (AlN) on insulator. On-chip AlN waveguide directional couplers, which are one of the most important components in quantum photonics, are fabricated and show the output power splitting ratios from 50:50 to 99:1. Polarization beam splitters with an extinction ratio of more than 10 dB are also realized from the AlN directional couplers. Using the fabricated AlN waveguide beam splitters, we observe Hong–Ou–Mandel interference with a visibility of .
2023, 11(7): 1196
Mode-locked biphoton frequency combs exhibit multiple discrete comblike temporal correlations from the Fourier transform of its phase-coherent frequency spectrum. Both temporal correlation and Franson interferometry are valuable tools for analyzing the joint properties of biphoton frequency combs, and the latter has proven to be essential for testing the fundamental quantum nature, the time-energy entanglement distribution, and the large-alphabet quantum key distributions. However, the Franson recurrence interference visibility in biphoton frequency combs unavoidably experiences a falloff that deteriorates the quality of time-energy entanglement and channel capacity for longer cavity round trips. In this paper, we provide a new method to address this problem towards optimum Franson interference recurrence. We first observe mode-locked temporal oscillations in a 5.03 GHz free-spectral range singly filtered biphoton frequency comb using only commercial detectors. Then, we observe similar falloff trend of time-energy entanglement in 15.15 GHz and 5.03 GHz free-spectral range singly filtered biphoton frequency combs, whereas, the optimum central time-bin accidental-subtracted visibility over 97% for both cavities. Here, we find that by increasing the cavity finesse , we can enhance the detection probability in temporal correlations and towards optimum Franson interference recurrence in our singly filtered biphoton frequency combs. For the first time, via a higher cavity finesse of 45.92 with a 15.11 GHz free-spectral range singly filtered biphoton frequency comb, we present an experimental -fold improvement of the Franson visibility compared to the Franson visibility with a cavity finesse of 11.14 at the sixth time bin. Near optimum Franson interference recurrence and a time-bin Schmidt number near 16 effective modes in similar free-spectral range cavity are predicted with a finesse of 200. Our configuration is versatile and robust against changes in cavity parameters that can be designed for various quantum applications, such as high-dimensional time-energy entanglement distributions, high-dimensional quantum key distributions, and wavelength-multiplexed quantum networks.
2023, 11(7): 1175
Quantum conference (QC) is a cryptographic task in secure communications that involves more than two users wishing to establish identical secret keys among users. The Greenberger–Horne–Zeilinger (GHZ) entangled state is the basic resource for quantum cryptographic communication due to the existence of multipartite quantum correlations. An unconditional and efficient quantum network can be established with a continuous variable (CV) GHZ entangled state because of its deterministic entanglement. Here, we report an implementation of QC scheme using a CV multipartite GHZ entangled state. The submodes of a quadripartite GHZ entangled state are distributed to four spatially separated users. The proposed QC scheme is proved to be secure even when the entanglement is distributed through lossy quantum channels and the collective Gaussian attacks are in the all lossy channels. The presented QC scheme has the capability to be directly extended to a larger scale quantum network by using entangled states with more submodes.
2023, 11(4): 533
Integrated quantum key distribution (QKD) systems based on photonic chips have high scalability and stability, and are promising for further construction of global quantum communications networks. On-chip quantum light sources are a critical component of a fully integrated QKD system; especially a continuous-variable QKD (CV-QKD) system based on coherent detection, which has extremely high requirements for the light sources. Here, for what we believe is the first time, we designed and fabricated two on-chip tunable lasers for CV-QKD, and demonstrated a high-performance system based on these sources. Because of the high output power, fine tunability, and narrow linewidth, the involved on-chip lasers guarantee the accurate shot-noise-limited detection of quantum signals, center wavelength alignment of nonhomologous lasers, and suppression of untrusted excess noise. The system’s secret key rate can reach 0.75 Mb/s at a 50 km fiber distance, and the secure transmission distance can exceed 100 km. Our results mark a breakthrough toward building a fully integrated CV-QKD, and pave the way for a reliable and efficient terrestrial quantum-secure metropolitan area network.
2023, 11(4): 504
Locking the sophisticated and expensive entanglement sources at the shared relay node is a promising choice for building a star-type quantum network with efficient use of quantum resources, where the involved parties only need to equip low-cost and simple homodyne detectors. Here, to our best knowledge, we demonstrate the first experimental continuous variable quantum key distribution with an entanglement source between the two users. We consider a practical partially characterized entangled source and establish the security analysis model of the protocol under realistic conditions. By applying a biased base technology, the higher key rate than that of the original protocol is achieved. The experimental results demonstrate that the distance between two users can reach up to 60 km over telecom single-mode fiber, implying the feasibility for high-rate and secure communication with a shared entangled source at metropolitan distances.
2023, 11(3): 463
We demonstrate a chip-integrated semiconductor source that combines polarization and frequency entanglement, allowing the generation of entangled biphoton states in a hybrid degree of freedom without post-manipulation. Our AlGaAs device is based on type-II spontaneous parametric downconversion in a counterpropagating phase-matching scheme in which the modal birefringence lifts the degeneracy between the two possible nonlinear interactions. This allows the direct generation of polarization–frequency entangled photons at room temperature and telecom wavelength, and in two distinct spatial modes, offering enhanced flexibility for quantum information protocols. The state entanglement is quantified by a combined measurement of the joint spectrum and Hong–Ou–Mandel interference (raw visibility ) of the biphotons, allowing to reconstruct a restricted density matrix in the hybrid polarization–frequency space.
2023, 11(2): 270
