Jingxuan Chen 1,2†Mingjin Wang 1,3†Ting Fu 1,2Yufei Wang 1,4,6,*[ ... ]Wanhua Zheng 1,2,3,4,5,7,*
Author Affiliations
Abstract
1 Laboratory of Solid State Optoelectronics Information Technology, Institute of Semiconductors, Chinese Academy of Scienceshttps://ror.org/034t30j35, Beijing 100083, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
4 College of Future Technology, University of Chinese Academy of Sciences, Beijing 101408, China
5 Weifang Academy of Advanced Opto-Electronic Circuits, Weifang 261021, China
6 e-mail: yufeiwang@semi.ac.cn
7 e-mail: whzheng@semi.ac.cn
Zero-energy topological states, which are protected by chiral symmetry against certain perturbations topologically, localize at interfaces between trivial and non-trivial phases in the Su–Schrieffer–Heeger (SSH) chain model. Here, we propose and demonstrate a method to manipulate chiral symmetry itself to improve the localized interfaces and enlarge the mode volume of topological states in the SSH model, thus optimizing the lasing performance of localized interfaces. As multiple defects corresponding to off-diagonal perturbations in an eigenmatrix are introduced, the topological state expands and extends to extra defects at the topological interface without breaking chiral symmetry. We apply the proposed method in electrical pumping semiconductor laser arrays to verify our theoretical prediction and optimize the output characteristics of the devices. The measured results of the proposed multi-defect SSH laser array show that the output power has been increased by 27%, and the series resistance and far-field divergence have been reduced by half compared to the traditional SSH laser array, establishing a high-performance light source for integrated silicon photonics, infrared light detection and ranging, and so on. Our work demonstrates that the proposed method is capable of improving topological localized interfaces and redistributing zero-energy topological states. Furthermore, our method can be applied to other platforms and inspire optimizations of more devices in broader areas.
Photonics Research
2023, 11(9): 1517
Xin Qi 1Jiaju Wu 1,5,*Feng Wu 2Mina Ren 1[ ... ]Hong Chen 1
Author Affiliations
Abstract
1 MOE Key Laboratory of Advanced Micro-structured Materials, School of Physics Sciences and Engineering, Tongji Universityhttps://ror.org/03rc6as71, Shanghai 200092, China
2 School of Optoelectronic Engineering, Guangdong Polytechnic Normal University, Guangzhou 510665, China
3 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
4 Department of Electrical Engineering, Tongji University, Shanghai 201804, China
5 e-mail: wujiaju@tongji.edu.cn
6 e-mail: yufeiwang@semi.ac.cn
7 e-mail: yongsun@tongji.edu.cn
Optical resonators with high quality (Q) factors are paramount for the enhancement of light–matter interactions in engineered photonic structures, but their performance always suffers from the scattering loss caused by fabrication imperfections. Merging bound states in the continuum (BICs) provide us with a nontrivial physical mechanism to overcome this challenge, as they can significantly improve the Q factors of quasi-BICs. However, most of the reported merging BICs are found at Γ point (the center of the Brillouin zone), which intensively limits many potential applications based on angular selectivity. To date, studies on manipulating merging BICs at off-Γ point are always accompanied by the breaking of structural symmetry that inevitably increases process difficulty and structural defects to a certain extent. Here, we propose a scheme to construct merging BICs at almost an arbitrary point in momentum space without breaking symmetry. Enabled by the topological features of BICs, we merge four accidental BICs with one symmetry-protected BIC at the Γ point and merge two accidental BICs with opposite topological charges at the off-Γ point only by changing the periodic constant of a photonic crystal slab. Furthermore, the position of off-Γ merging BICs can be flexibly tuned by the periodic constant and height of the structure simultaneously. Interestingly, it is observed that the movement of BICs occurs in a quasi-flatband with ultra-narrow bandwidth. Therefore, merging BICs in a tiny band provide a mechanism to realize more robust ultrahigh-Q resonances that further improve the optical performance, which is limited by wide-angle illuminations. Finally, as an example of application, effective angle-insensitive second-harmonic generation assisted by different quasi-BICs is numerically demonstrated. Our findings demonstrate momentum-steerable merging BICs in a quasi-flatband, which may expand the application of BICs to the enhancement of frequency-sensitive light–matter interaction with angular selectivity.
Photonics Research
2023, 11(7): 1262
Jian Fan 1,2Xuyan Zhou 1,3,4,**Weiqiao Zhang 1,2Yufei Wang 1,2,5[ ... ]Wanhua Zheng 1,2,3,5,*
Author Affiliations
Abstract
1 Laboratory of Solid-State Optoelectronics Information Technology, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
4 Weifang Academy of Advanced Opto-Electronic Circuits, Weifang 261071, China
5 College of Future Technology, University of Chinese Academy of Sciences, Beijing 101408, China
We first study the effect of cavity modes propagating in the lateral dimension on high-power semiconductor lasers with a large stripe width. A sidewall microstructure was fabricated to prevent optical feedback of lateral resonant modes. Theoretically, we demonstrate the existence of lateral resonant modes in the Fabry–Perot cavity with a large stripe width. Experimentally, we design the corresponding devices and compare them with conventional broad-area diode lasers. About a 15% reduction in threshold current and a 27% increase in maximum electro-optical conversion efficiency are achieved. The amplified spontaneous emission spectrum is narrowed, which proves that lateral microstructures suppress optical feedback of lateral resonant modes. Under a large continuous-wave operation, the maximum output power of laser device is 43.03 W, about 1 W higher than that of the standard broad-area laser at 48 A.
high power broad area laser resonant mode amplified spontaneous emission
Chinese Optics Letters
2023, 21(4): 041406
Author Affiliations
Abstract
1 MOE Key Laboratory of Advanced Micro-structured Materials, School of Physics Sciences and Engineering, Tongji Universityhttps://ror.org/03rc6as71, Shanghai 200092, China
2 School of Space Science and Physics, Shandong University, Weihai 264209, China
3 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
4 Department of Electrical Engineering, Tongji University, Shanghai 201804, China
5 e-mail: yufeiwang@semi.ac.cn
6 e-mail: jiang-haitao@tongji.edu.cn
7 e-mail: dgqql@sdu.edu.cn
8 e-mail: yongsun@tongji.edu.cn
Recently, the concepts of parity–time (PT) symmetry and band topology have inspired many novel ideas for light manipulation in their respective directions. Here we propose and demonstrate a perfect light absorber with a PT phase transition via coupled topological interface states (TISs), which combines the two concepts in a one-dimensional photonic crystal heterostructure. By fine tuning the coupling between TISs, the PT phase transition is revealed by the evolution of absorption spectra in both ideal and non-ideal PT symmetry cases. Especially, in the ideal case, a perfect light absorber at an exceptional point with unidirectional invisibility is numerically obtained. In the non-ideal case, a perfect light absorber in a broken phase is experimentally realized, which verifies the possibility of tailoring non-Hermiticity by engineering the coupling. Our work paves the way for novel effects and functional devices from the exceptional point of coupled TISs, such as a unidirectional light absorber and exceptional-point sensor.
Photonics Research
2023, 11(4): 517
Tiancai Wang 1,2Peng Cao 1,2Hongling Peng 1,3,*Chuanwang Xu 1,2[ ... ]Wanhua Zheng 1,3,5,6,**
Author Affiliations
Abstract
1 Laboratory of Solid-State Optoelectronics Information Technology, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 College of Electronic and Communication Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
4 Southwest Institute of Technology Physics, Chengdu 610041, China
5 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
6 Weifang Academy of Advanced Opto-electronic Circuits, Weifang 261021, China
In this paper, high-uniformity 2×64 silicon avalanche photodiode (APD) arrays are reported. Silicon multiple epitaxy technology was used, and the high performance APD arrays based on double-layer epiwafers are achieved for the first time, to the best of our knowledge. A high-uniformity breakdown voltage with a fluctuation of smaller than 3.5 V is obtained for the fabricated APD arrays. The dark currents are below 90 pA for all 128 pixels at unity gain voltage. The pixels in the APD arrays show a gain factor of larger than 300 and a peak responsivity of 0.53 A/W@M = 1 at 850 nm (corresponding to maximum external quantum efficiency of 81%) at room temperature. Quick optical pulse response time was measured, and a corresponding cutoff frequency up to 100 MHz was obtained.
avalanche photodiode arrays silicon multiple epitaxy technology dark current
Chinese Optics Letters
2023, 21(3): 032501
Jing Liu 1,2,*Mingjin Wang 1Yufei Wang 1,2,3,4Xuyan Zhou 1[ ... ]Wanhua Zheng 1,2,3,4,5,**
Author Affiliations
Abstract
1 Laboratory of Solid-State Optoelectronics Information Technology, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
4 College of Future Technology, University of Chinese Academy of Sciences, Beijing 101408, China
5 School of Electronic, Electrical and Communication Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
A high peak power density and low mechanical stress photonic-band-crystal (PBC) diode laser array based on non-soldered packaging technology is demonstrated. The array consists of the PBC diode laser bars with small fast axis divergence angles. Meanwhile, we design the non-soldered array structure that realizes mechanical stacking of 10 bars in the vertical direction. In the experiment, the peak power density of the PBC array is about 1.75 times that of the conventional array when the same total power is obtained. The peak power of the non-soldered array is 292.2 W, and the “smile” effect is improved by adjusting the mechanical fixing force of the array.
photonic-band-crystal non-soldered packaging low mechanical stress
Chinese Optics Letters
2022, 20(7): 071403
Xiaoxu Xing 1,2Xuyan Zhou 1,3,*Hongwei Qu 1,4Weiqiao Zhang 1,2[ ... ]Wanhua Zheng 1,3,4,6,**
Author Affiliations
Abstract
1 Laboratory of Solid-State Optoelectronics Information Technology, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 College of Materials Science and Optoelectronic Technology, University of Chinese Academy of Sciences, Beijing 100049, China
3 Weifang Academy of Advanced Optoelectronic Circuits, Weifang 261021, China
4 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
5 School of Electronic, Electrical and Communication Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
6 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
We studied the spectral beam combining (SBC) of a large optical cavity (LOC) laser array to achieve high-power and high-brightness laser output. We discussed the characteristics of the external cavity feedback efficiency and the focal length of the transform lens for lasers with different waveguide thicknesses. We have found that using LOC laser diodes can increase the proportion of external cavity feedback, thereby improving the SBC efficiency. At a current of 90 A, the CW output power of the SBC system is 59.2 W, and the SBC efficiency reaches up to 102.8%. All emitters of the laser array have achieved spectral locking with a spectral width of 11.67 nm, and the beam parameter product is 4.38 mm·mrad.
spectral beam combining large optical cavity high efficiency
Chinese Optics Letters
2022, 20(6): 061402
Author Affiliations
Abstract
1 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 Key Laboratory of Solid-State Optoelectronics Information Technology, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
4 Bimberg Chinese-German Center for Green Photonics, Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China
5 Institute of Solid State Physics and Center of Nanophotonics, Technische Universität Berlin, 10623 Berlin, Germany
We experimentally demonstrate for the first time to our knowledge electrically injected vertical-cavity surface-emitting lasers (VCSELs) with post-supported high-contrast gratings (HCGs) at 940 nm. The HCG-VCSELs have two posts to support the air-suspended HCGs, which are realized by simple fabrication without critical point drying. The HCG-VCSEL achieves a threshold current of about 0.65 mA and a side-mode suppression ratio of 43.6 dB under continuous-wave operation at 25°C. Theoretically the HCG-VCSEL with a λ/2-cavity for the transverse magnetic polarization has a smaller effective mode length of 1.38·(λ/n). Thus, the relaxation resonance frequency can be increased by 16% compared with that of the conventional VCSEL. The modulation speed of 100 Gbit/s for the HCG-VCSEL is expected in the on–off keying modulation format. Our easy design of HCG-VCSELs has great potential for applications in optical interconnects, sensing, illumination, and so on.
Photonics Research
2022, 10(5): 05001170
Yufei Jia 1,2Yufei Wang 1,3Xuyan Zhou 1Linhai Xu 1,2[ ... ]Wanhua Zheng 1,2,3,4,*
Author Affiliations
Abstract
1 Laboratory of Solid State Optoelectronics Information Technology, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 College of Future Technology, University of Chinese Academy of Sciences, Beijing 101408, China
4 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
We design a 645 nm laser diode (LD) with a narrow vertical beam divergence angle based on the mode expansion layer. The vertical beam divergence of 10.94° at full width at half-maximum is realized under 1.5 A continuous-wave operation, which is the smallest vertical beam divergence for such an LD based on the mode expansion layer, to the best of our knowledge. The threshold current and output power are 1.07 A and 0.94 W, limited by the thermal rollover for the 100 µm wide and 1500 µm long broad area laser, and the slope efficiency is 0.71 W/A. The low coherence device is fabricated with the speckle contrast of 3.6% and good directional emission. Such 645 nm LDs have promising applications in laser display.
beam divergence laser diode speckle laser display
Chinese Optics Letters
2021, 19(10): 101401
傅廷 1,3王宇飞 1,2王学友 1,3陈静瑄 1,3[ ... ]郑婉华 1,2,3,4,*
作者单位
摘要
1 中国科学院半导体研究所固态光电信息技术重点实验室, 北京 100083
2 中国科学院大学未来技术学院, 北京 101408
3 中国科学院大学材料科学与光电工程研究中心, 北京 100049
4 中国科学院半导体研究所集成光电子学国家重点实验室, 北京 100083

激光器是一种高亮度、高效率和高相干性的功率转换器件,特别是在半导体激光器系统中,不仅存在折射率的高低分布,而且还同时存在增益和损耗分布,是一个天然的非厄米光学系统。通过引入微结构调控激光器的折射率和增益损耗分布,可以在基于半导体激光芯片的光学平台上实现宇称时间对称、超对称等物理效应,并实现对激光器的空间光场和频域光谱的调控,从而获得高性能的新型微结构激光器。其中,宇称时间对称有望改善激光器的光谱、近场和远场分布,而超对称有望实现单侧模大功率输出。本文主要从这些物理效应的基本原理出发,综述了基于宇称时间对称和超对称的激光器的相关工作,探讨了新型微结构激光器的可能发展方向。

激光器 非厄米光子学 宇称时间对称 超对称 lasers non-Hermitian photonics parity-time symmetry supersymmetry
中国激光
2021, 48(12): 1201005
