Employing couplers to convert guided waves into free-space modes and flexibly control their wavefront is one of the key technologies in chip-integrated displays and communications. Traditional couplers are mainly composed of gratings, which have limitations in footprint, bandwidth, as well as controllability. Though the resonant/geometric metasurface newly emerges as a promising interface for bridging guided waves with free-space ones, it either relies on complex optimizations of multiple parameters, or is subject to the locked phase response of opposite spins, both of which hinder the functional diversity and practical multiplexing capability. Here, we propose and experimentally demonstrate an alternative with a spin-decoupled meta-coupler, simultaneously integrating triple functions of guided wave radiation, polarization demultiplexing, and dual-channel wavefront manipulation into a single device. By endowing polarization-dependent functionalities into a pure geometric metasurface, the out-coupled left-handed and right-handed circular polarization guided waves intelligently identify the predesigned phase modulation and reconstruct desired wavefronts, like bifocal focusing and holography multiplexing, with a polarization extinction ratio over 13.4 dB in experiments. We envision that the robust, broadband, and multifunctional meta-coupler could pave a way for the development of versatile multiplexed waveguide-based devices.
2023, 11(12): 2194
We propose and experimentally demonstrate a high quality (Q)-factor all-silicon bound state in the continuum (BIC) metasurface with an imperforated air-hole array. The metasurface supports two polarization-insensitive BICs originated from guided mode resonances (GMRs) in the frequency range of 0.4 to 0.6 THz, and the measured Q-factors of the two GMRs are as high as 334 and 152, respectively. In addition, the influence of the thickness of the silicon substrate on the two resonances is analyzed in detail. The proposed all-silicon THz metasurface has great potential in the design and application of high-Q metasurfaces.bound state in the continuum all-silicon metasurface high-quality factor terahertz
Chinese Optics Letters
2023, 21(11): 113601
Optical metasurfaces are two-dimensional ultrathin devices based on single-layer or multilayer arrays of subwavelength nanostructures. They can achieve precise control of phase, amplitude, and polarization on the subwavelength scale. In this paper, a substrate-free all-silicon coded grating is designed, which can realize the phase control of the outgoing beam after the -polarized plane wave is vertically incident on the metasurface at 0.1 THz. Through a single-layer silicon nanoarray structure, a low-reflection anomalous transmission metasurface is realized, and a variety of different beam deflectors are designed based on these encoded gratings. We propose a coded grating addition principle, which adds and subtracts two traditional coded grating sequences to obtain a new coded grating sequence. The encoded supergrating can flexibly control the scattering angle, and the designed substrate-free all-silicon encoded grating can achieve a deflection angle of 48.59°. In order to verify the principle of coded grating addition, we experimented with cascade operation of two coded sequence gratings to obtain the flexible control of the terahertz beam of the composite supergrating. The principle of grating addition provides a new degree of freedom for the flexible regulation of the terahertz wavefront. At the same time, this method can be extended to the optical band or microwave band, opening up new ways for electromagnetic wave manipulation and beam scanning.
2023, 11(10): 1738
High-Q metasurfaces have important applications in high-sensitivity sensing, low-threshold lasers, and nonlinear optics due to the strong local electromagnetic field enhancements. Although ultra-high-Q resonances of bound states in the continuum (BIC) metasurfaces have been rapidly developed in the optical regime, it is still a challenging task in the terahertz band for long years because of absorption loss of dielectric materials, design, and fabrication of nanostructures, and the need for high-signal-to-noise ratio and high-resolution spectral measurements. Here, a polarization-insensitive quasi-BIC resonance with a high-Q factor of 1049 in a terahertz all-silicon metasurface is experimentally achieved, exceeding the current highest record by 3 times of magnitude. And by using this ultra-high-Q metasurface, a terahertz intensity modulation with very low optical pump power is demonstrated. The proposed all-silicon metasurface can pave the way for the research and development of high-Q terahertz metasurfaces.
2022, 10(12): 2743
为了研究基于连续谱束缚态(BIC)高品质因子Q谐振, 提出了由双空心硅圆柱体组成太赫兹全介质超表面。采用数值模拟方法对结构的透射光谱及电磁场图进行了分析, 并利用本征模分析的方法研究了超表面结构参数对BIC频率的影响, 给出了该BIC超表面在太赫兹大频率范围工作的参数设计方法。结果表明, 在3.0THz左右实现了一个可调高Q环偶极Fano谐振; 本征模式的分析计算结果与入射电磁波模式的分析计算结果对称性不匹配,该超表面支持的是一个对称保护BIC。此研究为基于BIC的高Q超材料在超低阈值激光器件、非线性光学谐波产生及高灵敏度传感等领域的应用提供了理论参考。光学器件 连续谱束缚态 多极子分析 全介质超表面 高Q谐振 太赫兹 optical devices bound state in the continuum multipole analysis all-dielectric metasurface high-Q resonance terahertz
The interaction between magnetic quantum emitters and the local electromagnetic environment is a promising method to manipulate the spontaneous emission. However, it is severely limited by the weak interactions between the magnetic component of light and natural materials. Herein, we demonstrate that the special type of anapole states associated with the “onefold” electric toroidal dipole moment can be excited by efficient interaction between magnetic dipole emitters and silver oligomers. Based on magnetic anapole states, the radiative power is effectively suppressed with significant coupling between the emitter and the silver nonamer, physically providing an ideal playground for the study of non-radiative transitions. These findings not only introduce magnetic anapoles to plasmonics but also open a door for the development of new high-performance magnetic-dipole-based optoelectronic devices.
2022, 10(9): 2032
Anapole metamaterials have attracted growing attention in recent years due to their unique nonradiating and nontrivial properties. Although anapole modes have been demonstrated in metamaterials with three-dimensional structures, the design and realization of planar anapole metamaterials in a wide frequency range is still a big challenge. Here we propose and experimentally demonstrate a planar anapole metamaterial consisting of dumbbell-shaped apertures on a stainless-steel sheet at terahertz frequencies. The planar metamaterial can generate a resonant transparency in the terahertz spectrum due to the excitation of the anapole mode. Particularly, the frequency of anapole-induced resonant transparency can be tuned easily in the range of 0.15–0.93 THz by simply varying one geometric parameter of the dumbbell apertures. We anticipate that the resonant transparency in planar anapole metamaterials can be potentially used in filters, sensors, or other photonic devices.
2021, 9(2): 02000125
