Author Affiliations
Abstract
Key Laboratory of Light Field Manipulation and Information Acquisition, Ministry of Industry and Information Technology, and Shaanxi Key Laboratory of Optical Information Technology, School of Physical Science and Technology, Northwestern Polytechnical University, Xi’an 710129, China
The conversion-efficiency for second-harmonic (SH) in optical fibers is significantly limited by extremely weak second-order nonlinearity of fused silica, and pulse pump lasers with high peak power are widely employed. Here, we propose a simple strategy to efficiently realize the broadband and continuous wave (CW) pumped SH, by transferring a crystalline GaSe coating onto a microfiber with phase-matching diameter. In the experiment, high efficiency up to 0.08 %W-1mm-1 is reached for a C-band pump laser. The high enough efficiency not only guarantees SH at a single frequency pumped by a CW laser, but also multi-frequencies mixing supported by three CW light sources. Moreover, broadband SH spectrum is also achieved under the pump of a superluminescent light-emitting diode source with a 79.3 nm bandwidth. The proposed scheme provides a beneficial method to the enhancement of various nonlinear parameter processes, development of quasi-monochromatic or broadband CW light sources at new wavelength regions.
nonlinear optics second-harmonic generation continuous wave pump high efficiency multi-frequencies mixing broad spectra microfibers gallium selenide
Opto-Electronic Advances
2023, 6(9): 230012
Author Affiliations
Abstract
1 State Key Laboratory of Optoelectronic Materials and Technologies, School of Physics, Sun Yat-sen University, Guangzhou 510275, China
2 State Key Laboratory for Mesoscopic Physics and Frontiers Science Center for Nano-optoelectronics, School of Physics, Peking University, Beijing 100871, China
Microcavities constructed from materials with a second-order nonlinear coefficient have enabled efficient second-harmonic (SH) generation at a low power level. However, it is still technically challenging to realize double resonance with large nonlinear modal overlap in a microcavity. Here, we propose a design for a robust, tunable, and easy coupling double-resonance SH generation based on the combination of a newly developed fiber-based Fabry–Perot microcavity and a sandwich structure, whose numerical SH conversion efficiency is up to 3000% W-1. This proposal provides a feasible way to construct ultra-efficient nonlinear devices for generation of classical and quantum light sources.
microcavity double resonance second-harmonic generation
Chinese Optics Letters
2023, 21(11): 111901
徐思志 1夏瀛 1高瑜博 1,2刘星 1,2,*[ ... ]阮双琛 1,2,*
作者单位
摘要
1 深圳技术大学 先进光学精密制造技术广东普通高校重点实验室,深圳 518118
2 深圳技术大学 中德智能制造学院,深圳 518118
3 大族激光科技产业集团股份有限公司,深圳 518103
4 深圳大学 物理与光电工程学院 深圳市激光工程重点实验室,深圳 518060
采用多级串联的主振荡放大技术,将SESAM锁模的种子光通过多级串联端泵Nd∶YVO4晶体放大,产生平均功率为148.7 W、重复频率500 kHz~4 MHz、脉冲宽度8 ps的1 064 nm基频光,同时开展了LBO晶体高效率二倍频的研究。通过优化相位匹配,实现了平均功率为95 W的532 nm皮秒激光输出,光-光转换效率达65%,光束质量因子MX2=1.27/MY2=1.42,6 h功率抖动均方根低于0.8%。该绿光皮秒激光系统具有平均功率高、转换效率高、光束质量好、稳定性高、重频可调等优点,可以被作为皮秒激光加工系统的光源,被应用于科学研究和工业加工领域。
绿光皮秒 皮秒激光器 二次谐波产生 固体放大器 LBO晶体 Picosecond green laser Picosecond laser Second-harmonic generation Solid-state laser amplifier LBO crystal
光子学报
2023, 52(9): 0914002
Author Affiliations
Abstract
1 Key Laboratory of OptoElectronic Science and Technology for Medicine of Ministry of Education, Fujian Provincial Key Laboratory for Photonics Technology, Fujian Normal University, Fuzhou 350007, P. R. China
2 Department of Pathology, Fujian Medical University Union Hospital, Fuzhou 350001, P. R. China
3 Department of Colorectal Surgery, The First Affiliated Hospital of Fujian Medical University, Fuzhou 350001, P. R. China
4 Department of Gastric Surgery, Fujian Medical University Union Hospital, Fuzhou 350001, P. R. China
Gastrointestinal stromal tumors (GISTs) are the most common mesenchymal tumors arising in the digest tract. It brings a challenge to diagnosis because it is asymptomatic clinically. It is well known that tumor development is often accompanied by the changes in the morphology of collagen fibers. Nowadays, an emerging optical imaging technique, second-harmonic generation (SHG), can directly identify collagen fibers without staining due to its noncentrosymmetric properties. Therefore, in this study, we attempt to assess the feasibility of SHG imaging for detecting GISTs by monitoring the morphological changes of collagen fibers in tumor microenvironment. We found that collagen alterations occurred obviously in the GISTs by comparing with normal tissues, and furthermore, two morphological features from SHG images were extracted to quantitatively assess the morphological difference of collagen fibers between normal muscular layer and GISTs by means of automated image analysis. Quantitative analyses show a significant difference in the two collagen features. This study demonstrates the potential of SHG imaging as an adjunctive diagnostic tool for label-free identification of GISTs.
Multiphoton imaging two-photon excited fluorescence second-harmonic generation gastrointestinal stromal tumors
Journal of Innovative Optical Health Sciences
2023, 16(5): 2350007
作者单位
摘要
1 中国科学院物理研究所,北京 100190
2 清华大学物理系,北京 100084
使用强场太赫兹泵浦二次谐波产生探测、研究外尔半金属TaAs中的三阶非线性响应过程。当泵浦太赫兹电场沿着TaAs(112)晶面的不同晶向时,强场太赫兹诱导的光学二次谐波信号展现出了不同的响应,这可以用泵浦太赫兹电场引入的三阶非线性极化来定量地解释,其中较大的zzzz分量可能起着重要的作用。
非线性光学 强场太赫兹 二次谐波产生 外尔半金属 nonlinear optics intense electric field terahertz second harmonic generation Weyl semimetal
中国激光
2023, 50(17): 1714016
Author Affiliations
Abstract
1 Ultrafast Laser Laboratory, Key Laboratory of Opto-electronic Information Science and Technology of Ministry of Education, School of Precision Instruments and Opto-electronics Engineering, Tianjin University, Tianjin 300072, China
2 Science and Technology on Electro-Optical Information Security Control Laboratory, Tianjin 300308, China
As a newly discovered type of structured light, a spatiotemporal optical vortex (STOV), which is remarkable for its space–time spiral phase and transverse orbital angular momentum (OAM), has garnered substantial interest. Most previous studies have focused on the generation, characterization, and propagation of STOVs, but their nonlinear frequency conversion remains largely unexplored. Here, we experimentally demonstrate the generation of green and ultraviolet (UV) STOVs by frequency upconversion of a STOV carried near-infrared (NIR) pulse emitted by a high repetition rate Yb-doped fiber laser amplifier system. First, we verify that the topological charge of spatiotemporal OAM (ST-OAM) is doubled along with the optical frequency in the second-harmonic generation (SHG) process, which is visualized by the diffraction patterns of the STOVs in the fundamental and second-harmonic field. Second, the space–time characteristic of NIR STOV is successfully mapped to UV STOV by sum-frequency mixing STOV at 1037 nm and Gaussian beams in the green band. Furthermore, we observe the topological charges of the ST-OAM could be degraded owing to strong space–time coupling and complex spatiotemporal astigmatism of such beams. Our results not only deepen our understanding of nonlinear manipulation of ST-OAM spectra and the generation of STOVs at a new shorter wavelength, but also may promote new applications in both classical and quantum optics.
ultraviolet spatiotemporal optical vortex second-harmonic generation sum-frequency generation
Chinese Optics Letters
2023, 21(8): 080004
王楠楠 1,2,3高玉峰 3郑炜 3李慧 3,**林展翼 1,2,*
作者单位
摘要
1 华南理工大学医学院,广东 广州 510006
2 南方医科大学附属广东省人民医院(广东省医学科学院),广东 广州 510080
3 中国科学院深圳先进技术研究院生物医学光学与分子影像研究中心,广东 深圳 518055
衰老是引起主动脉硬化进而引发各种心血管疾病的主要独立风险因素。对主动脉增龄性改变进行定量评估有望为心血管疾病研究提供重要线索。采用二次谐波成像技术,结合三维灰度共生矩阵纹理分析算法,对不同周龄大鼠主动脉血管壁内外表面的胶原纤维进行了定量评估;提取出多种可量化表征主动脉增龄性改变的特征参数,从胶原纤维微结构角度揭示了主动脉增龄性变化规律。上述方法及提取出的特征参数有望为评估血管老化程度提供有力工具和重要参考指标,并进一步应用于与老化相关的心血管疾病的研究。
医用光学 二次谐波成像 三维灰度共生矩阵 主动脉 增龄性改变 胶原纤维 medical optics second harmonic generation microscopy three-dimensional gray level co-occurrence matrix aorta aging-related changes collagen fibers
中国激光
2023, 50(15): 1507102
Author Affiliations
Abstract
1 College of Physics and Optoelectronic Engineering, Key Laboratory of Optoelectronic Devices and Systems of Ministry of Education and Guangdong Province, Shenzhen University, Shenzhen 518060, Guangdong, P. R. China
2 Department of Bioengineering and COMSET, Clemson University, Clemson, SC 29634 USA
Structured illumination microscopy (SIM) is suitable for biological samples because of its relatively low-peak illumination intensity requirement and high imaging speed. The system resolution is affected by two typical detection modes: Point detection and area detection. However, a systematic analysis of the imaging performance of the different detection modes of the system has rarely been conducted. In this study, we compared laser point scanning point detection (PS-PD) and point scanning area detection (PS-AD) imaging in nonconfocal microscopy through theoretical analysis and simulated imaging. The results revealed that the imaging resolutions of PS-PD and PS-AD depend on excitation and emission point spread functions (PSFs), respectively. Especially, we combined the second harmonic generation (SHG) of point detection (P-SHG) and area detection (A-SHG) with SIM to realize a nonlinear SIM-imaging technique that improves the imaging resolution. Moreover, we analytically and experimentally compared the nonlinear SIM performance of P-SHG with that of A-SHG.
Super-resolution structured illumination microscopy second harmonic generation
Journal of Innovative Optical Health Sciences
2023, 16(4): 2350010
尤崴 1,2,5杨学宗 2,3,4,5,*孙玉祥 2李牧野 2,5[ ... ]冯衍 1,2,5
作者单位
摘要
1 中国科学院上海光学精密机械研究所,上海 201800
2 中国科学院大学杭州高等研究院,杭州 310024
3 山东大学 晶体材料国家重点实验室,济南 250100
4 山西大学 量子光学与光量子器件国家重点实验室,太原 030006
5 中国科学院大学,北京 100049
面向天文观测等领域对高功率单频589 nm钠导星激光器的应用需求,通过金刚石拉曼谐振及腔内倍频技术结合1 018 nm掺镱光纤激光技术,实现了最高功率16.5 W的连续波单频589 nm钠导星激光器研制。建立外腔拉曼振荡及腔内倍频理论,详细分析谐振腔输出耦合率和倍频晶体相位匹配条件对输出激光功率的影响。激光光谱宽度为16 MHz,光束质量因子为1.05,光光转化效率为20%。
固体激光器 单纵模激光器 金刚石 钠导星激光器 二次谐波产生 Solid-state laser Single longitudinal mode laser Diamond Sodium guide star laser Second harmonic generation
光子学报
2023, 52(5): 0552202
作者单位
摘要
国防科技大学理学院, 湖南 长沙 410073
采用自行研制的776.9 nm半导体激光器作为种子源, 经过锥形半导体放大器并整形后得到2.3 W的基频光,再利用Ⅰ类相位匹配的三硼酸锂晶体和蝶形倍频腔产生了388.4 nm紫外连续激光。分析了锥形放大器中热透镜效应对光束质量的影响, 并通过透镜、柱面镜、棱镜对光束进行整形, 提高了倍频腔的输入耦合效率。进一步通过优化倍频腔的束腰尺寸和腔参数, 提高了紫外激光二次谐波的转换效率。最终2.3 W的基频光产生940 mW的紫外倍频光输出, 倍频效率达到41%。
非线性光学 紫外连续激光 二次谐波 热透镜效应 三硼酸锂晶体 nonlinear optics ultraviolet continuous-wave laser second harmonic generation thermal lens effect LiB3O5 crystal
量子电子学报
2023, 40(3): 392
