中国激光
2023, 50(17): 1714016

Author Affiliations
Abstract
1 Ultrafast Laser Laboratory, Key Laboratory of Opto-electronic Information Science and Technology of Ministry of Education, School of Precision Instruments and Opto-electronics Engineering, Tianjin University, Tianjin 300072, China
2 Science and Technology on Electro-Optical Information Security Control Laboratory, Tianjin 300308, China
As a newly discovered type of structured light, a spatiotemporal optical vortex (STOV), which is remarkable for its space–time spiral phase and transverse orbital angular momentum (OAM), has garnered substantial interest. Most previous studies have focused on the generation, characterization, and propagation of STOVs, but their nonlinear frequency conversion remains largely unexplored. Here, we experimentally demonstrate the generation of green and ultraviolet (UV) STOVs by frequency upconversion of a STOV carried near-infrared (NIR) pulse emitted by a high repetition rate Yb-doped fiber laser amplifier system. First, we verify that the topological charge of spatiotemporal OAM (ST-OAM) is doubled along with the optical frequency in the second-harmonic generation (SHG) process, which is visualized by the diffraction patterns of the STOVs in the fundamental and second-harmonic field. Second, the space–time characteristic of NIR STOV is successfully mapped to UV STOV by sum-frequency mixing STOV at 1037 nm and Gaussian beams in the green band. Furthermore, we observe the topological charges of the ST-OAM could be degraded owing to strong space–time coupling and complex spatiotemporal astigmatism of such beams. Our results not only deepen our understanding of nonlinear manipulation of ST-OAM spectra and the generation of STOVs at a new shorter wavelength, but also may promote new applications in both classical and quantum optics.
ultraviolet spatiotemporal optical vortex second-harmonic generation sum-frequency generation Chinese Optics Letters
2023, 21(8): 080004
中国激光
2023, 50(15): 1507102
Author Affiliations
Abstract
1 College of Physics and Optoelectronic Engineering, Key Laboratory of Optoelectronic Devices and Systems of Ministry of Education and Guangdong Province, Shenzhen University, Shenzhen 518060, Guangdong, P. R. China
2 Department of Bioengineering and COMSET, Clemson University, Clemson, SC 29634 USA
Structured illumination microscopy (SIM) is suitable for biological samples because of its relatively low-peak illumination intensity requirement and high imaging speed. The system resolution is affected by two typical detection modes: Point detection and area detection. However, a systematic analysis of the imaging performance of the different detection modes of the system has rarely been conducted. In this study, we compared laser point scanning point detection (PS-PD) and point scanning area detection (PS-AD) imaging in nonconfocal microscopy through theoretical analysis and simulated imaging. The results revealed that the imaging resolutions of PS-PD and PS-AD depend on excitation and emission point spread functions (PSFs), respectively. Especially, we combined the second harmonic generation (SHG) of point detection (P-SHG) and area detection (A-SHG) with SIM to realize a nonlinear SIM-imaging technique that improves the imaging resolution. Moreover, we analytically and experimentally compared the nonlinear SIM performance of P-SHG with that of A-SHG.
Super-resolution structured illumination microscopy second harmonic generation Journal of Innovative Optical Health Sciences
2023, 16(4): 2350010

Author Affiliations
Abstract
1 State Key Laboratory of Advanced Optical Communication Systems and Networks, School of Physics and Astronomy, Shanghai Jiao Tong University, Shanghai 200240, China
2 Shanghai Research Center for Quantum Sciences, Shanghai 201315, China
3 Collaborative Innovation Center of Light Manipulations and Applications, Shandong Normal University, Jinan 250358, China
The compact and reliable ultraviolet (UV) source has attracted remarkable attention for its potential use in optical measurement systems, high-density optical storage, and biomedical applications. We demonstrate ultraviolet generation by frequency doubling in a lithium-tantalate-on-insulator (LTOI) microdisk via modal phase matching. The 50-µm-diameter microdisk was milled by a focused ion beam (FIB) and followed by chemo-mechanical polishing (CMP) to smooth the disk surface and edge, and the Q-factor reaches in the visible band. On-chip UV coherent light with a wavelength of 384.3 nm was achieved, which shows great promise for using LTOIs in integrated ultraviolet source platforms.
lithium-tantalate thin film ultraviolet light second-harmonic generation Chinese Optics Letters
2023, 21(6): 061902

Author Affiliations
Abstract
1 Key Laboratory of Space Laser Communication and Detection Technology, Shanghai Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Shanghai 201800, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 Pilot National Laboratory for Marine Science and Technology, Qingdao 266237, China
A 222 nm all-solid-state far-ultraviolet C (UVC) pulse laser system based on an optical parametric oscillator (OPO) and second-harmonic generation (SHG) using (BBO) crystals was demonstrated. Pumped by a laser with a repetition rate of 100 Hz at 355 nm, the maximum signal laser pulse energy of 1.22 mJ at 444 nm wavelength was obtained from the BBO-OPO system, corresponding to a conversion efficiency of 27.9%. The maximum output pulse energy of 164.9 µJ at the 222 nm wavelength was successfully achieved, corresponding to an SHG conversion efficiency of 16.2%. Moreover, the tunable output wavelength of UVC light from 210 nm to 252.5 nm was achieved.
all-solid-state pulse laser UVC disinfection optical parametric oscillator second-harmonic generation Chinese Optics Letters
2023, 21(1): 011401
季华实验室 光电技术研究部,广东 佛山 528200
手性二维钙钛矿是一类具有非中心对称结构的低维钙钛矿材料,兼具低维钙钛矿和手性材料的优点,可用于产生非线性光学效应。通过高压技术可以实现低维钙钛矿各种光学性质的调控,然而目前对手性二维钙钛矿高压光学性质,特别是高压下非线性光学效应的研究则鲜有报道。利用金刚石对顶砧技术研究了高压对手性二维钙钛矿材料(R-, S-)ClPEA2PbI4的PL光谱、吸收光谱和二次谐波效应的影响。结果表明,随着压强的增大,材料的PL光谱强度先增大到1 GPa的峰值,随后逐渐减弱直至6 GPa左右消失,同时峰值波长507 nm红移到568 nm。高压吸收谱表明手性钙钛矿在6 GPa附近吸收边存在突变。高压下激光二次谐波信号强度随压强的增大而逐渐减小,在6 GPa附近明显减弱。这些结果表明高压是一种调控二维手性钙钛矿光学性质的有效手段,对其未来在发光和近红外频率转换等器件中的应用提供了基础。
高压 二次谐波生成 金刚石对顶砧 手性二维钙钛矿 high pressure second-harmonic generation diamond anvil cell chiral 2D perovskites 红外与激光工程
2022, 51(7): 20220211
合肥工业大学计算机与信息学院, 安徽 合肥 230601
人们借助等离激元结构, 可以在亚波长范围内获得、操控局域放大的光场。它与非线性光学结合, 衍生出非线性等离激元。等离激元二次谐波因其卓越特性, 近年在理论和应用方面均有较大突破。基于流体动力学模型介绍了等离激元结构二次谐波理论, 总结了其发展与应用的报道, 包括等离激元共振增强二次谐波效率、基于磁场洛伦兹力的二次谐波效应、对二次谐波辐射方向和频率的调控, 以及等离激元二次谐波在结构检测、传感、成像等领域的应用。最后, 对等离激元二次谐波研究领域可能的发展方向进行了展望。
非线性光学 等离激元 二次谐波 超材料 超表面 nonlinear optics plasmonics second-harmonic generation metamaterials metasurface
