2021, 9(4) Column

MORE

Photonics Research 第9卷 第4期

Author Affiliations
Abstract
1 College of Advanced Interdisciplinary Studies, National University of Defense Technology, Changsha 410073, China
2 e-mail: shandapengfei@126.com
3 e-mail: zhoupu203@163.com
In this work, we analyze the effects of the background spectral noise in phase-modulated single-frequency seed lasers on the spectral purity of high-power narrow-linewidth fiber amplifiers. Through demonstrating the spectral evolution of the phase-modulated single-frequency part and the background spectral noise in a narrow-linewidth fiber amplifier, the mechanism for the spectral wing broadening effect is clarified and design strategies to maintain high spectral purity are given. Specifically, the background spectral noise in phase-modulated single-frequency seed lasers could lead to obvious spectral wing broadening and degeneration of spectral purity in narrow-linewidth fiber amplifiers through the four-wave-mixing effect. Notably, the spectral wing broadening effect could be suppressed by filtering out the background spectral noise in the seed laser or applying a counter-pumped configuration in the fiber amplifier. We have also conducted contrast experiments, which have verified the validity of the theoretical model and the design strategies for high-spectral-purity operation.
Photonics Research
2021, 9(4): 04000424
Shengnan Zhang 1,2Yufeng Li 1,3,*Peng Hu 1,2Zhenhuan Tian 1,2[ ... ]Feng Yun 2,4,*
Author Affiliations
Abstract
1 Shaanxi Provincial Key Laboratory of Photonics & Information Technology, Xi’an Jiaotong University, Xi’an 710049, China
2 Solid-State Lighting Engineering Research Center, Xi’an Jiaotong University, Xi’an 710049, China
3 e-mail: yufengli@mail.xjtu.edu.cn
4 e-mail: fyun2010@mail.xjtu.edu.cn
Multimode and random directionalities are major issues restricting the application of whispering gallery mode microcavity lasers. We demonstrated a 40 μm diameter microring with an off-centered embedded hole and warped geometry from strained III-nitride quantum well multilayers. Single-mode directional whispering gallery mode lasing was achieved by the warped structure and high-order mode suppression induced by the off-centered hole. In addition, the introduction of the off-centered hole reduced the lasing threshold from 3.24 to 2.79 MW/cm2 compared with the warped microdisk without an embedded hole while maintaining a high-quality factor of more than 4000. Directional light emission in 3D was achieved and attributed to the warped structure, which provides a vertical component of the light emission, making it promising for building multifunctional coherent light sources in optoelectronic integration.
Photonics Research
2021, 9(4): 04000432
Author Affiliations
Abstract
1 Wang Da-Heng Collaborative Innovation Center, Heilongjiang Provincial Key Laboratory of Quantum Manipulation and Control, Harbin University of Science and Technology, Harbin 150080, China
2 Photonics and Mathematical Optics Group, Tecnologico de Monterrey, Monterrey 64849, Mexico
3 School of Physics, University of the Witwatersrand, Johannesburg 2050, South Africa
4 Centro de Investigaciones en Óptica, A.C., Loma del Bosque 115, Colonia Lomas del campestre, 37150 León, Gto., Mexico
5 e-mail: b.pegar@tec.mx
One of the most prominent features of quantum entanglement is its invariability under local unitary transformations, which implies that the degree of entanglement or nonseparability remains constant during free-space propagation, true for both quantum and classically entangled modes. Here we demonstrate an exception to this rule using a carefully engineered vectorial light field, and we study its nonseparability dynamics upon free-space propagation. We show that the local nonseparability between the spatial and polarization degrees of freedom dramatically decays to zero while preserving the purity of the state and hence the global nonseparability. We show this by numerical simulations and corroborate it experimentally. Our results evince novel properties of classically entangled modes and point to the need for new measures of nonseparability for such vectorial fields, while paving the way for novel applications for customized structured light.
Photonics Research
2021, 9(4): 04000439
Author Affiliations
Abstract
1 Department of Electronic Engineering, Xiamen University, Xiamen 361005, China
2 e-mail: buyikun0522@xmu.edu.cn
3 e-mail: zqluo@xmu.edu.cn
Yellow lasers (565590 nm) are of tremendous interest in biomedicine, astronomy, spectroscopy, and display technology. So far, yellow lasers still have relied heavily on nonlinear frequency conversion of near-infrared lasers, precluding compact and low-cost yellow laser systems. Here, we address the challenge through demonstrating, for the first time, to the best of our knowledge, watt-level high-power yellow laser generation directly from a compact fiber laser. The yellow fiber laser simply consists of a Dy3+-doped ZBLAN fiber as gain medium, a fiber end-facet mirror with high reflectivity at yellow and a 450-nm diode laser as the pump source. We comprehensively investigated the dependence of the yellow laser performance on the output coupler reflectivity and the gain fiber length and demonstrated that the yellow fiber laser with an output coupler reflectivity of 4% and a gain fiber length of 1.8 m yields a maximum efficiency of 33.6%. A maximum output power of 1.12 W at 575 nm was achieved at a pump power of 4.20 W. This work demonstrated the power scaling of yellow Dy3+-doped ZBLAN fiber lasers, showing their promise for applications in ophthalmology, astronomical exploration, and high-resolution spectroscopy.
Photonics Research
2021, 9(4): 04000446
Author Affiliations
Abstract
1 Shaanxi Provincial Key Laboratory of Photonics & Information Technology, Xi’an Jiaotong University, Xi’an 710049, China
2 Solid-State Lighting Engineering Research Center, Xi’an Jiaotong University, Xi’an 710049, China
3 Department of Mechanical and Aerospace Engineering, The Hong Kong University of Science and Technology, Clear Water Bay, Kowloon, Hong Kong, China
4 HKUST LED-FPD Technology R&D Center at Foshan, Foshan 528200, China
Modulation bandwidth and the emission region are essential features for the widespread use of visible light communications (VLC). This paper addresses the contradictory requirements to achieve broadband and proposes ultrafast, asymmetric pyramids grown on adjacent deep concave holes via lateral overgrowth. Multicolor emission with an emission region between 420 nm and 600 nm is obtained by controlling the growth rate at different positions on the same face, which also can provide multiple subcarrier frequency points for the employment of wavelength division multiplexing technology. The spontaneous emission rate distinction is narrowed by lowering the number of the crystal plane, ensuring a high modulation bandwidth over broadband. More importantly, the residual stress and dislocation density were minimized by employing a patterned substrate, and lateral overgrowth resulted in a further enhancement of the recombination rate. Finally, the total modulation bandwidth of multiple subcarriers of the asymmetric pyramids is beyond GHz. These ultrafast, multicolor microLEDs are viable for application in VLC systems and may also enable applications for intelligent lighting and display.
Photonics Research
2021, 9(4): 04000452
Xinyu Chen 1†Wei Ding 2,4,*†Ying-Ying Wang 2,3Shou-Fei Gao 2[ ... ]Lijian Zhang 1,6,*
Author Affiliations
Abstract
1 National Laboratory of Solid State Microstructures, College of Engineering and Applied Sciences, Collaborative Innovation Center of Advanced Microstructures, Nanjing University, Nanjing 210093, China
2 Institute of Photonics Technology, Jinan University, Guangzhou 510632, China
3 Institute of Laser Engineering, Beijing University of Technology, Beijing 100124, China
4 e-mail: photonicsweiding@163.com
5 e-mail: yqlu@nju.edu.cn
6 e-mail: lijian.zhang@nju.edu.cn
Hollow-core fiber (HCF) promises to unify air-borne light propagation and non-line-of-sight transmission, thus holding great potential for versatile photonics-based quantum information applications. The early version of HCF based on photonic-bandgap guidance has not proven itself a reliable quantum channel because of the poor modal purity in both spatial and polarization domains, as well as significant difficulty in fabrication when the wavelength shifts to the visible region. In this work, based on the polarization degree of freedom, we demonstrate high-fidelity (0.98) single-photon transmission and distribution of entangled photons over a 36.4 m hollow-core conjoined-tube fiber (CTF) by using commercial silicon single-photon avalanche photodiodes. Our CTF realizes the combined merits of low loss, high spatial modal purity, low polarization degradation, and low chromatic dispersion. We also demonstrate single-photon low-latency (99.96% speed of light in vacuum) transmission, paving the way for extensive uses of HCF links in versatile photonics-based quantum information processing.
Photonics Research
2021, 9(4): 04000460
Author Affiliations
Abstract
1 Centre d’optique, photonique et laser (COPL), Université Laval, Québec City, Québec, Canada
2 Canada Research Center, Huawei Technologies Canada, Ottawa, Ontario, Canada
We experimentally demonstrate a silicon photonic modulator that can be loaded with a combination of lateral and interleaved p-n junctions to enhance its phase modulation. We use an asymmetric Bragg grating to introduce mode conversion in the active area, allowing the modulator to operate in reflection without introducing additional on-chip loss. With a compact footprint (phase shifter length of 290 μm), the modulator demonstrates a modulation speed up to 45 Gb/s with a bit error rate below the 7% forward-error-correction (FEC) threshold (up to 55 Gb/s with 20% FEC), and a low power consumption of 226 fJ/bit.
Photonics Research
2021, 9(4): 04000471
Junyu Qian 1,2†Pengfei Wang 1,2†Yujie Peng 1,*Yanyan Li 1[ ... ]Ruxin Li 1,4
Author Affiliations
Abstract
1 State Key Laboratory of High Field Laser Physics and CAS Center for Excellence in Ultra-intense Laser Science, Shanghai Institute of Optics and Fine Mechanics (SIOM), Chinese Academy of Sciences (CAS), Shanghai 201800, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 e-mail: lengyuxin@mail.siom.ac.cn
4 e-mail: ruxinli@mail.shcnc.ac.cn
The generation of high-peak-power, few-cycle mid-infrared (MIR) pulses using coherent beam combination and nonlinear pulse compression techniques simultaneously is demonstrated. The two pulses, with identical pulse energy of 2.8 mJ and pulse duration of 160 fs, are coherently combined at the input end of a krypton-filled hollow-core fiber (HCF), and then the bandwidth of the combined pulse is broadened to near an optical octave due to strong phase modulations, and the temporal width is compressed into a few-cycle regime. Finally, a 2.7 mJ, 22.9 fs, 20 Hz laser at 4 μm can be obtained, and the pulse peak power is greatly enhanced compared with that of conventional single-channel optical parametric chirped pulse-amplification systems. Furthermore, the peak power generated from this system has the prospect of further scaling up through use of more channels of coherent combination, which can pave a way to generate higher peak power ultra-intense MIR pulses for strong-field physics.
Photonics Research
2021, 9(4): 04000477
Author Affiliations
Abstract
1 Institute of Applied Physics and Computational Mathematics, Beijing 100088, China
2 Beijing Computational Science Research Center, Beijing 100193, China
3 Department of Physics, The Chinese University of Hong Kong, Shatin, Hong Kong SAR, China
4 e-mail: haiqing0@csrc.ac.cn
5 e-mail: zhang_wei@iapcm.ac.cn
Chiral optical responses of bilayer metasurfaces made of twisted metallic nanorods are investigated in detail with focus on the collective effect due to lattice resonance (LR). Using an analytical approach based on the coupled dipole method (supported by full wave simulation), we find optical chirality is dramatically increased by the coupling between localized surface plasmon resonances and LR. The collective effect results in significant chiral signal even for metasurfaces made of achiral unit cells. The interlayer coupling generally destroys the Wood’s anomaly and the associated transparency. While making use of Pancharatnam–Berry (PB) phase and propagation phase, one can modulate the optical activity effectively and achieve chirality-selective transparency induced by LR in a designed structure with a g-factor of absorption as high as 1.99 (close to the upper limit of 2). Our studies not only reveal a new mechanism of modulating chiral optical response by combination effects from PB phase, propagation phase, and LR, but also give a quantitative relationship between the geometry configuration and chiral optical properties, thus providing helpful guidance for device design.
Photonics Research
2021, 9(4): 04000484
Xiuli Li 1,2Linzhi Peng 1,2Zhi Liu 1,2,*Zhiqi Zhou 3[ ... ]Buwen Cheng 1,2,4
Author Affiliations
Abstract
1 State Key Laboratory on Integrated Optoelectronics, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 School of Information Science and Technology, ShanghaiTech University, Shanghai 201210, China
4 Beijing Academy of Quantum Information Sciences, Beijing 100193, China
We report the demonstration of a normal-incidence p-i-n germanium-tin (Ge0.951Sn0.049) photodetector on silicon-on-insulator substrate for 2 μm wavelength application. The DC and RF characteristics of the devices have been characterized. A dark current density under -1 V bias of approximately 125 mA/cm2 is achieved at room temperature, and the optical responsivity of 14 mA/W is realized for illumination wavelength of 2 μm under -1 V reverse bias. In addition, a 3 dB bandwidth (f3 dB) of around 30 GHz is achieved at -3 V, which is the highest reported value among all group III–V and group IV photodetectors working in the 2 μm wavelength range. This work illustrates that a GeSn photodetector has great prospects in 2 μm wavelength optical communication.
Photonics Research
2021, 9(4): 04000494
Author Affiliations
Abstract
1 MOE Key Laboratory of Material Physics and Chemistry under Extraordinary Conditions, and Shaanxi Key Laboratory of Optical Information Technology, School of Physical Science and Technology, Northwestern Polytechnical University, Xi’an 710129, China
2 Key Laboratory of Spectral Imaging Technology of Chinese Academy of Sciences, Xi’an 710119, China
3 State Key Laboratory for Mesoscopic Physics, Collaborative Innovation Centre of Quantum Matter, School of Physics, Peking University, Beijing 100871, China
4 Advanced Computing and Simulation Laboratory (AχL), Department of Electrical and Computer Systems Engineering, Monash University, Clayton, VIC 3800, Australia
5 e-mail: xuetaogan@nwpu.edu.cn
6 e-mail: fjxiao@nwpu.edu.cn
7 e-mail: jlzhao@nwpu.edu.cn
Plasmonic particle-on-film nanocavities, supporting gap modes with ultra-small volume, provide a great solution to boost light–matter interactions at the nanoscale. In this work, we report on the photoluminescence (PL) enhancement of monolayer MoS2 using high order modes of an Au nanosphere dimer-on-film nanocavity (DoFN). The high order plasmon modes, consisting of two bonding quadrupoles in the dimer and their images in the Au film, are revealed by combining the polarization-resolved scattering spectra with the numerical simulations. Further integrating the monolayer MoS2 into the DoFN, these high order modes are used to enhance PL intensity through simultaneously boosting the absorption and emission processes, producing a 1350-fold enhancement factor. It opens an avenue to enhance the light–matter interaction with high order plasmon modes and may find applications in future optoelectronics and nanophotonics devices.
Photonics Research
2021, 9(4): 04000501
Author Affiliations
Abstract
1 Department of Electrical and Electronic Engineering, Yonsei University, 03722 Seoul, Republic of Korea
2 Current address: Samsung Electronics, Hwasung, 18448 Gyeonggi-do, Republic of Korea
3 IHP, Im Technologiepark 25, 15236 Frankfurt (Oder), Germany
4 Technische Universität Berlin, Einsteinufer 25, 10587 Berlin, Germany
We demonstrate a silicon electronic–photonic integrated 25 Gb/s nonreturn-to-zero transmitter that includes driver circuits, depletion-type Si ring modulator, Ge photodetector, temperature sensor, on-chip heater, and temperature controller, all monolithically integrated on a 0.25 μm photonic BiCMOS technology platform. The integrated transmitter successfully provides stable and optimal 25 Gb/s modulation characteristics against external temperature fluctuation.
Photonics Research
2021, 9(4): 04000507
Author Affiliations
Abstract
1 Department of Physics, Changchun University of Science and Technology, Changchun 130022, China
2 e-mail: songxiaowei@cust.edu.cn
3 e-mail: linjingquan@cust.edu.cn
Ultrafast spatiotemporal control of a surface plasmon polariton (SPP) launch direction is a prerequisite for ultrafast information processing in plasmonic nanocircuit components such as ultrafast on–off of plasmonic switching and information recording. Here we realize for the first time, to the best of our knowledge, ultrafast spatiotemporal control of the preferential launch direction of an SPP at the nano-femtosecond scale via a plasmonic nano directional coupler. The spatiotemporal switching of the SPP field was revealed using time-resolved photoemission electron microscopy (TR-PEEM). Experimental results show that the extinction ratio of the SPP directional coupler can be substantially optimized by properly selecting the amplitude and time delay of the two incident light pulses in the experiment. More importantly, we demonstrate a solution for the launch direction of the SPP field, switched in a plasmonic nano directional coupler on the femtosecond timescale, by adjusting the instantaneous polarization state of the excitation light. The TR-PEEM images are supported by finite-difference time-domain (FDTD) simulations. We believe the results of this study can be used to develop high-speed, miniaturized signal processing systems.
Photonics Research
2021, 9(4): 04000514
Author Affiliations
Abstract
1 School of Precision Instrument and Opto-electronics Engineering, Tianjin Optical Fiber Sensing Engineering Center, Institute of Optical Fiber Sensing of Tianjin University, Key Laboratory of Opto-electronics Information Technology, Tianjin University, Tianjin 300072, China
2 School of Electrical and Electronic Engineering, Engineering Research Center of Optoelectronic Devices and Communication Technology, Ministry of Education, Tianjin Key Laboratory of Film Electronic and Communication Devices, Tianjin University of Technology, Tianjin 300384, China
3 e-mail: jiangjfjxu@tju.edu.cn
4 e-mail: shuangwang@tju.edu.cn
5 e-mail: tgliu@tju.edu.cn
Pressure-temperature cross-sensitivity and its accompanying temperature-related stability is a nerve-wracking obstruction for pressure sensor performance in a wide temperature range. To solve this problem, we propose a novel (to the best of our knowledge) all-silicon dual-cavity optical Fabry–Perot interferometer (FPI) pressure sensor. The all-silicon structure has high intrinsic reflectivity and is able to eliminate the influence of thermal-expansion-mismatch-induced stress and chemical-reaction-induced gas generation, and therefore, in essence, enhances measurement accuracy. From the experiment results, the pressure-temperature cross-sensitivity is reduced to be 5.96 Pa/°C, which presents the lowest pressure-temperature cross-sensitivity among the FPI pressure sensors with the capability of surviving high temperatures up to 700°C thereby opening the way for high-precision pressure monitoring in various harsh and remote environments.
Photonics Research
2021, 9(4): 04000521
Author Affiliations
Abstract
1 State Key Laboratory of Precision Measurement Technology and Instruments, Department of Precision Instruments, Tsinghua University, Beijing 100084, China
2 State Key Laboratory of Information Photonics and Optical Communications, School of Electronic Engineering, Beijing University of Posts and Telecommunications, Beijing 100876, China
3 e-mail: xsxiao@bupt.edu.cn
4 e-mail: cxyang@tsinghua.edu.cn
We report experimental observation of multimode Q-switching and spatiotemporal mode locking in a multimode fiber laser. A typical steady Q-switching state is achieved with a 1.88 μs pulse duration, a 70.14 kHz repetition rate, and a 215.8 mW output power, corresponding to the single pulse energy of 3.08 μJ. We find weak spatial filtering is essential to obtain stable Q-switched pulses, in contrast to the relatively stronger spatial filtering for spatiotemporal mode locking. Furthermore, a reversible transition process, as well as a critical bistable state, between multimode Q-switching and spatiotemporal mode locking, is achieved with specific spatial coupling and waveplates sets. We believe the results will not only contribute to understanding the complicated nonlinear dynamics in multimode, fiber-based platforms, but also benefit the development of promising high-pulse energy lasers.
Photonics Research
2021, 9(4): 04000530
Xi Wang 1†Weihong Shen 2†Wenxiang Li 1Yingjie Liu 1[ ... ]Ke Xu 1,4,*
Author Affiliations
Abstract
1 Department of Electronic & Information Engineering, Harbin Institute of Technology, Shenzhen 518055, China
2 State Key Laboratory of Advanced Optical Communication Systems and Networks, Shanghai Jiao Tong University, Shanghai 200240, China
3 e-mail: dujiangbing@sjtu.edu.cn
4 e-mail: kxu@hit.edu.cn
Recently, 2-μm wave band has gained increasing interest due to its potential application for next-generation optical communication. But the development of 2-μm optical communications is substantially hampered by the modulation speed due to the device bandwidth constraints. Thus, a high-speed modulator is highly demanded at 2 μm. Motivated by this prospect, we demonstrate a high-speed silicon Mach–Zehnder modulator for a 2-μm wave band. The device is configured as a single-ended push–pull structure with waveguide electrorefraction via the free carrier plasma effect. The modulator was fabricated via a multiproject wafer shuttle run at a commercial silicon photonic foundry. The modulation efficiency of a single arm is measured to be 1.6 V·cm. The high-speed characterization is also performed, and the modulation speed can reach 80 Gbit/s with 4-level pulse amplitude modulation (PAM-4) formats.
Photonics Research
2021, 9(4): 04000535
Yitong Wu 1,2,3Liangliang Ji 1,3,5,*Ruxin Li 1,3,4,6,*
Author Affiliations
Abstract
1 State Key Laboratory of High Field Laser Physics, Shanghai Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Shanghai 201800, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 CAS Center for Excellence in Ultra-intense Laser Science, Shanghai 201800, China
4 ShanghaiTech University, Shanghai 201210, China
5 e-mail: jill@siom.ac.cn
6 e-mail: ruxinli@mail.siom.ac.cn
The upper limit of the laser field strength in a perfect vacuum is usually considered as the Schwinger field, corresponding to 1029 W/cm2. We investigate such limitations under realistic nonideal vacuum conditions and find that intensity suppression appears starting from 1025 W/cm2, showing an upper threshold at 1026 W/cm2 level if the residual electron density in chamber surpasses 109 cm-3. This is because the presence of residual electrons triggers the avalanche of quantum electrodynamics cascade that creates copious electron and positron pairs. The leptons are further trapped within the driving laser field due to radiation reaction, which significantly depletes the laser energy. The relationship between the attainable intensity and the vacuity is given according to particle-in-cell simulations and theoretical analysis. These results answer a critical problem on the achievable light intensity based on present vacuum conditions and provide a guideline for future hundreds of petawatt class laser development.
Photonics Research
2021, 9(4): 04000541
Author Affiliations
Abstract
1 European Laboratory for Non-Linear Spectroscopy (LENS), Sesto Fiorentino, Italy
2 National Institute of Optics-CNR (CNR-INO), Sesto Fiorentino, Italy
3 Institute of Heritage Science-CNR (CNR-ISPC), Sesto Fiorentino, Italy
Visible light communication (VLC) is currently recognized as a relevant technology for a wealth of possible application scenarios. New classes of services can be designed in both outdoor and indoor environments, exploiting the directionality of the optical channel and the low attainable latencies. Such features allow VLC to offer both spatial localization of users and wireless communication by using widespread high-power LEDs as simultaneous illumination and information sources. In the indoor scenario, one of the most promising deployments is expected in museums, where digital data can be cast by the specific illumination system of each artwork and received by visitors placed nearby. This would enable a full set of services, aiming, e.g., at an immersive experience in the augmented reality approach or at real-time localization of visitors. In this work, we characterize for the first time the performance of a photodiode-based VLC system in a real museum environment, performing an extensive measurement campaign on several masterpieces (wall, canvas, and wood paintings) in the Basilica of Santa Maria Novella in Florence, Italy. In particular, we demonstrate the possibility of using indirect (diffused) illumination light to deliver specific information on each artwork to a visitor. We characterize the quality of such non-line-of-sight VLC links by performing packet error rate measurements as a function of angle and distance from the artwork, and we measure the effective field of view (FoV) of our receiving stage, as well as the influence of side displacements of the receiver on the transmission quality, demonstrating that diffusive VLC links can also be used for efficient localization of users in front of each artwork in museum applications. With observed baud rates up to 28 kbaud and FoV values up to 60° for realistic distances up to 6 m, we believe our work could pave the way for future studies involving VLC in a wealth of indoor applications, beyond the cultural heritage sector.
Photonics Research
2021, 9(4): 04000548
Author Affiliations
Abstract
1 Beijing National Research Center for Information Science and Technology (BNRist), Beijing 100084, China
2 Department of Electronic Engineering, Tsinghua University, Beijing 100084, China
We demonstrate a hybrid laser with a low intrinsic linewidth of 34.2 Hz and a high fiber-coupled output power of 11.7 dBm, by coupling a Si3N4-based subwavelength hole defect assisted microring reflector (SHDA-MRR) to a commercially available distributed feedback semiconductor laser. The proposed SHDA-MRR structure features an accurately controlled reflection response, with the manipulated modal coupling between two degenerate counterpropagating modes induced by a subwavelength hole defect embedded in the microring waveguide. With further joint optimization of cavity parameters, this Si3N4 SHDA-MRR structure is expected to reduce the laser intrinsic linewidth to a sub-hertz level. This work explores a low-cost and robust linewidth reduction scheme for the applications of high-speed coherent optical communications systems and high-resolution optical metrology.
Photonics Research
2021, 9(4): 04000558
Jie Li 1†Chenglong Zheng 1†Guocui Wang 2,3Jitao Li 1[ ... ]Jianquan Yao 1,6,*
Author Affiliations
Abstract
1 Key Laboratory of Opto-Electronics Information Technology (Tianjin University), Ministry of Education, School of Precision Instruments and Opto-Electronics Engineering, Tianjin University, Tianjin 300072, China
2 Beijing Key Laboratory for Metamaterials and Devices, Key Laboratory of Terahertz Optoelectronics, Ministry of Education, and Beijing Advanced Innovation Center for Imaging Technology, Department of Physics, Capital Normal University, Beijing 100048, China
3 Beijing Engineering Research Center for Mixed Reality and Advanced Display, School of Optics and Photonics, Beijing Institute of Technology, Beijing 100081, China
4 School of Mechanical Engineering, Jiangsu University, Zhenjiang 225009, China
5 e-mail: yating@tju.edu.cn
6 e-mail: jqyao@tju.edu.cn
Chiral metasurfaces based on asymmetric meta-atoms have achieved artificial circular dichroism (CD), spin-dependent wavefront control, near-field imaging, and other spin-related electromagnetic control. In this paper, we propose and experimentally verify a scheme for achieving high-efficiency chiral response similar to CD of terahertz (THz) wave via phase manipulation. By introducing the geometric phase and dynamic phase in an all-silicon metasurface, the spin-decoupled terahertz transmission is obtained. The giant circular dichroism-like effect in the transmission spectrum is observed by using a random phase distribution for one of the circular polarization components. More importantly, the effect can be adjusted when we change the area of the metasurface illuminated by an incident terahertz beam. In addition, we also demonstrate the spin-dependent arbitrary wavefront control of the transmitted terahertz wave, in which one of the circularly polarized components is scattered, while the other forms a focused vortex beam. Simulated and experimental results show that this method provides a new idea for spin selective control of THz waves.
Photonics Research
2021, 9(4): 04000567
Author Affiliations
Abstract
1 MOE Key Laboratory of Advanced Micro-structured Materials, School of Physics Sciences and Engineering, Tongji University, Shanghai 200092, China
2 e-mail: 2014guozhiwei@tongji.edu.cn
3 e-mail: hongchen@tongji.edu.cn
Photonic topological edge states in one-dimensional dimer chains have long been thought to be robust to structural perturbations by mapping the topological Su–Schrieffer–Heeger model of a solid-state system. However, the edge states at the two ends of a finite topological dimer chain will interact as a result of near-field coupling. This leads to deviation from topological protection by the chiral symmetry from the exact zero energy, weakening the robustness of the topological edge state. With the aid of non-Hermitian physics, the splitting frequencies of edge states can be degenerated again, with topological protection recovered by altering the gain or loss strength of the structure. This point of coalescence is known as the exceptional point (EP). The intriguing physical properties of EPs in topological structures give rise to many fascinating and counterintuitive phenomena. In this work, based on a finite non-Hermitian dimer chain composed of ultra-subwavelength resonators, we propose theoretically and verify experimentally that the sensitivity of topological edge states is greatly affected when the system passes through the EP. Using the EP of a non-Hermitian dimer chain, we realize a new sensor that is sensitive to perturbation of on-site frequency at the end of the structure and yet topologically protected from internal perturbation of site-to-site couplings. Our demonstration of a non-Hermitian topological structure with an EP paves the way for the development of novel sensors that are not sensitive to internal manufacturing errors but are highly sensitive to changes in the external environment.
Photonics Research
2021, 9(4): 04000574
Chong Zhang 1,2Jingpei Hu 1,2,4,*Yangeng Dong 1,2Aijun Zeng 1,2,5,*[ ... ]Chinhua Wang 3
Author Affiliations
Abstract
1 Laboratory of Information Optics and Optoelectronic Technology, Shanghai Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Shanghai 201800, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 Key Laboratory of Advanced Optical Manufacturing Technologies of Jiangsu Province and Key Laboratory of Modern Optical Technologies of Ministry of Education, Soochow University, Suzhou 215006, China
4 e-mail: hujingpei@siom.ac.cn
5 e-mail: aijunzeng@siom.ac.cn
Pixelated metasurfaces integrating both the functions of linear polarization and circular polarization filters on a single platform can achieve full-Stokes polarization detection. At present, the pixelated full-Stokes metasurfaces mainly face the following problems: low transmission, low circular dichroism (CD) of circular polarization filters, and high requirements in fabrication and integration. Herein, we propose high performance ultracompact all-dielectric pixelated full-Stokes metasurfaces in the near-infrared band based on silicon-on-insulator, which is compatible with the available semiconductor industry technologies. Circular polarization filters with high CD are achieved by using simple two-dimensional chiral structures, which can be easily integrated with the linear polarization filters on a single chip. In addition, the dielectric materials have higher transmission than metal materials with intrinsic absorption. We experimentally demonstrated the circular polarization filter with maximum CD up to 70% at a wavelength of 1.6 μm and average transmission efficiency above 80% from 1.48 μm to 1.6 μm. Therefore, our design is highly desirable for many applications, such as target detection, clinical diagnosis, and polarimetric imaging and sensing.
Photonics Research
2021, 9(4): 04000583
Author Affiliations
Abstract
School of Electrical and Electronic Engineering, Nanyang Technological University, Singapore 639798, Singapore
We demonstrate the generation of wavelength-tunable deep-ultraviolet pulses in a small-mode-area hollow-core fiber fabricated by tapering a nodeless tubular-type hollow-core fiber. Down-scaling of the cross-sectional geometry reduces the pump energy requirement for inducing sufficient nonlinear effects, presenting a unique opportunity for staging low-energy-threshold gas-based nonlinear optics. We report the onset of the ultraviolet light with the pump pulse energy as low as 125 nJ. Our numerical analysis shows that the frequency conversion arises due to soliton phase matching, and therefore shot-to-shot coherence of the ultraviolet emission is well-preserved. It offers a promising platform for a compact ultraviolet frequency comb source.
Photonics Research
2021, 9(4): 04000590
Author Affiliations
Abstract
1 Photonics Devices and Systems Group, Singapore University of Technology and Design, 8 Somapah Road, Singapore 487372, Singapore
2 Current address: Photonic Systems Laboratory (PHOSL), Ecole Polytechnique Fédérale de Lausanne, STI-IEL, Station 11, CH-1015 Lausanne, Switzerland
3 Institute of Microelectronics, A*STAR, 2 Fusionopolis Way, #08-02, Innovis Tower, Singapore 138634, Singapore
4 Institute of Photonics and Optical Science, School of Physics, The University of Sydney, Sydney, New South Wales 2006, Australia
5 The University of Sydney Nano Institute (Sydney Nano), The University of Sydney, Sydney, New South Wales 2006, Australia
Spectral tunability methods used in optical communications and signal processing leveraging optical, electrical, and acousto-optic effects typically involve spectral truncation that results in energy loss. Here we demonstrate temperature tunable spectral broadening using a nonlinear ultra-silicon-rich nitride device consisting of a 3-mm-long cladding-modulated Bragg grating and a 7-mm-long nonlinear channel waveguide. By operating at frequencies close to the grating band edge, in an apodized Bragg grating, we access strong grating-induced dispersion while maintaining low losses and high transmissivity. We further exploit the redshift in the Bragg grating stopband due to the thermo-optic effect to achieve tunable dispersion, leading to varying degrees of soliton-effect compression and self-phase-modulation-induced spectral broadening. We observe an increase in the bandwidth of the output pulse spectrum from 69 to 106 nm as temperature decreases from 70°C to 25°C, in good agreement with simulated results using the generalized nonlinear Schrödinger equation. The demonstrated approach provides a new avenue to achieve on-chip laser spectral tuning without loss in pulse energy.
Photonics Research
2021, 9(4): 04000596
Author Affiliations
Abstract
Wuhan National Laboratory for Optoelectronics & School of Optical and Electronic Information, Huazhong University of Science and Technology, Wuhan 430074, China
A high-speed germanium (Ge) waveguide photodiode (PD) is one of the key components of an integrated silicon photonics platform for large-capacity data communication applications, but the parasitic parameters limit the increase of its bandwidth. Several studies have been reported to reduce parasitic parameters, at the cost of compromising other performances. Here, we propose and investigate a bandwidth-boosting technique by comprehensively engineering the parasitic parameters. Experimentally, a bandwidth up to 80 GHz is realized for vertical positive-intrinsic-negative (PIN) Ge PDs without decreasing the responsivity and dark current, indicating that parasitic parameter engineering is a promising method to promote high-speed performance of Ge PDs.
Photonics Research
2021, 9(4): 04000605
Author Affiliations
Abstract
1 The Key Laboratory of Weak-Light Nonlinear Photonics, Ministry of Education, School of Physics and TEDA Applied Physics Institute, Nankai University, Tianjin 300071, China
2 Collaborative Innovation Center of Extreme Optics, Shanxi University, Taiyuan 030006, China
3 e-mail: jjxu@nankai.edu.cn
Spatial light modulators (SLMs) are devices for modulating amplitude, phase, or polarization of light beams on demand. Such devices are regarded as the backbone for optical information parallel processing and future optical computers. Currently, SLMs are mainly operated in an electrical addressing manner, wherein the optical beams are modulated by electrical signals. However, future all-optical information processing systems prefer to control light directly by light (i.e., optically addressed, OA) without electro-optical conversion. Here, we present an OASLM based on a metasurface (MS-OASLM), whose operation principle relies on nonlinear polarization control of read light by another write light at the nanoscale. Its resolution is more than 10 times higher than a typical commercial SLM and achieves 500 line pairs per millimeter (corresponding to a pixel size of only 1 μm). The MS-OASLM shows unprecedented compactness and is only 400 nm in thickness. Such MS-OASLMs could provide opportunities to develop next generation all-optical information processing and high resolution display technologies.
Photonics Research
2021, 9(4): 04000610
Author Affiliations
Abstract
School of Electrical Engineering and Computer Science, Oregon State University, Corvallis, Oregon 97331, USA
A novel characterization method is proposed to extract the optical frequency field-effect mobility (μop,FE) of transparent conductive oxide (TCO) materials by a tunable silicon microring resonator with a heterogeneously integrated titanium-doped indium oxide (ITiO)/SiO2/silicon metal–oxide–semiconductor (MOS) capacitor. By operating the microring in the accumulation mode, the quality factor and resonance wavelength shift are measured and subsequently used to derive the μop,FE in the ultra-thin accumulation layer. Experimental results demonstrate that the μop,FE of ITiO increases from 25.3 to 38.4 cm2?V-1?s-1 with increasing gate voltages, which shows a similar trend as that at the electric frequency.
Photonics Research
2021, 9(4): 04000615
Author Affiliations
Abstract
1 Engineering Research Center of Advanced Lighting Technology, Fudan University, Ministry of Education, Shanghai 200433, China
2 Department of Illuminating Engineering and Light Sources, School of Information Science and Engineering, Fudan University, Shanghai 200433, China
3 Institute of Future Lighting, Academy for Engineering and Technology, Fudan University, Shanghai 200433, China
The physical origin of the fractal topological band-gap structure in the one-dimensional Thue–Morse system has been revealed, which is characterized by the evolutions of two types of topological singularities with zero-scattering properties and the paths of phase vortex points, which are the mirrored paths of the first-type singularities. The field distribution of the upper and lower gap-edge states will interchange when the traditional gaps are closed and reopened. The topologically protected edge-states are found at both traditional gaps and fractal gaps. Our work broadens the topological properties of quasicrystals or aperiodic systems and provides potential applications in new optoelectronic devices.
Photonics Research
2021, 9(4): 04000622
Author Affiliations
Abstract
1 Max Planck Institute for the Science of Light, 91058 Erlangen, Germany
2 Université de Rennes I, Sciences Chimiques de Rennes, 35042 Rennes, France
3 Friedrich-Alexander-Universität, 91058 Erlangen, Germany
4 e-mail: jiapeng.huang@mpl.mpg.de
5 e-mail: shangran.xie@mpl.mpg.de
Broadband mid-infrared (IR) supercontinuum laser sources are essential for spectroscopy in the molecular fingerprint region. Here, we report generation of octave-spanning and coherent mid-IR supercontinua in As2S3-silica nanospike hybrid waveguides pumped by a custom-built 2.8 μm femtosecond fiber laser. The waveguides are formed by pressure-assisted melt-filling of molten As2S3 into silica capillaries, allowing the dispersion and nonlinearity to be precisely tailored. Continuous coherent spectra spanning from 1.1 μm to 4.8 μm (30 dB level) are observed when the waveguide is designed so that 2.8 μm lies in the anomalous dispersion regime. Moreover, linearly tapered millimeter-scale As2S3-silica waveguides are fabricated and investigated for the first time, to the best of our knowledge, showing much broader supercontinua than uniform waveguides, with improved spectral coherence. The waveguides are demonstrated to be long-term stable and water-resistant due to the shielding of the As2S3 by the fused silica sheath. They offer an alternative route to generating broadband mid-IR supercontinua, with applications in frequency metrology and molecular spectroscopy, especially in humid and aqueous environments.
Photonics Research
2021, 9(4): 04000630
Author Affiliations
Abstract
1 Heilongjiang Provincial Key Laboratory of Quantum Control, School of Science, Harbin University of Science and Technology, Harbin 150080, China
2 National and Local Joint Engineering Research Center of Fiber Optic Sensing Technology, College of Electronic Engineering, Heilongjiang University, Harbin 150080, China
Brillouin spectroscopy is an important topic and powerful tool in modern optics, as the acquisitions of acoustic velocities and elastic moduli are one of the keys to investigate and analyze the contents of material science and condensed matter physics. Although stimulated Brillouin spectroscopy based on the pump-probe technique has striking advantages that include higher spectral resolution and signal-to-noise ratio, it is challenging to accomplish high-speed acquisition in the presence of pump background noise. In this paper, we propose a method for signal–noise separation through spiral phase precoding of the Brillouin spectrum signal. We achieve on-demand tailoring spatial distribution of the signal, and hence the signal can be separated from the background noise. Furthermore, this approach has little energy loss due to phase-only modulation, and retains the advantages of high efficiency and high gain in Brillouin interaction. The proof-of-principle demonstration provides a practical way to reshape the spatial structure of Brillouin spectra, and shows the potential in quasi-noise-free nonlinear interactions.
Photonics Research
2021, 9(4): 04000637
Author Affiliations
Abstract
1 Institute for Advanced Study, Shenzhen University, Shenzhen 518060, China
2 Intelligent Internet of Things and Intelligent Manufacturing Center, College of Electronics and Information Engineering, Shenzhen University, Shenzhen 518060, China
3 Faculty of Sciences, University of Maroua, Maroua, Cameroon
4 Univ. Lille, CNRS, UMR 8523—PhLAM—Physique des Lasers Atomes et Molecules, F-59000 Lille, France
We discover single and homocentric optical spheres of the three-dimensional inhomogeneous nonlinear Schr?dinger equation (NLSE) with spherical symmetry, which is a novel model of light bullets that can present a three-dimensional rogue wave. The isosurface of this light bullet oscillates along the radius direction and does not travel with the evolution of time. The localized nature of rogue wave light bullets both in space and in time, which is in complete contrast to the traveling character of the usual light bullets, is due to the localization of the rogue wave in the one-dimensional NLSE. We present also an investigation of the stability of the optical sphere solutions. The lower modes of perturbation are found to display transverse instabilities that break the spherical symmetry of the system. For the higher modes, the optical sphere solutions can be classified as stable solutions.
Photonics Research
2021, 9(4): 04000643
Author Affiliations
Abstract
1 Shaanxi Province Key Laboratory of Quantum Information and Quantum Optoelectronic Devices, School of Physics, Xi’an Jiaotong University, Xi’an 710049, China
2 School of Mechanical Engineering and Automation, Fuzhou University, Fuzhou 350108, China
3 e-mail: huangf@fzu.edu.cn

Orbital angular momentum (OAM)-carrying beams have received extensive attention due to their high-dimensional characteristics in the context of free-space optical communication. However, accurate OAM mode recognition still suffers from reference misalignment of lateral displacement, beam waist size, and initial phase. Here we propose a deep-learning method to exquisitely recognize OAM modes under misalignment by using an alignment-free fractal multipoint interferometer. Our experiments achieve 98.35% recognizing accuracy when strong misalignment is added to hyperfine OAM modes whose Bures distance is 0.01. The maximum lateral displacement we added with respect to the perfectly on-axis beam is about ±0.5 beam waist size. This work offers a superstable proposal for OAM mode recognition in the application of free-space optical communication and allows an increase of the communication capacity.

Photonics Research
2021, 9(4): 04000B81
Author Affiliations
Abstract
1 Department of Information and Communication Systems Engineering, University of the Aegean, Palama 2, Karlovassi 83200 Samos, Greece
2 Department of Informatics and Computer Engineering, University of West Attica, Aghiou Spiridonos, 12243 Egaleo, Athens, Greece
3 e-mail: gsarantoglou@aegean.gr

In this work, we present experimental results concerning excitability in a multiband emitting quantum-dot-based photonic neuron. The experimental investigation revealed that the same two-section quantum dot laser can be tuned through a simple bias adjustment to operate either as a leaky integrate and fire or as a resonate and fire neuron. Furthermore, by exploiting the inherent multiband emission of quantum-dot devices revealed by the existence of multiple lasing thresholds, a significant enhancement in the neurocomputational capabilities, such as spiking duration and firing rate, is observed. Spike firing rate increased by an order of magnitude that leads to an enhancement in processing speed and, more importantly, neural spike duration was suppressed to the picosecond scale, which corresponds to a significant temporal resolution enhancement. These new regimes of operation, when combined with thermal insensitivity, silicon cointegration capability, and the fact that these multiband mechanisms are also present in miniaturized quantum-dot devices, render these neuromorphic nodes a proliferating platform for large-scale photonic spiking neural networks.

Photonics Research
2021, 9(4): 04000B87
Author Affiliations
Abstract
Advanced Semiconductor Laboratory, King Abdullah University of Science and Technology (KAUST), Thuwal 23955-6900, Saudi Arabia

We demonstrate a neural network capable of designing on-demand multiple symmetry-protected bound states in the continuum (BICs) in freeform structures with predefined symmetry. The latent representation of the freeform structures allows the tuning of the geometry in a differentiable, continuous way. We show the rich band inversion and accidental degeneracy in these freeform structures by interacting with the latent representation directly. Moreover, a high design accuracy is demonstrated for arbitrary control of multiple BIC frequencies by using a photonic property readout network to interpret the latent representation.

Photonics Research
2021, 9(4): 04000B96
Author Affiliations
Abstract
1 Department of Electrical and Systems Engineering, Washington University, St Louis, Missouri 63130, USA
2 Department of Electrical and Computer Engineering, University of Wisconsin, Madison, Wisconsin 53706, USA
3 Key Laboratory for Organic Electronics & Information Displays (KLOEID), Institute of Advanced Materials (IAM), and School of Materials Science and Engineering, Nanjing University of Posts & Telecommunications, Nanjing 210046, China

The connection between Maxwell’s equations and artificial neural networks has revolutionized the capability and efficiency of nanophotonic design. Such a machine learning tool can help designers avoid iterative, time-consuming electromagnetic simulations and even allows long-desired inverse design. However, when we move from conventional design methods to machine-learning-based tools, there is a steep learning curve that is not as user-friendly as commercial simulation software. Here, we introduce a real-time, web-based design tool that uses a trained deep neural network (DNN) for accurate far-field radiation prediction, which shows great potential and convenience for antenna and metasurface designs. We believe our approach provides a user-friendly, readily accessible deep learning design tool, with significantly reduced difficulty and greatly enhanced efficiency. The web-based tool paves the way to present complicated machine learning results in an intuitive way. It also can be extended to other nanophotonic designs based on DNNs and replace conventional full-wave simulations with a much simpler interface.

Photonics Research
2021, 9(4): 0400B104
Author Affiliations
Abstract
1 Institute for Photonics and Advanced Sensing and School of Physical Sciences, The University of Adelaide, Adelaide, SA 5005, Australia
2 Australian Institute for Machine Learning, The University of Adelaide, Adelaide, SA 5005, Australia
3 Australian Research Council Centre of Excellence for Nanoscale BioPhotonics, The University of Adelaide, SA 5005, Australia
4 Future Industries Institute, University of South Australia, Mawson Lakes, SA 5095, Australia

A new approach to optical fiber sensing is proposed and demonstrated that allows for specific measurement even in the presence of strong noise from undesired environmental perturbations. A deep neural network model is trained to statistically learn the relation of the complex optical interference output from a multimode optical fiber (MMF) with respect to a measurand of interest while discriminating the noise. This technique negates the need to carefully shield against, or compensate for, undesired perturbations, as is often the case for traditional optical fiber sensors. This is achieved entirely in software without any fiber postprocessing fabrication steps or specific packaging required, such as fiber Bragg gratings or specialized coatings. The technique is highly generalizable, whereby the model can be trained to identify any measurand of interest within any noisy environment provided the measurand affects the optical path length of the MMF’s guided modes. We demonstrate the approach using a sapphire crystal optical fiber for temperature sensing under strong noise induced by mechanical vibrations, showing the power of the technique not only to extract sensing information buried in strong noise but to also enable sensing using traditionally challenging exotic materials.

Photonics Research
2021, 9(4): 0400B109
Author Affiliations
Abstract
1 State Key Laboratory of Integrated Service Networks, Xidian University, Xi’an 710071, China
2 State Key Discipline Laboratory of Wide Band Gap Semiconductor Technology, School of Microelectronics, Xidian University, Xi’an 710071, China

We propose a modified supervised learning algorithm for optical spiking neural networks, which introduces synaptic time-delay plasticity on the basis of traditional weight training. Delay learning is combined with the remote supervised method that is incorporated with photonic spike-timing-dependent plasticity. A spike sequence learning task implemented via the proposed algorithm is found to have better performance than via the traditional weight-based method. Moreover, the proposed algorithm is also applied to two benchmark data sets for classification. In a simple network structure with only a few optical neurons, the classification accuracy based on the delay-weight learning algorithm is significantly improved compared with weight-based learning. The introduction of delay adjusting improves the learning efficiency and performance of the algorithm, which is helpful for photonic neuromorphic computing and is also important specifically for understanding information processing in the biological brain.

Photonics Research
2021, 9(4): 0400B119
Author Affiliations
Abstract
1 Department of Electrical and Computer Engineering, University of Washington, Seattle, Washington 98195, USA
2 Department of Physics and Astronomy, University of Waterloo, Waterloo, Ontario ON N2L 3G1, Canada
3 Institute of Quantum Computing, University of Waterloo, Waterloo, Ontario ON N2L 3G1, Canada
4 Google, Mountain View, California 94043, USA
5 Department of Electrical and Computer Engineering, University of Waterloo, Waterloo, Ontario ON N2L 3G1, Canada
6 Department of Physics, University of Washington, Seattle, Washington 98195, USA

As artificial neural networks (ANNs) continue to make strides in wide-ranging and diverse fields of technology, the search for more efficient hardware implementations beyond conventional electronics is gaining traction. In particular, optical implementations potentially offer extraordinary gains in terms of speed and reduced energy consumption due to the intrinsic parallelism of free-space optics. At the same time, a physical nonlinearity—a crucial ingredient of an ANN—is not easy to realize in free-space optics, which restricts the potential of this platform. This problem is further exacerbated by the need to also perform the nonlinear activation in parallel for each data point to preserve the benefit of linear free-space optics. Here, we present a free-space optical ANN with diffraction-based linear weight summation and nonlinear activation enabled by the saturable absorption of thermal atoms. We demonstrate, via both simulation and experiment, image classification of handwritten digits using only a single layer and observed 6% improvement in classification accuracy due to the optical nonlinearity compared to a linear model. Our platform preserves the massive parallelism of free-space optics even with physical nonlinearity, and thus opens the way for novel designs and wider deployment of optical ANNs.

Photonics Research
2021, 9(4): 0400B128
Author Affiliations
Abstract
1 Department of Mechanical and Industrial Engineering, Northeastern University, Boston, Massachusetts 02115, USA
2 Department of Electrical and Computer Engineering, Northeastern University, Boston, Massachusetts 02115, USA
3 Khoury College of Computer Science, Northeastern University, Boston, Massachusetts 02115, USA

Over the past decades, photonics has transformed many areas in both fundamental research and practical applications. In particular, we can manipulate light in a desired and prescribed manner by rationally designed subwavelength structures. However, constructing complex photonic structures and devices is still a time-consuming process, even for experienced researchers. As a subset of artificial intelligence, artificial neural networks serve as one potential solution to bypass the complicated design process, enabling us to directly predict the optical responses of photonic structures or perform the inverse design with high efficiency and accuracy. In this review, we will introduce several commonly used neural networks and highlight their applications in the design process of various optical structures and devices, particularly those in recent experimental works. We will also comment on the future directions to inspire researchers from different disciplines to collectively advance this emerging research field.

Photonics Research
2021, 9(4): 0400B135
Author Affiliations
Abstract
1 Department of Mechanical Engineering, Pohang University of Science and Technology (POSTECH), Pohang 37673, Republic of Korea
2 Department of Chemical Engineering, Pohang University of Science and Technology (POSTECH), Pohang 37673, Republic of Korea
3 National Institute of Nanomaterials Technology (NINT), Pohang 37673, Republic of Korea

We report an approach assisted by deep learning to design spectrally sensitive multiband absorbers that work in the visible range. We propose a five-layered metal-insulator-metal grating structure composed of aluminum and silicon dioxide, and we design its structural parameters by using an artificial neural network (ANN). For a spectrally sensitive design, spectral information of resonant wavelengths is additionally provided as input as well as the reflection spectrum. The ANN facilitates highly robust design of a grating structure that has an average mean squared error (MSE) of 0.023. The optical properties of the designed structures are validated using electromagnetic simulations and experiments. Analysis of design results for gradually changing target wavelengths of input shows that the trained ANN can learn physical knowledge from data. We also propose a method to reduce the size of the ANN by exploiting observations of the trained ANN for practical applications. Our design method can also be applied to design various nanophotonic structures that are particularly sensitive to resonant wavelengths, such as spectroscopic detection and multi-color applications.

Photonics Research
2021, 9(4): 0400B153
Author Affiliations
Abstract
1 Institute of Electromagnetic Space, Southeast University, Nanjing 210096, China
2 State Key Laboratory of Millimeter Wave, Southeast University, Nanjing 210096, China
3 School of Electronic Engineering and Computer Sciences, Peking University, Beijing 100871, China

Intelligent coding metasurface is a kind of information-carrying metasurface that can manipulate electromagnetic waves and associate digital information simultaneously in a smart way. One of its widely explored applications is to develop advanced schemes of dynamic holographic imaging. By now, the controlling coding sequences of the metasurface are usually designed by performing iterative approaches, including the Gerchberg–Saxton (GS) algorithm and stochastic optimization algorithm, which set a large barrier on the deployment of the intelligent coding metasurface in many practical scenarios with strong demands on high efficiency and capability. Here, we propose an efficient non-iterative algorithm for designing intelligent coding metasurface holograms in the context of unsupervised conditional generative adversarial networks (cGANs), which is referred to as physics-driven variational auto-encoder (VAE) cGAN (VAE-cGAN). Sharply different from the conventional cGAN with a harsh requirement on a large amount of manual-marked training data, the proposed VAE-cGAN behaves in a physics-driving way and thus can fundamentally remove the difficulties in the conventional cGAN. Specifically, the physical operation mechanism between the electric-field distribution and metasurface is introduced to model the VAE decoding module of the developed VAE-cGAN. Selected simulation and experimental results have been provided to demonstrate the state-of-the-art reliability and high efficiency of our VAE-cGAN. It could be faithfully expected that smart holograms could be developed by deploying our VAE-cGAN on neural network chips, finding more valuable applications in communication, microscopy, and so on.

Photonics Research
2021, 9(4): 0400B159
