Whispering gallery mode (WGM) microcavities have been widely used for high-sensitivity ultrasound detection, owing to their optical and mechanical dual-resonance enhanced sensitivity. The ultrasound sensitivity of the cavity optomechanical system is fundamentally limited by thermal noise. In this work, we theoretically and experimentally investigate the thermal-noise-limited sensitivity of a WGM microdisk ultrasound sensor and optimize the sensitivity by varying the radius and a thickness of the microdisk, as well as using a trench structure around the disk. Utilizing a microdisk with a radius of 300 μm and thickness of 2 μm, we achieve a peak sensitivity of 1.18μPaHz-1/2 at 82.6 kHz. To the best of our knowledge, this represents the record sensitivity among cavity optomechanical ultrasound sensors. Such high sensitivity has the potential to improve the detection range of air-coupled ultrasound sensing technology.

Photoelectric logic gates (PELGs) are the key component in integrated electronics due to their abilities of signal conversion and logic operations. However, traditional PELGs with fixed architectures can realize only very limited logic functions with relatively low on–off ratios. We present a self-driving polarized photodetector driven by the Dember effect, which yields ambipolar photocurrents through photonic modulation by a nested grating. The ambipolar response is realized by exciting the whispering-gallery mode and localized surface plasmon resonances, which leads to reverse spatial carrier generation and therefore the contrary photocurrent assisted by the Dember effect. We further design a full-functional PELG, which enables all five basic logic functions (“AND”, “OR”, “NOT”, “NAND”, and “NOR”) simultaneously in a single device by using one source and one photodetector only. Such an all-in-one PELG exhibits a strong robustness against structure size, incident wavelength, light power, and half-wave plate modulation, paving a way to the realization of ultracompact high-performance PELGs.

Chiral mirrors can produce spin selective absorption for left-handed circularly polarized (LCP) or right-handed circularly polarized (RCP) waves. However, the previously proposed chiral mirror only absorbs the designated circularly polarized (CP) wave in the microwave frequency band, lacking versatility in practical applications. Here, we propose a switchable chiral mirror based on a pair of PIN diodes. The switchable chiral mirror has four working states, switching from the handedness-preserving mirror to the LCP mirror, RCP mirror, and perfect absorber. The basis of these advances is to change the chirality of two-dimensional (2D) chiral metamaterials and the circular conversion dichroism related to it, which is the first report in the microwave frequency band. Surface current distributions shed light on how switchable chiral mirrors work by handedness-selective excitation of reflective and absorbing electric dipole modes. Energy loss distributions verify the working mechanism. The thickness of the switchable chiral mirror is one-tenth of the working wavelength, which is suitable for integrated manufacturing. The measurement results are in good agreement with the simulation results.

Metasurfaces have provided an unprecedented degree of freedom (DOF) in the manipulation of electromagnetic waves. A geometric phase can be readily obtained by rotating the meta-atoms of a metasurface. Nevertheless, such geometric phases are usually spin-coupled, with the same magnitude but opposite signs for left- and right-handed circularly polarized (LCP and RCP) waves. To achieve independent control of LCP and RCP waves, it is crucial to obtain spin-decoupled geometric phases. In this paper, we propose to obtain completely spin-decoupled geometric phases by engineering the surface current paths on meta-atoms. Based on the rotational Doppler effect, the rotation manner is first analyzed, and it is found that the generation of a geometric phase lies in the rotation of the surface current paths on meta-atoms. Since the induced surface current paths under the LCP and RCP waves always start oppositely and are mirror-symmetrical with each other, it is natural that the geometric phases have the same magnitude and opposite signs when the meta-atoms are rotated. To obtain spin-decoupled geometric phases, the induced surface current under one spin should be rotated by one angle while the current under the other spin is rotated by a different angles. In this way, LCP and RCP waves can acquire different geometric phase changes. Proof-of-principle prototypes were designed, fabricated, and measured. Both the simulation and experiment results verify spin-decoupled geometric phases. This work provides a robust means to obtain a spin-dependent geometric phase and can be readily extended to higher frequency bands such as the terahertz, IR, and optical regimes.

Mode-locked biphoton frequency combs exhibit multiple discrete comblike temporal correlations from the Fourier transform of its phase-coherent frequency spectrum. Both temporal correlation and Franson interferometry are valuable tools for analyzing the joint properties of biphoton frequency combs, and the latter has proven to be essential for testing the fundamental quantum nature, the time-energy entanglement distribution, and the large-alphabet quantum key distributions. However, the Franson recurrence interference visibility in biphoton frequency combs unavoidably experiences a falloff that deteriorates the quality of time-energy entanglement and channel capacity for longer cavity round trips. In this paper, we provide a new method to address this problem towards optimum Franson interference recurrence. We first observe mode-locked temporal oscillations in a 5.03 GHz free-spectral range singly filtered biphoton frequency comb using only commercial detectors. Then, we observe similar falloff trend of time-energy entanglement in 15.15 GHz and 5.03 GHz free-spectral range singly filtered biphoton frequency combs, whereas, the optimum central time-bin accidental-subtracted visibility over 97% for both cavities. Here, we find that by increasing the cavity finesse F, we can enhance the detection probability in temporal correlations and towards optimum Franson interference recurrence in our singly filtered biphoton frequency combs. For the first time, via a higher cavity finesse F of 45.92 with a 15.11 GHz free-spectral range singly filtered biphoton frequency comb, we present an experimental ≈3.13-fold improvement of the Franson visibility compared to the Franson visibility with a cavity finesse F of 11.14 at the sixth time bin. Near optimum Franson interference recurrence and a time-bin Schmidt number near 16 effective modes in similar free-spectral range cavity are predicted with a finesse F of 200. Our configuration is versatile and robust against changes in cavity parameters that can be designed for various quantum applications, such as high-dimensional time-energy entanglement distributions, high-dimensional quantum key distributions, and wavelength-multiplexed quantum networks.

Graphene-based terahertz (THz) metasurfaces combined with metallic antennas have the advantages of ultra-small thickness, electrical tunability, and fast tuning speed. However, their tuning ability is limited by non-independently tunable pixels and low modulation depth due to the ultra-small thickness of graphene. Here, we demonstrate a reconfigurable THz phase modulator with 5×5 independently tunable units enabled by switching the voltages applied on 10 graphene ribbons prepared by laser cutting. In addition, by introducing quasi-bound states in the continuum resonance through a designed double C-shaped antenna, the efficiency of the device is enhanced by 2.7–3.6 times under different graphene chemical potentials. Experimental results demonstrate that a focus can be formed, and the focal length is changed from 14.3 mm to 22.6 mm. This work provides potential for compact THz spatial light modulators that may be applied in THz communication, detection, and imaging.

We demonstrate integrated photonic circuits for quantum devices using sputtered polycrystalline aluminum nitride (AlN) on insulator. On-chip AlN waveguide directional couplers, which are one of the most important components in quantum photonics, are fabricated and show the output power splitting ratios from 50:50 to 99:1. Polarization beam splitters with an extinction ratio of more than 10 dB are also realized from the AlN directional couplers. Using the fabricated AlN waveguide beam splitters, we observe Hong–Ou–Mandel interference with a visibility of 91.7%±5.66%.

The control of light–matter coupling at the single electron level is currently a subject of growing interest for the development of novel quantum devices and for studies and applications of quantum electrodynamics. In the terahertz (THz) spectral range, this raises the particular and difficult challenge of building electromagnetic resonators that can conciliate low mode volume and high quality factor. Here, we report on hybrid THz cavities based on ultrastrong coupling between a Tamm cavity and an LC circuit metamaterial and show that they can combine high quality factors of up to Q=37 with a deep-subwavelength mode volume of V=3.2×10-4λ3. Our theoretical and experimental analysis of the coupled mode properties reveals that, in general, the ultrastrong coupling between a metamaterial and a Fabry–Perot cavity is an effective tool to almost completely suppress radiative losses and, thus, ultimately limit the total losses to the losses in the metallic layer. These Tamm cavity-LC metamaterial coupled resonators open a route toward the development of single photon THz emitters and detectors and to the exploration of ultrastrong THz light–matter coupling with a high degree of coherence in the few to single electron limit.

Heterojunction field-effect phototransistors using two-dimensional electron gas (2DEG) for carrier transport have great potential in photodetection owing to its large internal gain. A vital factor in this device architecture is the depletion and recovery of the 2DEG under darkness and illumination. This is usually achieved by adding an external gate, which not only increases the complexity of the fabrication and the electrical connection but also has difficulty ensuring low dark current (Idark). Herein, a quasi-pseudomorphic AlGaN heterostructure is proposed to realize the self-depletion and photorecovery of the 2DEG, in which both the barrier and the channel layers are compressively strained, making the piezoelectric and spontaneous polarization reverse, thus depleting the 2DEG and tilting the entire barrier and channel band to form two built-in photogates. The fabricated solar-blind phototransistors exhibit a very low Idark below 7.1×10-10mA/mm, a superhigh responsivity (R) of 2.9×109A/W, a record high detectivity (D*) of 4.5×1021 Jones, and an ultrafast response speed at the nanosecond level. The high performance is attributed to the efficient depletion and recovery of the full 2DEG channel by the two photogates, enabling direct detection of the sub-fW signal. This work provides a simple, effective, and easily integrated architecture for carrier control and supersensitive photodetection based on polarization semiconductors.

Optical physical unclonable functions (PUFs) have emerged as a promising strategy for effective and unbreakable anti-counterfeiting. However, the unpredictable spatial distribution and broadband spectra of most optical PUFs complicate efficient and accurate verification in practical anti-counterfeiting applications. Here, we propose an optical PUF-based anti-counterfeiting label from perovskite microlaser arrays, where randomness is introduced through vapor-induced microcavity deformation. The initial perovskite microdisk laser arrays with regular positions and uniform sizes are fabricated by femtosecond laser direct ablation. By introducing vapor fumigation to induce random deformations in each microlaser cavity, a laser array with completely uneven excitation thresholds and narrow-linewidth lasing signals is obtained. As a proof of concept, we demonstrated that the post-treated laser array can provide fixed-point and random lasing signals to facilitate information encoding. Furthermore, different emission states of the lasing signal can be achieved by altering the pump energy density to reflect higher capacity information. A threefold PUF (excited under three pump power densities) with a resolution of 5×5 pixels exhibits a high encoding capacity (1.43×1045), making it a promising candidate to achieve efficient authentication and high security with anti-counterfeiting labels.

Ultrashort pulse lasers have vital significance in the field of ultrafast photonics. A saturable absorber (SA) as the core device to generate ultrashort pulses has innovative design strategies; the most interesting of which is the integration strategy based on 2D materials. This review presents recent advances in the optoelectronic properties of 2D materials and in the way the materials are prepared, characterized, and integrated into devices. We have done a comprehensive review of the optical properties of materials and material-based devices and their current development in the field of fiber lasers and solid-state lasers. Finally, we offer a look at future applications for 2D materials in ultrafast lasers and their prospects.

Optical resonators with high quality (Q) factors are paramount for the enhancement of light–matter interactions in engineered photonic structures, but their performance always suffers from the scattering loss caused by fabrication imperfections. Merging bound states in the continuum (BICs) provide us with a nontrivial physical mechanism to overcome this challenge, as they can significantly improve the Q factors of quasi-BICs. However, most of the reported merging BICs are found at Γ point (the center of the Brillouin zone), which intensively limits many potential applications based on angular selectivity. To date, studies on manipulating merging BICs at off-Γ point are always accompanied by the breaking of structural symmetry that inevitably increases process difficulty and structural defects to a certain extent. Here, we propose a scheme to construct merging BICs at almost an arbitrary point in momentum space without breaking symmetry. Enabled by the topological features of BICs, we merge four accidental BICs with one symmetry-protected BIC at the Γ point and merge two accidental BICs with opposite topological charges at the off-Γ point only by changing the periodic constant of a photonic crystal slab. Furthermore, the position of off-Γ merging BICs can be flexibly tuned by the periodic constant and height of the structure simultaneously. Interestingly, it is observed that the movement of BICs occurs in a quasi-flatband with ultra-narrow bandwidth. Therefore, merging BICs in a tiny band provide a mechanism to realize more robust ultrahigh-Q resonances that further improve the optical performance, which is limited by wide-angle illuminations. Finally, as an example of application, effective angle-insensitive second-harmonic generation assisted by different quasi-BICs is numerically demonstrated. Our findings demonstrate momentum-steerable merging BICs in a quasi-flatband, which may expand the application of BICs to the enhancement of frequency-sensitive light–matter interaction with angular selectivity.

We present the design and experimentally demonstrate a dual-level grating coupler with subdecibel efficiency for a 220 nm thick silicon photonics waveguide which was fabricated starting from a 340 nm silicon-on-insulator wafer. The proposed device consists of two grating levels designed with two different linear apodizations, with opposite chirping signs, and whose period is varied for each scattering unit. A coupling efficiency of -0.8dB at 1550 nm is experimentally demonstrated, which represents the highest efficiency ever reported in the telecommunications C-band in a single-layer silicon grating structure without the use of any backreflector or index-matching material between the fiber and the grating.

Optical metamaterials offer the possibility of controlling the behavior of photons similarly to what has been done about electrons in semiconductors. However, most optical metamaterials are narrowband, and they achieve negative refraction within a small window of incident angles, making them impractical for common visible light systems that operate effectively over a wide range of frequencies and directions. Considerable resistive loss at the resonant frequency of these metamaterials further prevents them from being deployed in the real world. Here, we develop a novel metamaterial randomly assembled by a list of narrowband, omnidirectional, and ultralow-loss meta-cluster systems using a bottom-up approach. Weak interactions among numerous meta-cluster sets greatly broaden the effective bandwidth of the overall structure, exhibiting frequency selectivity and spatial modulation when responding to white-light illumination. We observe negative refraction in the 490–730 nm band, and observe an inverse Doppler effect at green, yellow, and red frequencies, across most of the visible spectrum. Our method allows for low-cost fabrication of sizable broadband omnidirectional three-dimensional metamaterial samples, which opens the door to the rapid development of optical metamaterials, micro–nano assembly and preparation, tunable optical device engineering, etc.

The realization of pseudomagnetic fields for lightwaves has attained great attention in the field of nanophotonics. Like real magnetic fields, Landau quantization could be induced by pseudomagnetic fields in the strain-engineered graphene. We demonstrated that pseudomagnetic fields can also be introduced to photonic crystals by exerting a linear parabolic deformation onto the honeycomb lattices, giving rise to degenerate energy states and flat plateaus in the photonic band structures. We successfully inspire the photonic snake modes corresponding to the helical state in the synthetic magnetic heterostructure by adopting a microdisk for the unidirectional coupling. By integrating heat electrodes, we can further electrically manipulate the photonic density of states for the uniaxially strained photonic crystal. This offers an unprecedented opportunity to obtain on-chip robust optical transports under the electrical tunable pseudomagnetic fields, opening the possibility to design Si-based functional topological photonic devices.

We report on deep-to-near-UV transient absorption spectra of core-shell Au/SiO2 and Au/TiO2 nanoparticles (NPs) excited at the surface plasmon resonance of the Au core, and of UV-excited bare anatase TiO2 NPs. The bleaching of the first excitonic transition of anatase TiO2 at ∼3.8eV is a signature of the presence of electrons/holes in the conduction band (CB)/valence band (VB) of the material. We find that while in bare anatase TiO2 NPs, two-photon excitation does not occur up to the highest used fluences (1.34mJ/cm2), it takes place in the TiO2 shell at moderate fluences (0.18mJ/cm2) in Au/TiO2 core-shell NPs, as a result of an enhancement due to the plasmon resonance. We estimate the enhancement factor to be of the order of ∼108–109. Remarkably, we observe that the bleach of the 3.8 eV band of TiO2 lives significantly longer than in bare TiO2, suggesting that the excess electrons/holes in the conduction/valence band are stored longer in this material.

The entanglement distribution network connects remote users by sharing entanglement resources, which is essential for realizing quantum internet. We propose a photonic-reconfigurable entanglement distribution network (PR-EDN) based on a silicon quantum photonic chip. The entanglement resources are generated by a quantum light source array based on spontaneous four-wave mixing in silicon waveguides and distributed to different users through time-reversed Hong–Ou–Mandel interference by on-chip Mach–Zehnder interferometers with thermo-optic phase shifters (TOPSs). A chip sample is designed and fabricated, supporting a PR-EDN with 3 subnets and 24 users. The network topology of the PR-EDN could be reconfigured in three network states by controlling the quantum interference through the TOPSs, which is demonstrated experimentally. Furthermore, a reconfigurable entanglement-based quantum key distribution network is realized as an application of the PR-EDN. The reconfigurable network topology makes the PR-EDN suitable for future quantum networks requiring complicated network control and management. Moreover, it is also shown that silicon quantum photonic chips have great potential for large-scale PR-EDN, thanks to their capacities for generating and manipulating plenty of entanglement resources.

A precise knowledge of the polarization state of light is crucial in technologies that involve the generation and application of structured light fields. The implementation of efficient methods to determine and characterize polarization states is mandatory; more importantly, these structured light fields must be at any spatial location at a low expense. Here, we introduce a new characterization method that relies on a rather convenient description of electric fields without neglecting their 3D nature. This method is particularly suitable for highly focused fields, which exhibit important polarization contributions along their propagation direction in the neighborhood of the focal region; i.e., the contributions out of the planes transverse to the optical axis, conventionally used to specify the polarization state of these fields. As shown, the method allows the extraction of information about the three field components at relatively low computational and experimental costs. Furthermore, it also allows characterization of the polarization state of a field in a rather simple manner. To check the feasibility and reliability of the method, we determined both analytically and experimentally the local polarization states for a series of benchmark input fields with it, finding excellent agreement between the theory and experiment.

Flat optics has been considered promising for constructions of spaceborne imaging systems with apertures in excess of 10 m. Despite recent advances, there are long-existing challenges to perform in-phase stitching of multiple flat optical elements. Phasing the segmented planar instrument has remained at the proof of concept. Here, we achieve autonomous system-level cophasing of a 1.5-m stitching flat device, bridging the gap between the concept and engineering implementation. To do so, we propose a flat element stitching scheme, by manipulating the point spread function, which enables our demonstration of automatically bringing seven flat segments’ tip/tilt and piston errors within the tolerance. With phasing done, the 1.5-m system has become the largest phased planar instrument ever built in the world, to our knowledge. The first demonstration of phasing the large practical flat imaging system marks a significant step towards fielding a 10-m class one in space, also paving the way for ultrathin flat imaging in various remote applications.

Transparent absorbers, with a functional integration of broadband electromagnetic shielding, microwave camouflage, and optical transparency, have attracted increasing attention in the past decades. Metal mesh, an artificial, optically transparent, conducting material composed of periodic metallic gratings, is the optimal choice for the microwave shielding layer of transparent absorbers because of its excellent compatibility between high transparency and low resistance. However, the micrometer-level periodicity of metallic grating concentrates the diffraction of light, which degrades the imaging quality of cameras and sensors in common. In this study, we report on a generalized Thiessen-polygon-randomization method that prevents the concentration of the diffraction of light in periodic metallic grating and demonstrate an ultrawide-band optically transparent diffraction-immune metamaterial absorber. The absorber is constructed with a multilayer indium-tin-oxide-based metasurface and a Thiessen-polygon-randomized metal-mesh reflector. The lossy metasurface provides multimode absorption, whereas the Thiessen-polygon randomization prevents the concentration of the diffraction of light. The practical sample achieves a 10 dB absorptivity and shielding effectiveness over a range of 8–26.5 GHz, and the optical transparency is also preserved over the entire visible and near-infrared regions. The point spread function and field of view are both improved by using the antidiffraction absorber. Our study paves the way for the application of optically transparent electromagnetic devices, display, and optoelectronic integration in a more practical stage.
