Author Affiliations
Abstract
1 School of Electronic Science and Engineering, Xiamen University, Xiamen 361005, China
2 Institute of Electromagnetics and Acoustics, Xiamen University, Xiamen 361005, China
3 Xiamen Sky Semiconductor Technology Co., Ltd., Xiamen 361026, China
The narrowband meta-absorbers exhibit significantly enhanced electromagnetic confinement capabilities, showcasing broad application prospects in sensing fields. They can be applied for biomarker detection, chemical composition analysis, and monitoring of specific gas in the environment. In this work, we propose a 3D meta-absorber with an out-of-plane plasma mechanism based on a two-photon printing system. Compared to the conventional fabrication of a metal-insulator-metal 2D meta-absorber, the 3D absorber is composed of a metal layer and a resin layer from top to bottom; its manufacturing process is simpler, only including two-photon printing and magnetron sputtering deposition. A noticeable absorbing resonance appears at 0.3142 THz with perfect absorbance with a high Q-factor of 104.67. The theoretical sensitivity to the refractive index of the sensor reaches up to 172.5 GHz/RIU, with a figure of merit (FOM) of 19.56. In the experiments, it was validated as a meta-absorber with high sensitivity for doxycycline (DCH). As the DCH concentration increases from 0 to 4 mg/mL, the absorption intensity decreases around 49%, while the resonant frequency shift is around 70 GHz. It reflects the real-time residual content of DCH, and is potentially applied in trace antibiotic detection. The results showcase a perfect narrowband absorption capability with strong electromagnetic confinement in the terahertz spectrum, along with high-Q sensing characteristics of DCH. Compared to 2D metamaterials, the diversity of 3D metamaterial significantly expands, and introduces additional effects to provide greater flexibility in manipulating electromagnetic waves. The 3D device offers opportunities for the application of terahertz biochemical sensing.
Photonics Research
2024, 12(5): 895
Yuxi Li 1Jiafu Wang 1,*Sai Sui 1,3Ruichao Zhu 1,4[ ... ]Shaobo Qu 1,5
Author Affiliations
Abstract
1 Shaanxi Key Laboratory of Artificially-Structured Functional Materials and Devices, Air Force Engineering University, Xi’an 710051, China
2 Air and Missile Defense College, Air Force Engineering University, Xi’an 710051, China
3 e-mail: suisai_mail@foxmail.com
4 e-mail: zhuruichao1996@163.com
5 e-mail: Qushaobo@mail.xjtu.edu.cn
Coding metasurfaces can manipulate electromagnetic wave in real time with high degree of freedom, the fascinating properties of which enrich the metasurface design with a wide range of application prospects. However, most of the coding metasurfaces are designed based on external excitation framework with the wired electrical or wireless light control devices, thus inevitably causing the interference with electromagnetic wave transmission and increasing the complexity of the metasurface design. In this work, a simplistic framework of single-pixel-programmable metasurfaces integrated with a capsuled LED array is proposed to dynamically control electromagnetic wave. The framework fully embeds the photoresistor in the meta-atom, controlling the LED array to directly illuminate the photoresistor to modulate the phase response. With this manner, the complex biasing network is transformed to the universal LED array, which means the physical control framework can be transformed to a software framework, and thus the functions of the metasurface can be freely manipulated by encoding the capsuled LED array avoiding mutual coupling of adjacent meta-atoms in real time. All the results verify that the far-field scattering pattern can be customized with this single-pixel-programmable metasurface. Encouragingly, this work provides a universal framework for coding metasurface design, which lays the foundation for metasurface intelligent perception and adaptive modulation.
Photonics Research
2024, 12(5): 884
Zijian Liu 1†Yuying Xi 1†Wenbo Zeng 1Ting Ji 1,3,*[ ... ]Guohui Li 1,2,5,*
Author Affiliations
Abstract
1 College of Physics, College of Electronic Information and Optical Engineering, Key Laboratory of Advanced Transducers and Intelligent Control System of Ministry of Education, Taiyuan University of Technology, Taiyuan 030024, China
2 Shanxi-Zheda Institute of Advanced Materials and Chemical Engineering, Taiyuan 030032, China
3 e-mail: jiting@tyut.edu.cn
4 e-mail: yanxiacui@tyut.edu.cn
5 e-mail: liguohui@tyut.edu.cn
Lead-free perovskite Cs2AgBiBr6 manifests great potential in developing high-performance, environmentally friendly, solution-processable photodetectors (PDs). However, due to the relatively large energy bandgap, the spectrum responses of Cs2AgBiBr6 PDs are limited to the ultraviolet and visible region with wavelengths shorter than 560 nm. In this work, a broadband Cs2AgBiBr6 PD covering the ultraviolet, visible, and near infrared (NIR) range is demonstrated by incorporating titanium nitride (TiN) nanoparticles that are prepared with the assistance of self-assembled polystyrene sphere array. In addition, an atomically thick Al2O3 layer is introduced at the interface between the Cs2AgBiBr6 film and TiN nanoparticles to alleviate the dark current deterioration caused by nanoparticle incorporation. As a result, beyond the spectrum range where Cs2AgBiBr6 absorbs light, the external quantum efficiency (EQE) of the TiN nanoparticle incorporated Cs2AgBiBr6 PD is enhanced significantly compared with that of the control, displaying enhancement factors as high as 2000 over a broadband NIR wavelength range. The demonstrated enhancement in EQE arises from the photocurrent contribution of plasmonic hot holes injected from TiN nanoparticles into Cs2AgBiBr6. This work promotes the development of broadband solution-processable perovskite PDs, providing a promising strategy for realizing photodetection in the NIR region.
Photonics Research
2024, 12(3): 522
Author Affiliations
Abstract
1 Key Laboratory of Material Physics, Ministry of Education, School of Physics and Microelectronics, Zhengzhou University, Zhengzhou 450052, China
2 Key Laboratory of Opto-Electronics Information Technology (Tianjin University), Ministry of Education, School of Precision Instruments and Opto-Electronics Engineering, Tianjin University, Tianjin 300072, China
3 Beijing Key Laboratory for Metamaterials and Devices, Key Laboratory of Terahertz Optoelectronics, Ministry of Education, and Beijing Advanced Innovation Center for Imaging Technology, Department of Physics, Capital Normal University, Beijing 100048, China
4 State Key Laboratory of Modern Optical Instrumentation, College of Optical Science and Engineering, Zhejiang University, Hangzhou 310027, China
5 e-mail: zanghuaping@zzu.edu.cn
6 e-mail: yzhang@mail.cnu.edu.cn
Polarization is crucial in various fields such as imaging, sensing, and substance detection. A compact, fast, and accurate polarization detection device is vital for these applications. Herein, we demonstrate a multifocus metalens for terahertz polarization detection that requires only a single measurement to obtain complete polarization parameters and reconstruct the polarization state of the incident field. The individual subarrays of this metalens convert each of the six polarized components into the same polarization, which in turn links the Stokes parameters to these six foci. The incident linear polarizations and elliptical polarizations are characterized by Stokes parameters and polarization ellipses. Simulations and experimental results show that the scheme can accurately detect the incident polarization with a single measurement. The proposed metasurface polarimetry may find applications in the fields of real-time terahertz detection and integrated optics.
Photonics Research
2024, 12(3): 514
Author Affiliations
Abstract
1 Institute of Optoelectronic Technology, China Jiliang University, Hangzhou 310018, China
2 Centre for THz Research, China Jiliang University, Hangzhou 310018, China
3 College of Metrology & Measurement Engineering, China Jiliang University, Hangzhou 310018, China
4 e-mail: lichenxiacjlu@163.com
Programmable hyper-coded holography has the advantage of being programmable as well as being flexibly modifiable. Digitally coded metamaterials with excellent electromagnetic modulation capability and the ability to control the phase to modulate the spatial radiation field through external excitation in the form of switching can be used to realize low-cost digital arrays. We design a 1-bit encoded programmable metasurface, which is electrically connected to control the PIN diode in the switching state and to switch the condition of each metasurface cell between “0” and “1.” Using the designed programmable metasurface, we can randomly encode the cell structure to realize single-focus focusing, multi-focusing, and simple holographic letter imaging. Based on the nonlinear holographic model, we employ the Gerchberg-Saxton improvement algorithm to modulate the energy distribution at the focus by adjusting the phase distribution. Importantly, we introduce the Fourier convolution principle to regulate the holographic imaging focus flexibly.
Photonics Research
2024, 12(1): 61
Author Affiliations
Abstract
1 Key Laboratory of Material Physics, Ministry of Education, School of Physics and Microelectronics, Zhengzhou University, Zhengzhou 450052, China
2 Beijing Key Laboratory for Metamaterials and Devices, Key Laboratory of Terahertz Optoelectronics, Ministry of Education, and Beijing Advanced Innovation Center for Imaging Technology, Department of Physics, Capital Normal University, Beijing 100048, China
3 Key Laboratory of Opto-Electronics Information Technology (Tianjin University), Ministry of Education, School of Precision Instruments and Opto-Electronics Engineering, Tianjin University, Tianjin 300072, China
4 State Key Laboratory of Modern Optical Instrumentation, College of Optical Science and Engineering, Zhejiang University, Hangzhou 310027, China
5 e-mail: wangmengguang@zju.edu.cn
6 e-mail: zanghuaping@zzu.edu.cn
7 e-mail: yzhang@mail.cnu.edu.cn
The manipulation and detection of polarization states play a crucial role in the application of 6G terahertz communication. Nonetheless, the development of compact and versatile polarization detection devices capable of detecting arbitrary polarizations continues to be a challenging endeavor. Here, we demonstrate a terahertz polarization detection scheme by performing mode purity analysis and multidimensional analysis of the transmitted vortex field. The power of the proposed polarization recognition is verified by using three polarization trajectories, including linear polarizations, circular polarizations, and elliptical polarizations. Using the reconstructed complete polarization parameters, the detected polarization states are characterized using polarization ellipses, Poincaré sphere, and full-Stokes parameters. The experimental results validate the power of this scheme in polarization detection. This scheme holds promise for applications in polarization imaging and terahertz communication.
Photonics Research
2023, 11(12): 2256
Author Affiliations
Abstract
1 National Key Laboratory of Science and Technology on Micro/Nano Fabrication, School of Integrated Circuits, Peking University, Beijing 100871, China
2 School of Electronics, Peking University, Beijing 100871, China
3 School of Automation, University of Science and Technology Beijing, Beijing 100083, China
4 School of Instrument Science and Opto-Electronics Engineering, Beijing Information Science and Technology University, Beijing 100096, China
5 State Key Laboratory of Transducer Technology, Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100190, China
6 University of Chinese Academy of Sciences, Beijing 100049, China
7 Beijing Advanced Innovation Center for Integrated Circuits, Beijing 100871, China
8 Frontiers Science Center for Nano-optoelectronics, Peking University, Beijing 100871, China
Surface lattice resonance (SLR) is a pretty effective mechanism to realize ultranarrow linewidths in the spectrum. Herein, we propose and demonstrate reflection-type SLRs in all-metal metasurfaces experimentally, compared with the traditional transmission-type SLR, which can avoid the refractive index (RI) mismatch problem and are more suitable for high-efficiency RI sensing due to direct contact and strong light–matter interaction. The measured SLR linewidth is 13.5 nm influenced by the meta-atom size, which needs a compromise design to keep a balance between the narrow linewidth and noise immunity. Notably, the SLR sensitivity is determined by the lattice period along the polarization direction with regularity, which establishes an intuitive link between structures and optical responses and provides a theoretical guide for metasurface designs. Additionally, incident angle multiplexing will make the resonance wavelength red shift or blue shift in the case of orthogonal polarization. The rectangular array metasurface can realize dual SLRs with different sensing performances. Flexibly, the SLR can also be formed by the different meta-atoms and arrays. This research supports SLR multifarious applications involving not only RI sensing but also nonlinear optics, nano-lasers, etc.
Photonics Research
2023, 11(12): 2210
Ye Xiang 1,2,3†Yongping Zhai 1†Jiazhi Yuan 2,3Ke Ren 2,3[ ... ]Wenxin Wang 2,3,*
Author Affiliations
Abstract
1 College of Advanced Interdisciplinary Studies, National University of Defense Technology, Changsha 410073, China
2 College of Physics and Optoelectronic Engineering, Harbin Engineering University, Harbin 150001, China
3 Qingdao Innovation and Development Center of Harbin Engineering University, Harbin Engineering University, Qingdao 266500, China
Surface lattice resonances (SLRs) with ultra-narrow linewidth (high quality factor) can enhance light–matter interactions at the nanoscale and modulate the propagating light from the emission wavelength direction to efficiency by photonic band engineering. Therefore, SLRs can serve as an excited candidate to enhance and, more importantly, modulate amplified spontaneous emission (ASE) with more optical parameters. Here, this work presents a system of two-dimensional Ag-coated Al nanocone array (Ag-NCA) packaged with Nile red, and a normal ASE with 15-fold enhancement is observed under external driving light. This enhancement fades away, obviously, in the case of the off-normal condition, as the optical feedback evolves from the band edge steady state to the propagating state. The ASE of this hybrid plasmonic system expands the possibilities of interaction between light and matter and has great promise for applications in nanolasing, super-resolution imaging, and photonic integration circuits.
Photonics Research
2023, 11(12): 2202
Bin Fang 1,2,4,*†Zhizhang Wang 2†Yantao Li 1Jitao Ji 2[ ... ]Tao Li 2,5,*
Author Affiliations
Abstract
1 College of Optical and Electronic Technology, Centre for THz Research, China Jiliang University, Hangzhou 310018, China
2 National Laboratory of Solid State Microstructures, College of Engineering and Applied Sciences, Nanjing University, Nanjing 210093, China
3 School of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
4 e-mail: binfang@cjlu.edu.cn
5 e-mail: taoli@nju.edu.cn
Employing couplers to convert guided waves into free-space modes and flexibly control their wavefront is one of the key technologies in chip-integrated displays and communications. Traditional couplers are mainly composed of gratings, which have limitations in footprint, bandwidth, as well as controllability. Though the resonant/geometric metasurface newly emerges as a promising interface for bridging guided waves with free-space ones, it either relies on complex optimizations of multiple parameters, or is subject to the locked phase response of opposite spins, both of which hinder the functional diversity and practical multiplexing capability. Here, we propose and experimentally demonstrate an alternative with a spin-decoupled meta-coupler, simultaneously integrating triple functions of guided wave radiation, polarization demultiplexing, and dual-channel wavefront manipulation into a single device. By endowing polarization-dependent functionalities into a pure geometric metasurface, the out-coupled left-handed and right-handed circular polarization guided waves intelligently identify the predesigned phase modulation and reconstruct desired wavefronts, like bifocal focusing and holography multiplexing, with a polarization extinction ratio over 13.4 dB in experiments. We envision that the robust, broadband, and multifunctional meta-coupler could pave a way for the development of versatile multiplexed waveguide-based devices.
Photonics Research
2023, 11(12): 2194
Author Affiliations
Abstract
1 Key Laboratory of Semiconductor Materials Science, Beijing Key Laboratory of Low Dimensional Semiconductor Materials and Devices, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2 Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3 School of Integrated Circuits and Electronics, MIIT Key Laboratory for Low-Dimensional Quantum Structure and Devices, Beijing Institute of Technology, Beijing 100081, China
4 Engineering Research Center for Semiconductor Integrated Technology, Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
5 Fachgebiet Angewandte Nanophysik, Institut für Physik & IMN MacroNano, Technische UniversitätIlmenau, Ilmenau 98693, Germany
6 e-mail: yueshizhong@semi.ac.cn
7 e-mail: wangzj@semi.ac.cn
8 e-mail: yong.lei@tu-ilmenau.de
Optical frequency combs (OFCs) have great potential in communications, especially in dense wavelength-division multiplexing. However, the size of traditional OFCs based on conventional optical microcavities or dispersion fibers is at least tens of micrometers, far larger than that of nanoscale electronic chips. Therefore, reducing the size of OFCs to match electronic chips is of necessity. Here, for the first time to our knowledge, we introduce surface plasmon polaritons (SPPs) to the construction of OFCs to realize a miniature device. The thickness of our device is reduced below 1 μm. Though the presence of SPPs may induce ohmic and scattering loss, the threshold of the device is obtained as 9 μW, comparable to the conventional device. Interestingly, the response time is 13.2 ps, much faster than the optical counterparts. This work provides a feasible strategy for the miniaturization of OFCs.
Photonics Research
2023, 11(12): 2105
