基于曲率特征的漂移配准方法

石珣; 任洁; 任小康; 任进军; 袁芝丰

doi:doi:10.3788/lop55.081008

激光与光电子学进展, 2018, 55 (8): 081008, 网络出版: 2018-08-13

基于曲率特征的漂移配准方法下载： 554次

Drift Registration Based on Curvature Characteristics

论文大纲

石珣 ¹任洁 ²任小康 ¹任进军 ¹袁芝丰 ¹

作者单位

¹ 西北师范大学计算机科学与工程学院，甘肃兰州 730070

² 兰州城市学院信息工程学院，甘肃兰州 730070

图像处理点云快速配准曲率一致性漂移 image processing point cloud fast registration curvature coherent point drift

AI 词云图 AI语音精读 AI语音超短摘要

注：本部分内容由 AI 自动生成，请您知悉。

摘要

点云配准是三维建模的关键步骤，而配准速率又是其中的一个瓶颈。实际中点云数据规模大并且对配准速率有一定要求。针对配准点云规模增大导致的配准速率退化以及点云距离过大导致配准失败的情况，结合曲率特征与一致性漂移思想提出一种快速配准点云的方法，首先计算点云曲率特征，然后对比点云间的曲率相似度，提取具有相似结构的特征点作为配准点云。实验表明,该方法不仅将配准的时间消耗缩减1/2左右，并且能够配准距离200个单位坐标差的点云。

Abstract

Point registration is a critical step of three-dimensional modeling, but the registration rate has been a major bottleneck restricting development of point registration. In the real life, the point registration data are large in scale and have certain requirement of the registration rate. Concerning decrease of the registration rate resulted from a large point registration scale and potential registration failure caused by a too large cloud distance, this paper combines features of curvature and the concept of coherent point drift to propose a quick point registration method. To begin with, the point cloud curvature is calculated. Then, the curvature similarity between point clouds is compared. The registered point clouds with feature points similar in the structure are extracted. This experiment suggests that this method can not only reduce the time consumption of registration by around two folds, but also register point clouds within the distance of 200 units of coordinate difference.

参考文献

[1] 韦盛斌, 王少卿, 周常河, 等. 用于三维重建的点云单应性迭代最近点配准算法［J］. 光学学报, 2015, 35(5): 0515003.

Wei S B, Wang S Q, Zhou C H, et al. An iterative closest point algorithm based on biunique correspondence of point clouds for 3D reconstruction［J］. Acta Optica Sinica, 2015, 35(5): 0515003.

[2] 张晓, 张爱武, 王致华. 基于改进正态分布变换算法的点云配准［J］. 激光与光电子学进展, 2014, 51(4): 041002.

Zhang X, Zhang A W, Wang Z H. Point cloud registration based on improved normal distribution transform algorithm［J］. Laser & Optoelectronics Progress, 2014, 51(4): 041002.

[3] 杨书娟, 张珂殊, 邵永社. 机载激光雷达系统的航带平差法［J］. 中国激光, 2017, 44(12): 1210003.

Yang S J, Zhang K S, Shao Y S. Strip adjustment method for airborne lidar system［J］. Chinese Journal of Lasers, 2017, 44(12): 1210003.

[4] 王岩. 阵列激光三维成像点云数据配准技术研究［D］. 长春: 中国科学院长春光学精密机械与物理研究所, 2016.

Wang Y. Registration of array laser three dimension imaging point cloud［D］. Changchun: Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, 2016.

[5] 黄作维, 刘峰, 胡光伟. 基于多尺度虚拟格网的LiDAR点云数据滤波改进方法［J］. 光学学报, 2017, 37(8): 0828004.

Huang Z W, Liu F, Hu G W. Improved method for LiDAR point cloud data filtering based on hierarchical pseudo-grid［J］. Acta Optica Sinica, 2017, 37(8): 0828004.

[6] 伍梦琦, 李中伟, 钟凯, 等. 基于几何特征和图像特征的点云自适应拼接方法［J］. 光学学报, 2015, 35(2): 0215002.

Wu M Q, Li Z W, Zhong K, et al. Adaptive point cloud registration method based on geometric features and photometric features［J］. Acta Optica Sinica, 2015, 35(2): 0215002.

[7] Besl P J,McKay N D. A method for registration of 3-D shapes［J］. IEEE Transactions on Pattern Analysis and Machine Intelligence, 1992, 14(2): 239-256.

[8] Chui H, Rangarajan A. A feature registration framework using mixture models［C］∥Proceedings of the IEEE Workshop on Mathematical Methods in Biomedical Image Analysis, 2000: 190-197.

[9] Jian B, Vemuri B C. Robust point set registration using Gaussian mixture models［J］. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2011, 33(8): 1633-1645.

[10] Myronenko A, Song X. Point set registration: coherent point drift［J］. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2010, 32(12): 2262-2275.

[11] Campbell D, Petersson L. GOGMA: globally-optimal Gaussian mixture alignment［C］. Computer Vision and Pattern Recognition,2016: 5685-5694.

[12] 黄源, 达飞鹏, 陶海跻. 一种基于特征提取的点云自动配准算法［J］. 中国激光, 2015, 42(3): 0308002.

Huang Y, Da F P, Tao H J. An automatic registration algorithm for point cloud based on feature extraction［J］. Chinese Journal of Lasers, 2015, 42(3): 0308002.

[13] 李仁忠, 杨曼, 田瑜, 等. 基于ISS特征点结合改进ICP的点云配准算法［J］. 激光与光电子学进展, 2017, 54(11): 111503.

Li R Z, Yang M, Tian Y, et al. Point cloud registration algorithm based on the ISS feature points combined with improved ICP algorithm［J］. Laser & Optoelectronics Progress, 2017, 54(11): 111503.

[14] 曾繁轩, 李亮, 刁鑫鹏. 基于曲率特征的迭代最近点算法配准研究［J］. 激光与光电子学进展, 2017, 54(1): 011003.

Zeng F X, Li L, Diao X P. Iterative closest point algorithm registration based on curvature features［J］. Laser & Optoelectronics Progress, 2017, 54(1): 011003.

[15] 舒程珣, 何云涛, 孙庆科. 基于卷积神经网络的点云配准方法［J］. 激光与光电子学进展, 2017, 54(3): 031001.

Shu C X, He Y T, Sun Q K. Point cloud registration based on convolutional neural network［J］. Laser & Optoelectronics Progress, 2017, 54(3): 031001.

[16] 朱延娟, 周来水, 张丽艳. 散乱点云数据配准算法［J］. 计算机辅助设计与图形学学报, 2006, 18(4): 475-481.

Zhu Y J,Zhou L S, Zhang L Y. Registration of scattered cloud data［J］.Journal of Computer-Aided Design & Computer Graphics, 2006, 18(4): 475-481.

[17] Yang M, Lee E. Segmentation of measured point data using a parametric quadric surface approximation［J］. Computer-Aided Design, 1999, 31(7): 449-457.

石珣, 任洁, 任小康, 任进军, 袁芝丰. 基于曲率特征的漂移配准方法[J]. 激光与光电子学进展, 2018, 55(8): 081008. Shi Xun, Ren Jie, Ren Xiaokang, Ren Jinjun, Yuan Zhifeng. Drift Registration Based on Curvature Characteristics[J]. Laser & Optoelectronics Progress, 2018, 55(8): 081008.
