基于高光谱图像的生菜叶片水分预测研究

为了便于生菜合理施水管理, 力求构建生菜叶片水分检测模型。采集生菜叶片获取高光谱图像并同时测量叶片含水率, 分析高光谱图像寻求生菜叶片水分特征波段, 处理特征波段处的波段图像, 求取生菜叶片水分的图像特征, 并通过相关性分析筛选出其中与水分相关性高的图像特征。由于图像特征之间存在可能的相关性, 利用偏最小二乘PLS提取图像特征的主成分, 作为具有回归预测能力的BP神经网络的输入, 构建PLS-ANN模型。同时分别利用BP神经网络、传统的多元回归方法MLR建模, 采用相同的样本数据分别对三种模型进行预测试验, 结果表明, 发棵期的PLS-ANN网络模型的生菜叶片水分预测平均误差率达到9.323%, 比BP-ANN和MLR预测模型均有了改善。

Abstract

In order to conduct rational management of watering lettuce, the model of detecting lettuce leaves’ moisture was built. First of all, the hyperspectral images of lettuce leaves were acquired and simultaneously the moisture proportions of leaves were measured. Meanwhile, hyperspectral images were analyzed and the characteristic bands of lettuce leaves’ moisture were found. Then the images in characteristic bands were processed and the image features of lettuce leaves’ moisture were computed. The image features highly relevant to moisture were obtained through correlation analysis. Furthermore, due to the possible correlation among image features, the principal components of the images were extracted by principal components analysis and were used as BP neural network’s inputs to establish PCA-ANN model. At the same time, other models were constructed by using BP neural network and traditional MLR (multiple liner regression) method respectively. Prediction examinations of the three models were made based on the same sample data. The experimental results show that the average prediction error of PCA-ANN prediction model of tillering stage reaches 9.323% which is improved compared with BP-ANN and MLR prediction models.

参考文献

[1] Rodriguez D, Fitzgerald G, Christensen L, et al. Remote Sensing of Environment, 2007, 108: 121.

[2] MAO Han-ping, ZHANG Xiao-dong, LI Xue, et al(毛罕平, 张晓东, 李雪, 等). Journal of Jiangsu University·Natural Science Edition(江苏大学学报·自然科学版), 2008, 29(5): 369.

[3] HUANG Cai-jin, HAN Lu-jia, LIU Xian, et al(皇才进, 韩鲁佳, 刘贤, 等). J. Infrared Millim. Waves(红外与毫米波学报), 2009, 28: 184.

[4] CAI Hong-chang, CUI Hai-xin, GAO Li-hong, et al(蔡鸿昌, 崔海信, 高丽红, 等). Chinese Agricultural Science Bulletin(中国农学通报), 2006, 22(8): 532.

[5] WANG Fang-yong, WANG Ke-ru, WANG Chong-tao(王方永, 王克如, 王崇桃). Journal of Shihezi University Natural Science(石河子大学学报), 2007, (4): 404.

[6] DAI Zhi-xiang, SHAO Lu-shou, DING Ke-jian(戴之祥, 邵陆寿, 丁克坚). Transactions of The Chinese Society of Agricultural Machinery(农业机械学报), 2007, 38: 200.

[7] CAI Jian-rong, WANG Jian-hei, CHEN Quan-sheng, et al(蔡健荣, 王建黑, 陈全胜, 等). Transactions of the Chinese Society of Agricultural Engineering(农业工程学报), 2009, 25: 127.

[8] HONG Tian-sheng, QIAO Jun, NING Wang, et al(洪添胜, 乔军, NING Wang, 等). Transactions of The Chinese Society of Agricultural Engineering(农业工程学报), 2007, 23: 151.

[9] LI Jiang-bo, SU Yi-nan, RAO Xiu-qin(李江波, 苏忆楠, 饶秀勤). Packaging and Food Machinery(包装与食品机械), 2010, 28: 1.

[10] ZHANG Xin-ming, ZHANG Ai-li, ZHANG Yan-bin, et al(张新明, 张爱丽, 郑延斌, 等). Computer Science(计算机科学), 2011, 38: 278.

[11] LI Lin(李林). Journal of Tarim University(塔里木大学学报), 2007, 19: 40.

[12] CHEN Bo, OUYANG Zhu(陈博, 欧阳竹). Transactions of The Chinese Society of Agricultural Engineering(农业工程学报), 2010, 24: 81.

[13] MA Sha, XIAO Ming, HUANG Zhi-quan(马莎, 肖明, 黄志全). Engineering Journal of Wuhan University(武汉大学学报), 2008, 54: 43.

孙俊, 武小红, 张晓东, 高洪燕. 基于高光谱图像的生菜叶片水分预测研究[J]. 光谱学与光谱分析, 2013, 33(2): 522. SUN Jun, WU Xiao-hong, ZHANG Xiao-dong, GAO Hong-yan. Research on Lettuce Leaves’ Moisture Prediction Based on Hyperspectral Images[J]. Spectroscopy and Spectral Analysis, 2013, 33(2): 522.
