激光与光电子学进展, 2015, 52 (2): 021001, 网络出版: 2015-01-29

融合光谱、纹理及形态特征的水稻种子品种高光谱图像单粒鉴别 下载: 540次

Variety Discrimination for Single Rice Seed by Integrating Spectral, Texture and Morphological Features Based on Hyperspectral Image
作者单位
江南大学轻工过程先进控制教育部重点实验室, 江苏 无锡 214122
摘要
水稻种子品种的单粒鉴别对于防止制种时的混杂、掺假现象,保证种子纯度具有重要意义。利用高光谱图像技术研究了水稻种子品种的单粒快速鉴别方法。采集了10 类水稻种子在400~1000 nm 范围内的高光谱反射图像并提取其光谱、纹理和形态特征;结合偏最小二乘判别分析模型比较了不同特征及其组合下的分类精度,并利用多次递进无信息变量消除算法结合偏最小二乘投影分析方法筛选最优波段。结果显示,在仅利用23 个最优波段情况下,融合均值、熵、能量和形态特征所建立的鉴别模型获得了令人满意的识别精度,其训练集、测试集精度分别为99.22%、96%。结果表明,高光谱特征融合可以在少量波段情况下有效地提高水稻种子品种单粒鉴别的精度,基本满足国家标准对种子纯度的检测要求。
Abstract
Variety discrimination for single rice seed is important to prevent the mixing and adulteration during seed production and to ensure the seed purity. A fast discrimination method for single rice seed by using the hyperspectral imaging technology is investigated. Hyperspectral images of rice seeds from ten varieties are collected over the wavelength region of 400~1000 nm, and the spectral, texture and morphological features of rice seeds are extracted. The discrimination accuracy of different features and their combinations is compared by using the partial least squares discriminant analysis, and the multiple progressive uninformative variable elimination algorithm combined with the partial least squares projection analysis algorithm is used for optimal waveband selection. The results show that the satisfactory discrimination accuracy, which is 99.22% and 96% for the training set and test set respectively, is achieved when mean, entropy and power features for the 23 optimal wavebands and morphological features are integrated. It suggests that multiple hyperspectral feature integration can effectively improve discrimination accuracy for single rice seed at the case of a small amount of wavebands, which basically meets the requirements of the national standards on the seed purity identification.
参考文献

[1] 刘洋, 章国安. 可见光通信调制方式及其性能研究[J]. 激光与光电子学进展, 2014, 51(9): 090601.

    Liu Yang, Zhang Guoan. Study on modulation scheme of visible light communications and its performance [J]. Laser & Optoelectronics Progress, 2014, 51(9): 090601.

[2] 曹鹏飞, 李宏宁, 罗艳琳, 等. 基于多光谱成像选取四季豆叶片的特征波段[J]. 激光与光电子学进展, 2014, 51(1): 011101.

    Cao Pengfei, Li Hongning, Luo Yanlin, et al.. Selection of feature bands for Phaseolus vulgaris leaves based on multispectral imaging [J]. Laser & Optoelectronics Progress, 2014, 51(1): 011101.

[3] Lü B, Wu J. Quantifying spectroscopic concentration ratio by polarization subtraction technique [J]. Chinese Optics Letters, 2013, 11(s2): s23001.

[4] Quan J, Bai B, Jin S, et al.. Indoor positioning modeling by visible light communication and imaging [J]. Chinese Optics Letters, 2014, 12(5): 052201.

[5] Dana W, Ivo W. Computer image analysis of seed shape and seed color for flax cultivar description [J]. Computers and Electronics in Agriculture, 2008, 61(2): 126-135.

[6] Khatchatourian O, Padilha F R R. Soybean varieties recognition through the digital image processing using artificial neural network [J]. Engenharia Agricola, 2008, 28(4): 759-769.

[7] 成芳, 应义斌. 机器视觉技术在农作物种子质量检验中的应用研究进展[J]. 农业工程学报, 2001, 17(6): 175-179.

    Cheng Fang, Ying Yibin. Application of machine vision to quality evaluation of agricultural seed resources [J]. Transactions of the Chinese Society of Agricultural Engineering, 2001, 17(6): 175-179.

[8] 苏谦, 邬文锦, 王红武, 等. 基于近红外光谱和仿生模式识别玉米品种快速鉴别方法[J]. 光谱学与光谱分析, 2009, 29(9): 2413-2416.

    Su Qian, Wu Wenjin, Wang Hongwu, et al.. Fast discrimination of varieties of corn based on near infrared spectra and biomimetic pattern recognition [J]. Spectroscopy and Spectral Analysis, 2009, 29(9): 2413-2416.

[9] 刘天玲, 苏琪雅, 孙群, 等. 基于NIR 分析和模式识别技术的玉米种子识别系统[J]. 光谱学与光谱分析, 2012, 32(6): 1550-1553.

    Liu Tianling, Su Qiya, Sun Qun, et al.. Recognition of corn seeds based on pattern recognition and near infrared spectroscopy technology [J]. Spectroscopy and Spectral Analysis, 2012, 32(6): 1550-1553.

[10] 张初, 刘飞, 孔汶汶, 等. 利用近红外高光谱图像技术快速鉴别西瓜种子品种[J]. 农业工程学报, 2013, 29(20): 270-277.

    Zhang Chu, Liu Fei, Kong Wenwen, et al.. Fast identification of watermelon seed variety using near infrared hyperspectral imaging technology [J]. Transactions of the Chinese Society of Agricultural Engineering, 2013, 29(20): 270-277.

[11] 黄敏, 朱晓, 朱启兵, 等. 基于高光谱图像的玉米种子特征提取与识别[J]. 光子学报, 2012, 41(7): 868-873.

    Huang Min, Zhu Xiao, Zhu Qibing, et al.. Morphological characteristics of maize seed extraction and identification based on the hyperspectral image [J]. Acta Photonica Sinica, 2012, 41(7): 868-873.

[12] 朱启兵, 冯朝丽, 黄敏, 等. 基于图像熵信息的玉米种子纯度高光谱图像识别[J]. 农业工程学报, 2012, 28(23): 271-276.

    Zhu Qibing, Feng Zhaoli, Huang Min, et al.. Maize seed classification based on image entropy using hyperspectral imaging technology [J]. Transactions of the Chinese Society of Agricultural Engineering, 2012, 28(23): 271-276.

[13] 李宣平, 王雪. 模糊聚类协作区域主动轮廓模型医学图像分割[J]. 仪器仪表学报, 2013, 34(4): 860-865.

    Li Xuanping, Wang Xue. Active contour model-based medical image segmentation method collaborative with fuzzy cmeans [J]. Chinese Journal of Scientific Instrument, 2013, 34(4): 860-865.

[14] 黄敏, 朱晓, 朱启兵, 等. 基于主动轮廓模型的玉米种子高光谱图像分类[J]. 数据采集与处理, 2013, 28(3): 289-293.

    Huang Min, Zhu Xiao, Zhu Qibing, et al.. Hyperspectral image classification of maize seeds based on active contour model [J]. Journal of Data Acquisition and Processing, 2013, 28(3): 289-293.

[15] 安斌, 陈书海, 陈华, 等. 纹理特征在多光谱图像分类中的应用[J]. 激光与红外, 2002, 32(3): 188-190.

    An Bin, Chen Shuhai, Chen Hua, et al.. Application of texture feature in mutispectral image classification [J]. Laser & Infrared, 2002, 32(3): 188-190.

[16] 王书志, 张建华, 冯全. 基于纹理和颜色特征的甜瓜缺陷识别[J]. 农业机械学报, 2011, 42(3): 175-179.

    Wang Shuzhi, Zhang Jianhua, Feng Quan. Defect detection of mulskmelon based on texture features and color features [J]. Transactions of the Chinese Society of Agricultural Machinery, 2011, 42(3): 175-179.

[17] 冯欣, 曾周末, 封皓, 等. 基于小波信息熵的分布式振动传感器系统的扰动评价方法[J]. 光学学报, 2013, 33(11): 1106005.

    Feng Xin, Zeng Zhoumo, Feng Hao, et al.. A method for evaluating the disturbance in distributed vibration sensor based on wavelet information entropy [J]. Acta Optica Sinica, 2013, 33(11): 1106005.

[18] 金飞剑. 基于机器视觉的杂草图像特征提取及识别研究[D]. 镇江: 江苏大学, 2007. 49-56.

    Jin Feijian. Research of Feature Extraction and Recognition Method of Weed Image Based on Machine Vision [D]. Zhenjiang: Jiangsu University, 2007. 49-56.

[19] Wu D, He Y, Nie P, et al.. Hybrid variable selection in visible and near-infrared spectral analysis for non-invasive quality determination of grape juice [J]. Analytica Chimica, 2010, 659(1): 229-237.

[20] Li S, Lin L, Milliken R, et al.. Hybridization of partial least squares and neural network models for quantifying lunar surface minerals [J]. Icarus, 2012, 221(1): 208-225.

[21] 何彬. 基于红外光谱技术的牛奶掺杂判别方法的研究[D]. 天津: 天津大学, 2010. 38-47.

    He Bin. Research on Discriminant Analysis of Milk Adulteration by Infrared Spectroscopy [D]. Tianjin: Tianjin University, 2010. 38-47.

[22] Westerhuis J A, Van Velzen E J J, Hoefsloot H C J, et al.. Multivariate paired date analysis: Multi level PLSDA versus OPLSDA [J]. Metabolomics, 2010, 6(1): 119-128.

[23] Zheng C, Sun D-W, Zheng L. Recent developments and applications of image features for food quality evaluation and inspection -a review [J]. Trends in Food Science and Technology, 2006, 17(12): 642-655.

[24] 孔祥兵, 舒宁, 陶建斌, 等. 一种基于多特征融合的新型光谱相似性测度[J]. 光谱学与光谱分析, 2011, 31(8): 2166-2170.

    Kong Xiangbing, Shu Ning, Tao Jianbin, et al.. A new spectral similarity measure based on multiple features integration [J]. Spectroscopy and Spectral Analysis, 2011, 31(8): 2166-2170.

邓小琴, 朱启兵, 黄敏. 融合光谱、纹理及形态特征的水稻种子品种高光谱图像单粒鉴别[J]. 激光与光电子学进展, 2015, 52(2): 021001. Deng Xiaoqin, Zhu Qibing, Huang Min. Variety Discrimination for Single Rice Seed by Integrating Spectral, Texture and Morphological Features Based on Hyperspectral Image[J]. Laser & Optoelectronics Progress, 2015, 52(2): 021001.
