天然生物材料促进高性能钙钛矿太阳能电池的进展 下载: 639次
1 Introduction
Metal halide perovskites(MHPs)have attracted tremendous attention of both academia and industry communities due to their outstanding optoelectronic merits of high light absorption coefficient[1-2],long electron-hole diffusion length[3-4],tunable bandgap[5-6],and small exciton binding energy[7]. Attributed to the excellent properties,the power conversion efficiency(PCE)of perovskite solar cells(PeSCs)has boosted to a certified value of 25.5% within a decade of efforts[8]. Combined with the advances in manufacturing such as low-cost raw materials[9-10],low-temperature and facile fabrication process[11-12],as well as scalable and flexible compatibility[13-15],PeSCs have become the vanguard of the new renewable and clean solar energy technologies.
In general,perovskite solar cells are composed of the sandwich structures,where the photogenerated carriers in the active layer must travel across the perovskite film,enter the charge transport layer,and finally are collected at the corresponding electrodes. The performances of the PeSCs are the results of the whole system,which requires each layer to collaborate well and all the interfaces to work fluently. However,due to the soft and ionic nature of the perovskite and rapid crystal growth process,numerous defects are inevitable to form at the surface and grain boundaries of perovskite film[16-17]. These defects can act as recombination centers,impeding carrier transport and thus confining the PCE of PeSCs[18-20]. The defects are sensitive to external stress including moisture,heat,light and bias,destroying the long-term stability of PeSCs[21-24]. Moreover,the interfaces in the device are other sources for nonradiative recombination due to unmatched interface energy level alignment,which set the ceiling of photovoltage and further limit the PCE of PeSCs [25-27].
Many strategies have been explored to break the limits by improving the perovskite film quality with fewer defects and modifying the interface energetics,such as additive engineering[28-29],post-treatment[30] and interface design [31-34]. Various functional materials including metal cations,polymers,ionic liquids and fullerene derivatives have been developed to assist the implement of these strategies [35-40]. Recently,natural biomaterials,which are abundant in raw materials,low-cost on fabrication,flexible and biocompatible even biodegradable for application,have been emerging in the field of green optoelectronics devices[41-44],especially for renewable energy technologies[45-49]. Biomaterials play versatile roles as additive to improve perovskite film,as interlayer to improve interface contact,as novel charge transport layer to facilitate carrier transport,even as electrode to improve flexibility(
图 1. 天然生物材料在钙钛矿太阳能电池中的作用,ETL:电子传输层;HTL:空穴传输层[50-55]
Fig. 1. Roles of natural biomaterials in PeSCs. ETL:electron transport layer;HTL:hole transport layer[50-55]
In this review,we retrospect recent progress of natural biomaterials used in PeSCs. In the first section,we introduce the roles of biomaterials on perovskite film including morphology optimization,defect passivation and energetics modification. The following section discusses the biomaterial-assisted perovskite interface. Finally,we give an outlook on the further development of PeSCs with respect to natural biomaterials.
1 Biomaterials-assisted perovskite film
1.1 Morphology optimization
Morphology,which refers to the uniformity,coverage,roughness,crystallinity and grain size of the film,is an important index to assess the quality of perovskite film. The perovskite film with poor morphology can greatly decrease the device performance by causing serious current leakage and substantial charge recombination losses[56-57]. The morphology of perovskite film can be well optimized by natural biomaterials in the way of additive engineering. Biomaterial additives can effectively modulate the perovskite crystallization kinetics,thereby prompting the formation of homogeneous and uniform perovskite film with larger grain size and fewer defect sites.
An interesting study of feeding “coffee” for perovskite film was performed by Wang and coworkers[58]. They introduced 1,3,7-trimethylxanthine,also named as caffeine,into the perovskite film to tune the morphology of perovskite film. It was found that the two conjugated carboxyl groups of caffeine as molecule locks could strongly interact with the unbonded Pb2+ ions,retarding perovskite crystal growth and forcing a preferred crystalline orientation(
图 2. (a)含咖啡因和不含咖啡因的钙钛矿薄膜的形貌图像,(b)含咖啡因和不含咖啡因的钙钛矿薄膜沿(110)晶面的二维掠入射广角x射线衍射图,(c)含咖啡因和不含咖啡因PeSCs的J-V曲线,(d)在氮气环境和85 ℃加热条件下PeSCs的归一化效率衰减曲线[58]
Fig. 2. (a)Morphology images of perovskite films with and without caffeine,(b)normalized azimuth angle plots along(110)crystal plane from the 2D grazing incidence wide-angle X-ray diffraction patterns of perovskite films with and without caffeine,(c)J-V curves of PeSCs with and without caffeine,(d)normalized PCE decays upon 85 ℃ continuous annealing in nitrogen box[58]
Long-chain biopolymers with multiple functional groups can provide more interactions and stronger constraining force to modulate the morphological quality. Yang et al. added wood-based polymer,ethyl cellulose(EC),into the antisolvent to fabricate high quality perovskite film [49]. It was clearly displayed that EC biopolymer slowed down the crystallization process of perovskite film in
图 3. (a)在100 °C退火条件下,含EC和不含EC钙钛矿薄膜的结晶过程,(b)含不同EC浓度钙钛矿薄膜的SEM俯视图,(c)长链EC支架抗膨胀/收缩应力示意图[49],(d)多官能团M13噬菌体的化学结构,(e)基于M13噬菌体模板的钙钛矿晶体生长的工作机制,(f)含M13噬菌体的PeSCs在不同热处理条件下的PCE统计分析[50]
Fig. 3. (a)The crystallization process of perovskite films with and without EC under 100 °C annealing,(b)top-view SEM images of perovskite films with different EC concentrations,(c)the schematic diagram of the long-chain EC scaffold against expansion/shrinkage stress,[49](d)chemical structure of M13 bacteriophage with multiple functional groups,(e)working mechanism of M13 bacteriophage-templated perovskite crystal growth,(f)PCE statistical analysis of PeSCs with M13 bacteriophage under different heat treatment[50]
1.2 Defect passivation
Defects are usually formed when the growth of the crystal lattice is interrupted or misaligned,which are basically unavoidable in practical situation due to the soft and ionic nature of perovskite[16,59]. Diverse defects including vacancies,interstitials and anti-site substitutions exist at the surface and grain boundary of perovskite film,which can act as electronic trap states in the band gap of the perovskite and hence capture photogenerated carriers during PeSCs operation[17,60]. The defects also accelerate ion migrations,and reduce the splitting of quasi-Fermi levels,ultimately decreasing the device PCE[61-63]. Furthermore,defects are detrimental to the stability of perovskite films and solar cells[64-65]. Therefore,it is of great importance to minimize the defect density at the perovskite surface and grain boundary for the enhancement of both efficiency and stability of PeSCs.
Natural biomaterials show impressive capability to passivate defects in the perovskite. Xiong et al. employed forest-based biomaterial,betulin,as defect passivator for the first time and reached an PCE over 21% for p-i-n structured PeSCs(
图 4. (a)森林基生物材料桦木素与钙钛矿相互作用示意图,(b)在正向和反向扫描下,含桦木素和不含桦木素的PeSCs的J-V曲线[51],在(c)没有缺陷、(d)有Pb-I反位缺陷以及(e)PLL钝化Pb-I反位缺陷条件下的MAPbI3(001)晶面电荷密度分布,在(f)没有缺陷、(g)有Pb-I反位缺陷以及(h)PLL钝化Pb-I反位缺陷条件下的MAPbI3(001)晶面态密度[66]
Fig. 4. (a)The schematic illumination of the interactions between forested-based biomaterial betulin and perovskite,(b)J-V curves of PeSCs with and without betulin under forward and reverse scan,[51] charge density distribution of MAPbI3(001)surface(c)with no defect,(d)with Pb-I antisite defect and(e)with Pb-I antisite defect after PLL passivating,density of states of MAPbI3(001)surface(f)with no defect,(g)with Pb-I antisite defect and(h)with Pb-I antisite defect after PLL passivating[66]
Moreover,Hu et al. explored the relationship of passivation effect and molecule interaction strength by using a series of natural amino acid(NAA)molecules including glycine,glutamic acid,proline and arginine as precursor additive(
图 5. (a)天然氨基酸(NAAs)分子的化学结构,包括甘氨酸(Gly)、谷氨酸(Glu)、脯氨酸(Pro)和精氨酸(Arg),原始和各种NAAs钝化的钙钛矿薄膜的(b)稳态和(c)时间分辨光致发光光谱[67],(d)钙钛矿与茶碱、咖啡因和可可碱的相互作用结构及其相应的理论相互作用能,(e)在反向扫描下,含生物材料和不含生物材料的PeSCs的J-V曲线,(f)在连续光照(90 ± 10 mWcm-2)下,经茶碱处理和不经茶碱处理的封装后PeSCs的归一化PCE衰变曲线[48]
Fig. 5. (a)Chemical structure of natural amino acids(NAAs)molecules including glycine(Gly),glutamic acid(Glu),proline(Pro),and arginine(Arg),(b)steady-state and(c)time-resolved photoluminescence(PL)spectra of the pristine and various NAAs-passivated perovskite films,[67](d)interaction structures of perovskite and theophylline,caffeine,and theobromine with corresponding theoretical interaction energy,(e)J-V curves of PeSCs with or without biomaterials’ treatment under reverse scan direction,(f)normalized PCE decays of encapsulated PeSCs with or without theophylline treatment under continuous light(90 ± 10 mWcm-2)exposure[48]
1.3 Energetics modification
Electronic structures are the basic properties of a semiconductor,such as valence band(VB),conduction band(CB),Fermi level(EF)and vacuum level [68-69]. Perovskite with suitable electronic structures is essential to form favorable energy level alignment with adjacent charge transport layers and to improve charge transport in PeSCs [70-71]. A lot of work has demonstrated that the electronic structures of perovskite can be effectively tuned by self-doping effect,which prefer to be more n-type(or p-type)with rich PbI2(or MAI)in the film composition[72-73]. It was reported that the surface electronic structures of perovskites film heavily depended on the underlying work function(WF)of substrates(electrodes)[74-75]. Perovskite surface generally shows the higher WF when deposited on the higher WF substrate. The researchers also used molecule doping via natural biomaterials to adjust the energy level positions of perovskite and improve the performance of PeSCs.
Priya et al. introduced biomaterial deoxyribonucleic acid(DNA)into the perovskite precursor and obtained more p-type perovskite film with superior hole transport capability[52]. The Fermi level of the perovskite film is shifted from -4.91 to -5.01 eV after DNA incorporation. The highest occupied molecular orbital(HOMO)level of DNA matched with the VB of the perovskite,significantly prompting hole transport in the perovskite film. As confirmed by the steady-state photoluminescence(PL)spectra,a remarkable quenching was observed when the DNA-incorporated perovskite contacted with HTL. Therefore,the efficiency of DNA-based PeSCs(20.63%)was significantly improved compared to the control device(18.43%). Later,bioactive neurotransmitter dopamine was also introduced into the perovskite precursor to fabricate perovskite active layer with favorable energetics,reported by Zhang and coworkers[76]. They found a downshift of EF toward VB for dopamine-incorporated perovskite film,accompanied by a valence band maximum(VBM)of -5.22 eV,which matched with the hole transport layer(-5.20 eV)compared with the pristine perovskite film with a VBM of -5.33 eV. The intimate contact facilitated hole transfer from the perovskite into HTL with a reduction of charge recombination,and largely increased the device performance.
Recently,Capsaicin,the compound that makes chili pepper spicy,was reported having a significant impact on the perovskite energetics by Xiong and coworkers.[77] They added a small amount of capsaicin into the perovskite precursor and systematically investigated the electronic structure of perovskite film. As shown in
图 6. (a)PTAA:F4TCNQ、沉积在PTAA:F4TCNQ上的原始钙钛矿和含辣椒素钙钛矿的二次电子截止区和价带区的UPS能谱,(b)由UPS能谱得出的钙钛矿在添加和不添加辣椒素时的能级示意图,(c)钙钛矿-辣椒素/PTAA:F4TCNQ/ITO的截面AFM形貌及在0 V偏压下对应的KPFM图像和电势变化曲线,(d)在正向和反向扫描下,掺杂辣椒素和不掺杂辣椒素PeSCs的J-V曲线,(e)近期基于多晶和单晶MAPbI3的 p-i-n型 PeSCs的研究[77],(f)在室温下和45% 相对湿度的环境空气中,未封装的PeSCs的效率演变曲线,(g)含肉碱和不含肉碱钙钛矿薄膜的二次电子截止区UPS能谱(左)、价带区LEIPS能谱(中)和导带区LEIPS能谱(右),(h)含肉碱和不含肉碱的PeSCs的能级示意图[78]
Fig. 6. (a)UPS spectra of secondary electron cutoff region and valence band region of PTAA:F4TCNQ,pristine perovskite and capsaicin-containing perovskite deposited on PTAA:F4TCNQ,(b)energy levels of perovskite with and without the capsaicin derived from UPS spectra,(c)cross-sectional AFM topographies,corresponding KPFM images,and potential profiles under zero-voltage bias of perovskite-capsaicin/PTAA:F4TCNQ/ITO,(d)J-V curves of PeSCs with or without the capsaicin under reverse and forward scan directions,(e)recent works on polycrystalline based and single-crystal MAPbI3-based p-i-n PeSCs,(f)evolution of the PCEs measured from unencapsulated PeSCs in ambient air with 45% relative humidity(RH)at room temperature(RT),[77](g)UPS spectra of secondary electron cutoff region(left panel),LEIPS spectra of valence band region(middle panel),and LEIPS spectra of conduction band region(right panel)of the perovskite films with and without the carnitine,(h)the schematic illustration of the energy levels of PeSCs with and without carnitine[78]
Chen et al. also used natural vitamin B(carnitine)as an energetics modifier to fabricate high-performance PeSCs[78]. After the incorporation of vitamin B,it was observed that the WF increased by 150 meV,and the VBM shifted toward EF by 100 meV,while the conduction band minimum(CBM)shifted away from the Fermi level by 310 meV(
2 Biomaterials-assisted interface
Interface,which governs carrier extraction and collection in the devices,is of great importance to the efficiency and stability of PeSCs. An ideal interface generates no energy loss when carriers pass through the interface. Furthermore,interface should be robust enough with a strong barrier for ion migration,and oxygen and moisture permeation[80-82]. With this purpose in mind,the researchers put extensive efforts to improve interface contact,optimize interface energetics,and minimize interfacial trap states[83-86]. In this section,we focus on recent work of using biomaterials for interface engineering in PeSCs,in terms of electron transport layer,hole transport layer and stretchable electrode.
2.1 Electron transport layer
TiO2 is common ETL in conventional n-i-p PeSCs due to its suitable electronic structures and brilliant chemical,electronical and optical properties[87-89]. However,tremendous oxygen vacancies on TiO2 surface and the ultraviolet photocatalysis effect can trigger the decomposition of perovskite,leading to poor efficiency and stability of PeSCs[90]. You et al. utilized biopolymer heparin sodium(HS)as an interlayer anchored on TiO2 surface(
图 7. 基于HS修饰TiO2的PeSCs的SEM截面图,(b)原始和HS修饰的TiO2,以及(c)沉积在原始和HS修饰的TiO2基底上的钙钛矿薄膜的SEM俯视图,(d)在正向和反向扫描下,无HS层和有HS层的PeSCs的J-V曲线,(f)在氮气和空气环境中,无HS层和有HS层的PeSCs的稳定性测试[91],(g)DNA与介孔二氧化钛相互作用机制的示意图,(h)未掺杂与DNA掺杂的介孔二氧化钛表面电势曲线[92]
Fig. 7. (a)Cross-section SEM image of PeSCs with HS modified TiO2,top-view SEM images of:(b)pristine and HS-modified TiO2,and(c)perovskite films deposited on pristine and HS-modified TiO2 substrates,J–V characteristics of PeSCs(d)without and(e)with HS layers under forward and reverse scan directions,(f)stability test of PeSCs without and with HS interlayers in N2 and ambient environment,[91](g)the schematic illumination of the interaction mechanism between DNA and meso-TiO2,(h)the surface potential curves of undoped and DNA doped meso-TiO2[92]
Recently,Das et al. proposed a new type of bio-PeSCs[53],where natural biomaterials,bacteriorhodopsin(bR),are bridging perovskite and mesoporous TiO2 ETL to enhance light energy conversion efficiency(
图 8. (a)生物PeSCs的器件结构,(b)钙钛矿与bR之间的FRET原理图,(c)生物PeSCs的能级示意图,(d)bR修饰前后PeSCs的J-V曲线[53]
Fig. 8. (a)Device structure of the bio-PeSCs,(b)the schematics of the FRET process between perovskite and bR,(c)band alignment of the bio-PeSCs,(d)J-V curves of PeSCs with and without bR modification[53]
Besides biopolymers,small biomaterials also exhibit excellent interfacial behaviors in PeSCs. Zhang et al. applied neurotransmitter(dopamine)to modify TiO2,creating a cross-link between TiO2 and perovskite(
图 9. (a)多巴胺与钙钛矿和TiO2界面的相互作用示意图,(b)能级示意图,(c)在氮气气氛中和持续光照下,以TiO2和多巴胺修饰的TiO2为电子传输层的PeSCs的归一化PCE变化曲线[93],不同HAP含量的PeSCs在水中浸泡0~24 h后的(d)照片和(e)Pb释放浓度[95]
Fig. 9. (a)The schematic interactions of dopamine with perovskite and TiO2 interface,(b)energy level diagram,(c)the normalized PCE change of PeSCs with TiO2 and dopamine-capped TiO2 as ETLs kept under continuous full-sun illumination in nitrogen atmosphere[93],(d)photographs and(e)Pb release concentrations of PeSCs with different HAP contents after the immersion in water for 0-24 h[95]
The ETL SnO2 possesses high carrier mobility and can be deposited at low temperature[96-97]. However,the poor film crystallinity of SnO2 creates numerous trap states,which triggers interface recombination and decreases the device performance[98]. Dopamine was proposed to modify the interfacial contact between SnO2 and perovskite film by Hou and coworkers.[99] They prepared a self-assembled monolayer(SAM)of dopamine(DA)between SnO2 and perovskite. Similar to the case of TiO2,dopamine anchored on SnO2 surface and passivated the defects on SnO2 surface. Dopamine also improved the surface affinity of the SnO2 film,providing a good template for perovskite growth and thus creating the high-quality perovskite film with enlarged grain size and smoother surface. Dopamine could further reduce the WF of SnO2 with the formation of an interfacial dipole,enhancing electron extraction at the interface. Kim et al. introduced a biomolecule SAM of creatine on the SnO2 surface to improve ETL/perovskite interface(
图 10. (a)肌酸层在钙钛矿/SnO2界面的偶极子效应,(b)肌酸层的缺陷钝化作用,(c)UPS能谱得出的能级示意图[100],(d)以Isatin和Isatin-Cl 为阴极中间层的器件结构示意图,(e)能级示意图,(f)在正向和反向扫描下,原始、Isatin和Isatin-Cl 修饰后器件的J-V曲线[84]
Fig. 10. (a)Dipole effect of creatine layer at the perovskite/SnO2 interface,(b)defect passivation ability of the creatine layer,(c)energy level illustration of the UPS results,[100](d)the schematic of device structure with Isatin and Isatin-Cl as cathode interlayer,(e)the energy level diagram,(f)J-V curves of pristine,Isatin and Isatin-Cl optimized devices under forward and reverse scan directions[84]
Fullerene and its derivatives are the main organic materials used for ELT in inverted p-i-n PeSCs[101]. However,the large energy difference between the LUMO of PCBM and WF of metal electrodes impairs the electron collection efficiency at the cathode and limits the overall efficiency of PeSCs. Xiong et al. used natural biomaterials Isatin and its derivative Isatin-Cl(
2.2 Hole transport layer
Hole transport layer(HTL)takes the responsibility of hole transport and extraction during PeSCs operation. The HTLs generally include PEDOT:PSS,Spiro-OMeTAD,polytriarylamine(PTAA)and inorganic NiOx[102]. Among them,Spiro-OMeTAD is considered to be the landmark during the development of PeSCs,which established all-solid PeSCs with a PCE over 10%[103]. However,Spiro-OMeTAD needs additional doping of bis(trifluoromethane)sulfonimidelithium salt(LiTFSI)and hydrophilic 4-tert-butylpyridine(tBP)to enhance solubility and hole mobility,which not only complicates the fabrication process but also brings poor stability due to the hygroscopic and diffusive nature of these dopants[102]. Therefore,there is urgent demand to develop cost-effective and dopant-free HTLs for highly efficient and stable PeSCs.
Li et al. demonstrated that natural photosynthetic catalyst Chlorophyll was feasible for hole transport in PeSCs[104]. They utilized zinc Chlorophyll aggregates,Chl-1 and Chl-2,as HTL without dopants,and then fabricated CH3NH3PbI3-xClx based PeSCs with a PCE of 11.44%(
图 11. (a)叶绿素锌聚集物Chl-1和Chl-2的分子结构,(b)以Chl-1、Chl-2、P3HT为空穴传输层的PeSCs能级图,(c)时间分辨PL衰变曲线[104],(d)腺嘌呤修饰前后NiOx膜的UPS能谱,(e)器件能级示意图,(f)在正向和反向扫描下,腺嘌呤修饰前后器件的J-V曲线[54]
Fig. 11. (a)Molecular structures of zinc chlorophyll aggregates,Chl-1 and Chl-2,(b)the energy level diagram of PeSCs based on Chl-1,Chl-2,and P3HT as HTLs,(c)time-resolved PL decays,[104](d)UPS spectra for NiOx film before and after adenine modification,(e)the energy diagram of the device,(f)J-V curves of control and adenine-modified devices under forward and reverse scan directions[54]
NiOx is commonly used as HTL in inverted PeSCs with the advance of low cost and good stability,however,its high VBM level and poor conductivity largely restrict the device performance[106]. Recently,Xie et al. reported that natural biomaterial adenine was an excellent surface modifier for NiOx HTL[54]. The adenine modification reduced the WF of NiOx by 0.05 eV and increased the VBM of NiOx from 0.71 to 0.86 eV,leading to a deeper VB level of 5.4 eV than the pristine NiOx film(5.3 eV)(
PEDOT:PSS is also widely used in the inverted PeSCs due to its facile and soluble fabrication process. However,its low WF limits the device photovoltage,and the acidic nature of PEDOT:PSS is also detrimental to the long-term stability of PeSCs[107-108]. To overcome the drawbacks of PEDOT:PSS,Li and workers introduced dopamine(DA)into PEDOT:PSS aqueous solutions[109]. The WF of PEDOT:PSS was surprisingly increased from 5.1 to 5.33 eV after doping dopamine,and the PH value raised from 1.5 to 5.2. The improved WF matched well with the VB of perovskite(5.4 eV),facilitating charge transfer and eliminating the photovoltage limit(
图 12. (a)共聚物DA-PEDOT:PSS的合成条件以及PEDOT:PSS和DA-PEDOT:PSS在PeSCs中的能级[109],(b)PEDOT:PSS和DA-PEDOT:PSS的掺杂差异,(c)PEDOT:PSS和DA-PEDOT:PSS分别在室温和373 K下的ESR谱,(d)基于PEDOT:PSS和DA-PEDOT:PSS的PeSCs的J-V曲线,(e)基于PEDOT:PSS和DA-PEDOT:PSS的PeSCs在空气环境中(温度≈25 ℃,湿度≈40%)的长期稳定性[110]
Fig. 12. (a)Synthesis condition,copolymer of DA-PEDOT:PSS,and energy levels of PEDOT:PSS and DA-PEDOT:PSS in PeSCs,[109](b)considerable differences in doping of PEDOT:PSS and DA-PEDOT:PSS,(c)ESR spectra of PEDOT:PSS and DA-PEDOT:PSS at room temperature and 373 K,respectively,(d)J–V curves of PEDOT:PSS and DA-modified PEDOT:PSS based PeSCs,(e)long-term stability of PeSCs with PEDOT:PSS and DA-modified PEDOT:PSS HTLs in air under ambient conditions(temperature ≈ 25 ℃,humidity ≈ 40%)[110]
2.3 Stretchable electrode
Stretchable electrodes play a key role in flexible PeSCs and the further application of PeSCs in wearable electronic devices. The commonly used flexible electrodes are based on silver nanowire networks or copper conductors,which are usually coated on plastic substrates such as polyethylene terephthalate(PET)and polyethylene naphthalate(PEN)[111-112]. Although these electrodes exhibit good stretchable capability and mechanical stability,the plastic substrates are hard to degrade in the environment and will cause white pollutions. Therefore,biomaterial-based flexible electrodes attract more attention due to their environmental harmless,biodegradable and biocompatible ability.
Cellulose paper,as a mature technique,is low-cost,light-weight,flexible,biocompatible and totally biodegradable,making it being an attractive substrate for flexible devices,which has been used in flexible sensors and organic solar cells. In 2018,Gao et al. employed carbon-modified cellulose paper as anode electrode and fabricated HTL-free flexible PeSCs for the first time(
图 13. (a)纸基无空穴传输层的PeSCs的器件结构图及(b)相应的能级图,(c)在正向和反向扫描下,纸基无空穴传输层的PeSCs的光伏性能,(d)不同弯曲周期的纸基器件的J-V曲线,(e)粘贴在手腕上的无空穴传输层的纸基PeSCs的光学图像,(f)弯曲半径R为6 mm[113]
Fig. 13. (a)Device structure of paper based HTM-free PeSCs and(b)corresponding energy level diagram,(c)photovoltaic performance of paper based HTM-free PeSCs under forward and reverse scan directions,(d)J-V curves of paper based device with different bending cycles,(e)optical image of paper based HTM-free PeSCs attached on the wrist and(f)bent with radius(R)of 6 mm[113]
图 14. (a)竹源纤维素纳米纤维(b-CNF)电极的制备工艺,(b)b-CNF/IZO电极从随机皱折中恢复的照片,(c)b-CNF/IZO和PET/IZO电极在不同曲率半径下弯曲时的方阻,(d)在曲率半径为4 mm的情况下,周期性弯曲试验中柔性PeSCs的主要参数变化[55]
Fig. 14. (a)Preparation process of bamboo-derived cellulose nanofibril(b-CNF)electrodes,(b)photographs of b-CNF/IZO electrode recovery from random crumpling,(c)square resistance of b-CNF/IZO and PET/IZO electrode bending at different curvature radii,(d)the main parameters’ variation of the flexible PeSCs upon periodic bending tests of a 4 mm curvature radius[55]
图 15. (a)基于M13噬菌体模板的金纳米线电极制备工艺示意图,(b)在PDMS上的基于病毒模板的金纳米线的示意图,(c)基于M13病毒模板的金纳米线电极拉伸能力测试,(d)基于M13病毒模板的金纳米线电极的PeSCs拉伸能力测试[114]
Fig. 15. (a)The schematic illustration of preparation process of M13 bacteriophage-templated gold nanowire electrode,(b)illustrations of the virus-templated Au nanowires on PDMS with PTAA and perovskite layers,(c)stretchable ability test of M13 virus-templated Au nanowire electrode,(d)stretchable ability test of M13 virus-templated Au nanowire-based PeSCs[114]
3 Summary and outlook
In this review,we have summarized recent progress of natural biomaterials boosting highly efficient and stable PeSCs. Natural biomaterials play significant roles in active layer and interface of PeSCs. For the active layer,various natural biomaterials have been successfully introduced into the perovskite precursor to improve morphology,reduce trap density,and modify electronic structure of perovskite films,increasing device efficiency. The mechanism behind the improved perovskite film quality includes multiple factors such as retarded crystallization process,defect passivation via various functional groups and doping behavior. Natural materials also benefit for the long-term stability of PeSCs,attributed to the elimination of vulnerable defects and the enhancement of perovskite crystal structure. In terms of interface,natural biomaterials are effectively applied as buffer layer and charge transport layer to improve interface contact and hence minimize interface charge recombination loss in PeSCs. The mechanism behind the enhanced interface properties is mainly ascribed to the favorable energy level alignment induced by natural biomaterials,boosting charge transfer at the interface. Furthermore,natural biomaterials-based electrodes show excellent flexibility,strong stretchable ability,brilliant biocompatibility and biodegradability,which are suable for the fabrication of flexible and wearable PeSCs.
In fact,the performance of biomaterials-based PeSCs still lags behind the chemicals-based counterparts. To further improve the efficiency and stability of biomaterials-based PeSCs,in-depth understand of interactions between biomaterials and perovskite should be carefully investigated. The mechanism behind biomaterials-assisted perovskite formation and interface optimization is still unclear. Further exploration of novel biomaterials is highly required for the customized demands of PeSCs. Meanwhile,we also hope the application of natural biomaterials in lead-free PeSCs. The integration of green and biodegradable biomaterials with the nontoxic perovskite would fabricate the full green PeSCs with high efficiency and long-term stability.
[24] Yang J, Liu X, Zhang Y, et al. Comprehensive understanding of heat-induced degradation of triple-cation mixed halide perovskite for a robust solar cell[J]. Nano Energy, 2018, 54: 218-226.
[47] Li J, Wang N, Wang Y, et al. Efficient inverted organic solar cells with a thin natural biomaterial L-Arginine as electron transport layer[J]. Sol. Energy, 2020, 196: 168-176.
[54] Xie L, Cao Z, Wang J, et al. Improving energy level alignment by adenine for efficient and stable perovskite solar cells[J]. Nano Energy, 2020, 74: 104846.
[86] Xiong S, Dai Y, Yang J, et al. Surface charge-transfer doping for highly efficient perovskite solar cells[J]. Nano Energy, 2021, 79: 105505.
